Quick Start Guide

Hardware Specifications

Item
Chassis Specifications
Size
Weight
Temperature
Humidity
Network Interfaces
Ports
2.4GHz Radio
5 GHz Radio
Radio Frequencies
Power Supply Specifications
PoE Input Power
AC Power Adapter
Power Consumption
Regulatory Compliances
Radio
Emissions
Immunity
Safety
Specification
W x D x H: 140 x 140 x 47.8 mm (5.51 x 5.51 x 1.88 inches)
500 g (1.10 lbs)
Operating: 0 °C to 40 °C (32 °F to 104 °F)
Storage: -20 °C to 70 °C (-4 °F to 158 °F)
Operating: 5% to 95% (non-condensing)
One RJ-45 Port: 1000BASE-T, PoE (PD)
IEEE 802.11b/g/n
IEEE 802.11a/n
2400 ~ 2483.5 MHz
2412 ~ 2472 MHz
5745 ~ 5825 MHz (China)
5180 ~ 5320 MHz (ETSI)
5500 ~ 5700 MHz (ETSI)
48 VDC, 0.3A
AC Input: 100 ~ 240 VAC
DC Output: 12 VDC, 2 A
22.5 W maximum
ETSI 300 328 (802.11b/g)
ETSI 301 893 (802.11a Full range)
ETSI 301 489 (DC power)
FCC Part 15C 15.247/15.207 (2.4-2.4835GHz, 5.725-5.850GHz)
FCC Part 15E 15.407 (5.150GHz-5.250GHz)
NCC LP0002 (2.4-2.4835GHz, 5.250-5.350GHz, 5.725-5.850GHz)
EN 55022:2007, Class A/B
IEC 61000-3-2/3
FCC Class B Part 15
CNS13438
EN 55024:2001 + A2:2003
IEC 61000-4-2/3/4/5/6/8/11
CSA c us (CSA/UL60950-1)
CB (IEC60950-1)
– 6 –
