Supported Mandatory CEA 3D Video Format Timings
1280x720p @ 50Hz Top-and-Bottom
1280x720p @ 50Hz Frame packing
1280x720p @ 59.94 / 60Hz Top-and-Bottom
1280x720p @ 59.94 / 60Hz Frame packing
1920x1080i @ 50Hz Side-by-Side (Half)
1920x1080i @ 59.94 / 60Hz Side-by-Side (Half)
1920x1080p @ 23.98 / 24Hz Top-and-Bottom
1920x1080p @ 23.98 / 24Hz Frame packing
If the RX status LED continues to flash slower than "no signal" mode or on screen display shows
RX
check if display supports 3D format. Try switching the 3D video format on the source.

SUPPORTED AUDIO BIT RATES

 Digital Audio from HDMI inputs: Up to 6Mbit/s bit-rate
 Supports AC3 and DTS
 Supports 2-channel PCM audio: 16~24 bits audio sample with 32~96KHz sampling rate
2-channel PCM
16 bits
24 bits
32KHz 44.1KHz
YES YES
YES YES
48KHz 96KHz
YES YES
YES YES
