  • Page 1 v1.0.6...

  • Page 2: Table Of Contents

    Table of Contents What’s in the Box....3 YouTube Streamer ... 37 Selecting Your Dominant Eye ..4 Streamer Playlist Formats.

  • Page 3: What's In The Box

    WHAT’S IN THE BOX • Smart Swim™ (1x) • Bungies (4@5 sizes) • Battery pack (1x) (not waterproof) • USB charge cable (1x) • USB splitter cable (1x) • Floats (6x) • Grappling tool (1x) • Case (1x) • Reference Card (1x) •...

  • Page 4: Selecting Your Dominant Eye

    SELECTING YOUR DOMINANT EYE 1. Power on Smart Swim™ 2. Scroll to “System Configure” 3. Open “System Configure” App ― *The first time opening this app will require a system reboot 4. Select the “eye orientation” property 5. Use the Select button to select your dominant eye setting ―...

  • Page 5: Assembly Of Smart Swim

    ASSEMBLY OF SMART SWIM™ BUNGIE SIZE CHART: EXTRA-SMALL(9MM), SMALL(14MM), MEDIUM(19MM), LARGE(23MM), EXTRA-LARGE(32MM)
  • Page 6 Step 1: Step 2: Remove strap and Adjustable Strap Retainer from the goggles. Pull the 23mm O-Ring through the right hole of the goggle. Use the tip of the Grappling Tool to help push the O-ring through and use the Grappling Tool to grab it from the other end. RETAINER RIGHT EYE HAVE A TYR LOGO (LOOKING FROM THE FRONT)
  • Page 7 Step 3: Step 4: Pull the lower strap through three of the 23mm O-rings as Put inside strap through left goggle slot and pull it through. shown and repeat with the upper strap. ...
  • Page 8 Step 5: Step 6: Put the end of the strap through the inner hole of the Put the end of the strap through the outer hole of the Adjustable Strap Retainer. Adjustable Strap Retainer to secure it. NOTE: ENSURE THAT THE “TYR” LOGO IS FACING UPRIGHT.
  • Page 9 Step 7: Step 8: Grab the O-Ring loop on the right goggle slot and pull over In the Goggle Guide, follow the instructions to disconnect the eyepiece. Then, slide the O-ring to the second Hook of the right side of the nose piece. Then, push the nosepiece through Smart Swim Eyepiece.
  • Page 10 Step 9: Step 10: Optional Slide the 9mm O-ring all the way to the right and over the Slide the upper strap over the battery and the lower strap bump. Then, pull the O-ring to the first hook of the Smart under the battery to get the straps behind the battery.

  • Page 11: Charging Smart Swim

    CHARGING SMART SWIM™ Use the included Y-Splitter to share your charging source with Charge state can be determined by plugging in the battery your smart swim. pack and observing. • Blue LEDs: Flashing (charging) • Blue LEDs: Not Flashing (not charging) •...
  • Page 12 Using the phone pairing app, you will observe the power percent: Green = Charging Red = Not Charging...
  • Page 13 The carousel will indicate the charge state from the lower right corner. NOTE: YOUR SMART SWIM REQUIRES 3+ HOURS TO FULLY CHARGE. 100% INDICATED ON THE CHARGE STATE WILL NOT BE ACCURATE WITH- OUT 3+ HOURS OF CONTINUOUS CHARGING. NOTE: MAY TAKE LONGER IF CHARGE SOURCE IS SHARED WITH OTHER DEVICES.

  • Page 14: Power On Smart Swim

    POWER ON SMART SWIM™ Power on Smart Swim™ Power on Smart Swim™ Carousel is ready for navigation...

  • Page 15: Application Overview

    APPLICATION OVERVIEW THE SMART - CAROUSEL System System Apps+And Open Media YouTube Configure Settings Updates Trainer Water Player Streamer...

  • Page 16: Button Interface

    BUTTON INTERFACE • SELECT = Select current item. SELECT FORWARD BACK • BACK (Button A) = Move cursor down/right. • FORWARD (Button B) = Move cursor up/left. • POWER = Sleep or Power off system. • Button Actions are application dependent. •...

  • Page 17: Carousel Operations

    CAROUSEL OPERATIONS • Scroll the icons left or right using button A or button B Button Chart ― Use the Select button to open the center icon/ (Single Press) application Button B: Scroll Icons Right • Display the Date and Time by triple pressing the up button Button A: Scroll Icons Left •...

  • Page 18: System Configure

    1. SYSTEM CONFIGURE • Setup misc. non-Realtime settings • Select Log Splits (Yes, No) • Select dominant eye ― Removes splits from session files • Create Smart Swim™ Device Name. (Format: “username” ― Splits can be enabled or disable via pre-programmed “[SS-####]”) workouts ―...
  • Page 19 • Body Weight – Used in calorie computations • Select GPS file Format (KML-Google Earth, GPX-Garmin Uploads) ― The current algorithm considers users weight, and weather the user is resting or actively moving, total ― Only one format will be saved during a session active time vs total rest time.
  • Page 20 • GPS Course File (Undefined, “File Name”) • Display Theme (“filename”) ― Allows the user to select a GPS Course mapping to ― This option allows the user to change the appearance overlay onto the current rendered tracks of the apps based on the theme file selected. Ex: Black on White background vs.
  • Page 21 Button-Chart • The first time the configuration App is executed the system will require a reboot (Single Press) • Any time the device name is changed the system will Button B: Scroll up settings require a reboot Button A: Scroll down settings •...

  • Page 22: System Settings

    2. SYSTEM SETTINGS Access android operating system settings on Smart Swim™ Button-Chart ― Blue Tooth (Single Press) ― Wi-Fi Button B: Scroll up settings. ― GPS location services Button A: Scroll down settings. ― Clock date and time Select: Select to change setting. ―...

  • Page 23: Apps And Updates

    3. APPS AND UPDATES Button-Chart (Single Press) Button B: Scroll up to previous App update Button A: Scroll down to next App update Select: Select App Update (Double Press) Button B: n/a Button A: n/a Select: (Triple Press) Button B: n/a •...

  • Page 24: Lap Trainer

    4. LAP TRAINER • Lap training tool for pool swimming sessions • Saves Session with intervals and total distances • Shows stats on current speed and distance • Saves snapshot of final session time and distance. • Shows pace clock •...
  • Page 25 Button-Chart Theme-Settings (Single Press) BackGroundColor, CountDownColor, StopWatchColor, StopWatchSize, HidePowerState, FontSelect, DistanceColor, Button B: Finish current set and show next workout-set. DistanceSize, SetxIntervalColor, IntervalSize, Button A: Show previous workout set. TotalDistanceColor, TotalDistanceSize, AnalogScale, Select: Start/Re-Start and save current session. ClockHorizontal, ClockVertical, HideHeading, HideSwimState (Double Press) ClockName, AnalogColor, AnalogCountDownColor, Button B:...
  • Page 26 1. Total Distance in current interval. 2. Pace for current interval. (Based on split distance setting) 3. Intervals accomplished at previous interval distance achieved. 4. Swim state: red = resting, green = swimming, yellow=backstroke. 5. Compass heading indicator and heading. 6.
  • Page 27 Double press Select Button to open a workout file. Workout/Session mode can be: • Free form = no workouts, just swim. • Loaded workout = scroll workout file with Button A or Button B Next/Previous set. Swim at athletes’ pace. •...
  • Page 28 Preprogrammed instruction set: All preprogrammed instructions start with the PRG= tag. 3. PRG=@Repeating=0:0:30,4xSets,4xtimes, set1=1x150(mix), set2=2x75s(IM), 1. PRG=@Resting (resting set) set3=4x50s(free), set4=6x25s repeat 4x. ― Ex: PRG=@Resting=0:00:30, next=7x500s 30 rest, with ― PRG=@Set=2x150, @rest=0:0:15 splits ― PRG=@Set=2x75, @on=0:1:05 ― This record will provide a 30 second rest period prior to starting the next set.

  • Page 29: Open Water

    5. OPEN WATER • Shows metrics on current speed and distance 1. Shows current and average pace • Shows pace clock 2. Shows battery state • Open Water training tool for GPS Open water sessions 3. Shows compass heading • Be sure to enable GPS location services from the settings app 4.
  • Page 30 Button-Chart (Single Press) Button B: Finish current set and show next workout-set. When Grid mode is enabled zoom in. Button A: Show previous workout set. When grid mode is enabled zoom out. Select: Start/Re-Start and save current session. (Double Press) Button B: Finish current set, show current workout-set and restarts stopwatch.
  • Page 31 GPS Digital Mode 1. GPS Satellite connection status ― Red = no satellites connected. (Must wait several minutes for first connection.) ― Green with X = waiting for initial lock to settle (20+ seconds) ― Green with Pause = waiting for user to press start. ―...
  • Page 32 GPS Grid Mode 1. GPS Satellite connection status ― Red = no satellites connected (Must wait several minutes for first connection) ― Green with X = waiting for initial lock to settle (20+ seconds) ― Green with Pause = waiting for user to press start ―...
  • Page 33 Workout Load Screen Workout/Session mode can be: ― Free form = no workouts, just swim. ― Loaded workout = scroll workout file with Button A or Button B Next/Previous set. Swim at athletes’ pace. * No preprogrammed workouts available for Open Water mode...

  • Page 34: Media Player

    6. MEDIA PLAYER • Renders local media content stored on swim. • Supports blue tooth audio devices. • Includes /music files. • Includes /movies files. • Includes /pictures files. • Allows selection of current track. • Shows swim state. • Shows compass heading. •...
  • Page 35 Button-Chart (Single Press) Button B: If video is playing (Volume up) If video is paused (play next track) Button A: If video is playing (Volume down) If video is paused (play previous track) Select: Play/Pause (Double Press) Button B: If video is playing (Reset Bluetooth devices) Button A: Select: Show Track Selection dialog...
  • Page 36 The Media player remembers last location and track The Media player provides a dialog for controlling special features Loop: Loops on currently selected track Autoplay: Loops on All videos, audios and images AutoPause: Will pause current track when user is not swimming HUD On: Turn on all special HUD features...

  • Page 37: Youtube Streamer

    7. YOUTUBE STREAMER • Requires Wi-Fi connection. Button-Chart (Single Press) • Supports blue tooth audio devices. Button B: If video is playing (Volume up), If video is paused (play next track) • Renders you tube video content. Button A: If video is playing (Volume down), If video is paused (play previous •...
  • Page 38 Open the search dialog by double clicking the select button 1. Enter a new search string. ― Top edit box uses keyboard or pairing app to erase and type in a new search string. 2. Select a previously searched search string. ―...
  • Page 39 Button A = up/left by single or double clicking the button. Button B = down/right by single or double clicking the button. This will move the cursor appropriately. Move the cursor over the video of your choice, then press select. When the video first loads after a search you must then press select again to start the video playback process.
  • Page 40 Wi-Fi Signal Status: Green = ok, Yellow = disconnected, Steps to login to your YouTube Account Red = Access required • Open Search dialog • Enable Show Logo option VIDEO COUNTDOWN TIMER TOTAL SESSION TIME • Perform a Video Search •...
  • Page 41 • Move the circular cursor up to the upper right blue login option • Move the cursor over the email id and press Select to open the keyboard. (Use the paring app to assist in sending your email address to fill the email id box) ―...
  • Page 42 • Move the cursor over the password id and press Select to open the keyboard. (Use the paring app to assist in sending your password). ― NOTE: You may need to dismiss the search dialog box using the back button after pressing select. (Press and hold Select to dismiss search dialog) •...

  • Page 43: Streamer Playlist Formats

    8. STREAMER PLAYLIST FORMATS Playlist for the You Tuber streamer app are simple text-based files with a version header record. The system currently supports 3 video string formats. See included playlist samples as a template to get you started. Format 1: StreamVideos(v)-1.0Smart Swim™...
  • Page 44 Use the following steps to retrieve a playlist template to build your own playlist: • Open the Smart Swim Pairing App. • Select the “Download” button. • Select the “Stream Workouts” option. • Select the “PLAY-MPSwims Gold.txt” playlist session. • This will download and open a playlist in your text editor. •...

  • Page 45: Sport Dv Camera

    9. SPORT DV CAMERA Button-Chart (Single Press) • Requires Wi-Fi connection Button B: Zoom out on cameras image. • Renders Sport DV Camera image Button A: Zoom in on cameras image. Select: Restart session time from 00:00. • allows image horizontal stabilization (Double Press) •...
  • Page 46 Turn on Sport DV Cameras Wi-Fi mode. Press power on and see red light. Run the Sport DV Camera App Press and hold mode button and see green light flashing. Wi-fi is now on. Now you see the camera video feed with WIFI signal strength in the upper left corner.
  • Page 47 (Double click Button B) Image correction and other camera details (Double click Button A) Camera credentials dialog • Invert the camera image provides for mounting in left vs right If user has changed their camera login credentials for WIFI eye modes or mounting the camera remotely upside down. connection to the camera.

  • Page 48: Naming Your Smart Swim

    NAMING YOUR SMART SWIM™ Power on Smart Swim™ Use the soft keyboard to enter your unique “Smart Swim™” device name. Scroll to “System Configure” Open “System Configure” App ― Your first time opening the configuration application, your system will be rebooted. The configuration app will reload after the reboot is completed.
  • Page 49 Getting Acclimated • It may take you some time to get acclimated to wearing and using your Smart Swim™. • Be aware of your surroundings. • Start by only viewing the Smart Swim™ Display at random times during your sessions. •...
  • Page 50 Calibrate Sensors 1. At times you may find your onboard sensors are not While holding your Smart Swim™ in front of you, level to the responding properly horizon line. 2. Your lap training sessions are not keeping in step with you Step 1: rotate the system from your right to your left shoulder.
  • Page 51 Step 4: place the system on a flat surface and let it rest for up to 10 seconds. Step 3: rotate the system around the horizon line, in a full circle. Slowly. Calibration completed. This can be performed at any time.

  • Page 52: Your First Swim

    YOUR FIRST SWIM 1. You are now ready for your first swim. NOTE: 2. With a pool close by the Lap Trainer will be your go to ANTI-FOG, NEW GOGGLES YOU WON’T BE TOO CONCERNED FOR YOUR FIRST FEW SWIMS. AS TIME PROGRESSES YOU WILL App.

  • Page 53: Date And Time Settings

    • Enter new day of month using soft keyboard • If pairing with “Vuzix Smart Swim App” date and time will be • Press button A to highlight year set from the paired device based on paired devices date time •...
  • Page 54 Enable GPS Settings NOTE: SATELLITE CONNECTIONS WILL TAKE AS MUCH AS 7 OR MORE MINUTES THE FIRST TIME YOU TURN ON YOUR GPS CONNEC- TION. CONNECTION TIME WILL BE MUCH SHORTER WITH SUC- CESSIVE CONNECTIONS IN THE FUTURE. BE IN AN OUTSIDE OPEN SPACE FOR BEST RESULTS.

  • Page 55: Enable Wi-Fi Networks

    ENABLE WI-FI NETWORKS Scroll to And Open Settings Turn on Wi-Fi Select Wi-Fi option Verify Wi-Fi is detected *If the Wi-Fi requires a password you can use the pairing app to assist in entering it.

  • Page 56: Pairing Bluetooth Devices

    PAIRING BLUETOOTH DEVICES Scroll to And Open Settings Turn on your blue tooth device Select Scan from the blue tooth settings, Select “Visible to all nearby Bluetooth Devices” option Select Blue Tooth Verify your device is found...
  • Page 57 Scroll down with buttons to highlight and then select the device Your blue tooth device is now ready and paired. you want to pair with. Select the Pair button when visible. The system will auto pair with the same device each time you reboot your Smart Swim.

  • Page 58: Managing Installed Applications

    MANAGING INSTALLED APPLICATIONS To clear an applications memory or to uninstall an application This dialog will then allow you to perform system maintenance select this option. The following dialog will allow you to select the on the selected application. application you want to manage. Selecting a System App:...
  • Page 59 Selecting a Non-System App: Results from Uninstalling an app:...

  • Page 60: Smart Swim Phone App

    SMART SWIM™ PHONE APP Using the pairing app will greatly enhance your interaction Once installed you will find the Vuzix Smart Swim App icon with smart swim. You can download and install the Vuzix installed in your apps folder on your phone.
  • Page 61 3. Apps And Updates = login to the your Smart Swim with your Phone. Vuzix private update server and Once you have successfully paired check for updates. with your Smart Swim from your 4.
  • Page 62 “Paired Devices” list. The Swim. You should see the display of your Smart Swim on the “Vuzix Smart Swim App” will connect and operate in either mode. pairing apps front window. The name of your connected Smart Swim will be displayed in the status bar.
  • Page 63 Pairing Apps front control interface window. 1. Tapping on the left side of the SNAP sends the Button A event. ― Double Tap sends Double Button A 2. Swiping left from the center of SNAP will send the Button A event. 3.
  • Page 64 Selecting “DOWNLOAD” provides downloading content and sample workouts from your Smart Swim to your phone. This content can be saved or renamed for sharing, storing or uploading to your Smart Swim for another session. Content downloaded from the above options will be stored at the following locations on your phone: 1.
  • Page 65 Selecting “UPLOAD” provides uploading content from your phone to your Smart Swim. Lap Training Uploaded from either “Download” folder on phone or “Archive” vuzix private server. Open Water Uploaded from either “Download” folder on phone or “Archive” vuzix private server Stream Playlist Uploaded from “Download”...
  • Page 66 Selecting “Manage Content” from the app’s menu, provides located on your Phones “Download” folder. managing/deleting content from your Smart Swim. You can select a workout from the “Archive” Vuzix Private server. The following dialog is presented. Using your phones “Download” folder will allow you to share workouts created from email sources or other web sources that offer Smart Swim compatible workouts.
  • Page 67 Selecting “KEYS” button from the app’s main display, provides a means of sending login and text box entries to Smart Swim as keyboard events. The keyboard will open when selecting this function. Selecting “MSG” button from the app’s main display, provides a means of sending a text message to Smart Swim.

  • Page 68: Smart Swim - Theme Design

    SMART SWIM – THEME DESIGN Themes can be created and modified by the user. You can All theme settings are type checked by the configuration tool design analog clock faces to include with your theme designs. and must be properly formatted. Simply follow the proper file naming convention and save in Examples: your phones download folder to upload from the smart swim...
  • Page 69 Example theme file: “white_background” IntervalSize =75 // SSG-Theme Version(1.0) // FontSelect =sportsball “65%” // HidePowerState =true “Hide the // This theme is a white background // FontSelect =videodames power state bar” StopWatchColor =#FF000000 with colored display and specific // FontSelect =vt323regular “140%” // MapLineColor =”Color of tracking CountDownColor =#FFFF0000 font selection...

  • Page 70: Theme Tutorial

    11. Exit the text editor. 6. Scroll Down to the “DistanceSize” property and change the 12. This will re-open and reconnect the Vuzix Smart Swim value from a “2” to a “10”. pairing app to your Smart Swim.

  • Page 71: Technical Specifications

    TECHNICAL SPECIFICATIONS 1. Wearable Computer Battery Life Chart 2. Android Operating System 3. Wi-Fi • (7 hours) Running just a clock 4. Bluetooth • (5+ hours) Running GPS in accuracy mode 5. GPS Sensor • (3.5 hours) Running Lap Trainer 6.

  • Page 72: Trouble Shooting

    TROUBLE SHOOTING My Smart Swim is not fully charged. Lap Training App is intermittently missing my lap transitions. ― You must wait at least 3+ hours for a fully charged battery. ― Recalibrate your 9-axis sensors by following the calibration steps detailed above. ―...
  • Page 73 My theme setting changes have changed. My Smart Swim Device Name is not properly displayed in the paring apps main Window. ― Whenever the configuration app “restores system defaults” all the default system theme settings will be restored. You ― If you change the device must provide a non-system theme name for your theme.
  • Page 76 Learning More Visit www.vuzix.com/support/smartswim for more information on the Smart Swim™ or contact technical_support@vuzix.com for additional information. For more information on Smart Swim™ AND accessories, visit: vuzix.com | vuzix.eu | vuzix.jp Vuzix Corporation 25 Hendrix Road West Henrietta, NY 14586 ©Vuzix 2020.
