As shown below, the entire headband also rotates around the universal mount which
will allow for different positions of the head band over the users head. This movement
also allows the eye piece to be positioned up and down in the user's field of vision.
Eye piece tilt
Once the head band has been optimally adjusted, we turn our attention to the
eyepiece. As shown above, the eye piece can be tilted towards the eye by as much as
plus or minus 15 degrees from center. This allows for the optimum placement of the
display eye piece in your vision field from low near the cheek to high near the eyebrow
while allowing the eyepiece to be tilted towards the user's eye.
4
Vuzix 425PB0001-01
