1
3. Connect Cables
Mounting on a Ceiling T-rail
.
1
Position the AP's ceiling-mount clip holders on either side of the T-rail.
2
Turn the AP until the two clips lock the AP to the T-rail.
Connect network cable to the RJ-45 port for your network connection. The RJ-45
port connection can also provide PoE power to the unit.
1
Connect Category 5e or better cable to the RJ-45 port.
2
– 3 –
Quick Start Guide
1
