NOTE 3: If no video displayed and on screen display says "Not Supported Format" adjust
resolution and frame rate on source device.

SUPPORTED RESOLUTIONS

Supported Resolutions
640x480p @ 59.94 / 60Hz
720x480p @ 59.94Hz
720x480p @ 60Hz
720x576p @ 50Hz
1280x720p @ 50Hz
1280x720p @ 59.94 / 60Hz
1920x1080i @ 50Hz
1920x1080i @ 59.94 / 60Hz
1920x1080p @ 50Hz
1920x1080p @ 59.94 / 60Hz
1920x1080p @ 23.98 / 24Hz
1920x1080p @ 25Hz
1920x1080p @ 29.97 / 30Hz
640x480 @ 59.94 / 72.809Hz (DVi only)
800x600 @ 60.317 / 72.188Hz (DVi only)
1024x768 @ 60 / 70.069Hz (DVi only)
1280x768 @ 60 Hz
1280x1024 @ 60 Hz (DVi only)
1600x1200 @ 60 Hz (DVi only)
If Tx LED continues to flash slower than "no signal" mode), and there is no video or video is
poor, then the resolution is not supported.
(DVi only)
Resolution
480p
576p
720p
1080i
1080p / 60
1080p / 24
VGA
SVGA
XGA
WXGA
SXGA
UXGA
9
