3

Installation

Figure 3-1
Wall mounting
Mount the antenna mounting plate onto the wall (position A). Use two
holes in the antenna mounting plate.
26
A
Option for Mounting the ANT793-6MN on a Mast
B
Compact Operating Instructions ANT793-6MN
A5E01116925B-05
