- Page 1 TECHCONNECT HDBT OWNERS MANUAL www.visionaudiovisual.com/techconnect/tc2-hdbt TC2-HDBTv2_manual_en_v1.doc...
-
Page 2: Declaration Of Conformity
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. All products are designed and imported into the EU by ‘Vision’ who is wholly owned by ‘Azlan Logistics Ltd.’, Registered in England Nr. 04625566 at Lion House, 4 Pioneer Business Park, Clifton Moor, York, YO30 4GH. -
Page 3: Place Of Installation
WARNING SIGNS If you detect an abnormal smell or smoke, turn this product off immediately and unplug the power cord. Contact your reseller or Vision. PACKAGING Save all packing material. It is essential for shipping in the event the unit ever needs repair. - Page 4 This product sends uncompressed HDMI over CAT6 (ethernet) cables. The cable can be up to 70m long. Vision’s HDBaseT products will work with other HDBaseT approved by the HDBaseT Alliance. HDBaseT signal cannot be routed through a TCP/IP network. This product simply passes the EDID information through and cannot change it.
-
Page 5: Indicator Lights
CAT5e or CAT6 cable. CAT6 is superior quality and has a lower skew rate. NOTE: The most common cause of problems is poor quality CAT5e/6 cable. Vision strongly recommends you use quality CAT6 cable with a low skew rate. POWER ON HDBT DEVICES POWER ON DISPLAY POWER ON SOURCE TC2-HDBTv2_manual_en_v1.doc... -
Page 6: Troubleshooting
TROUBLESHOOTING If your system is not operating properly, please refer to the following information. If the problem persists, disconnect from power and contact your AV reseller immediately. Problem Correction Status lights no on Check CAT5e/6 cable • The cable should be wired to 568B standard at both ends. •... -
Page 7: Specifications
SPECIFICATIONS TRANSMITTER/RECEIVER DIMENSIONS: 106 x 74 x 15 mm PRODUCT WEIGHT: 0.36 kg (per set) CONSTRUCTION MATERIAL: Metal COLOUR: White TECHNICAL DETAILS: Signaling rates: 2.97Gbits x 3 Input Video Signal: 0.5-1.0 volts p-p Input DDC Signal: 5 volts p-p (TTL) HDMI Maximum Resolution: 3840 x 2160 (“4k”) HDMI Version: 1.4 (3D) Operating temperature range: -5 to +35°C (-41 to +95 °F) -
Page 8: Warranty
WARRANTY This product comes with a 2-year return to base warranty, effective from the date of purchase. This warranty applies only to the original purchaser and is not transferable. For the avoidance of doubt, this will be taken from the information held by the appointed national distributor at the point of sale.
