INFO
Press INFO button on Rx to see on screen display:
 Signal Quality
 Source (relates to other versions of product)
 Channel
 Resolution

STATUS INDICATORS

Standby Power saving
Boot up 15~20 seconds for
system boot up.
Searching If system can‟t
available establish link over 80s
channels after initialization.
Wireless No input from selected
source
linked
Mode
Video format not
recognized
Video format
recognized
NOTE 1: If link does not establish the transmitter may be out of range. Adjust distance between
Tx and Rx. The maximum video transmission range for 1080p content is up to 7m (20 feet) in
line of sight (LOS). The minimum range is 2m (6.5 feet).
Rx Power Rx Status
LED
Solid Red
Flashing Flashing
Blue
Flashing Flashing
Blue
Solid Blue Flashing
(Quickly)
Solid Blue Flashing
(Slowly)
Solid Blue Solid Blue
Rx OSD Display
LED
off
-
