Page 1: Operating Instructions
Model No.: EX0101-W50/W51 Operating Instructions Thanks for purchasing our product. Please be sure to read this instruction manual carefully before using our product. - Page 2 EX0101-W50/W51 has the ability of buffering and amplifying. Series connection of EX0101-W50/W51 achieves long distance transmission of HDMI signal. When two pairs or more EX0101-W50/W51 are sacked together, they can be used to create a larger distribution(Daisy chained.) The IR system call back the source at the end of destination.
-
Page 3: Hdmi Extender (By Cat-5E/6 Cable)
HDMI Extender (By CAT-5E/6 Cable) Product Overview ■ ( Model Number: EX0101-W50/W51) Features ■ One pair as a full functional module, no need for setting. Use UTP LAN cable (CAT-5E/6) to substitute HDMI cable to achieve long distance transmission. UTP cable termination follows the standard of IEEE-568B. - Page 4 Notice Grandbeing Inc. reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. Warning To reduce the risk of fire, electric shock or product damage: 1. Do not expose this apparatus 6. Clean this apparatus to rain, moisture, dripping or only with dry cloth.
-
Page 5: Package Contents
: HD-LCD/HD-DLP ) into EX0101-W51. Connect the IR TX UNIT into EX0101-W50 IR TX, Connect the IR RX UNIT into EX0101-W51 IR RX. Remark: In most cases the power adapter could be taken off. The power adapter is only needed when the signal source has no sufficient power driving ability. -
Page 6: Specifications
Specifications ■ Operating Temperature Range -5 to +35°C ( -41 to +95 °F ) Operating Humidity Range 5 to 90 % RH ( no condensation ) Input Video Signal 0.5-1.0 volts p-p Input DDC Signal 5 volts p-p ( TTL ) DTV/HDTV: 1080p/1080i/720p/576p/480p/576i/480i, Video Format Supported... -
Page 7: Panel Descriptions
Panel Descriptions ■ 1.EX0101-W50 Front Panel Back Panel Page 5... - Page 8 2.EX0101-W51 Front Panel Back Panel Page 6...
-
Page 9: Typical Application
Typical Application ■ Power cable connection ■ (optional) If use power cable to connect this two units as above, only one of the unit needs to use the power adapter. The other unit can fetch the power from the the power cable. Maintenance ■... -
Page 10: Product Service
Product Service ■ ● Provided Service Damage Requiring service: The unit should be serviced by qualified service personnel if: The DC power supply cord or AC adaptor has been damaged; Objects or liquids have gotten into the unit; The unit has been exposed to rain; The unit does not operate normally or exhibits a marked change in performance;... -
Page 11: Warranty Limits And Exclusions
the repair of any unit received without such proof of purchase. ● Warranty If your product does not work properly because of a defect in materials or workmanship, Grandbeing Company (referred to as “the warrantor”) will, for the length of the period indicated as below, （Parts (1) Year， Labor(90) Days）which starts with the date of original purchase (“Limited Warranty period”), at its option either (a) repair your product with new or refurbished parts, or (b) replace it with a new or a refurbished product. - Page 12 damages for lost time, cost of having someone remove or re-install an installed unit if applicable, travel to and from the service location, loss of or damage to media or images, data or other recorded content. The items listed are not exclusive, but are for illustration only.) Parts and service, which are not covered by this limited warranty, are your responsibility.
- Page 13 Grandbeing Technology Co., Ltd. Address: 6C, Jialitai Building, No. 6 Yanshan Road, Nanshan District Shenzhen, P.R. China Tel: 86-755-26678449 Fax: 86-755-26678549 Post Code: 518067 www.grandbeing.biz...
