Edificio Genebre. Av. de Joan Carles I, 46-48
08908 L'Hospitalet de Llobregat. Barcelona (Spain)
genebre@genebre.es - www.genebre.es
INSTRUCTIONS FOR INSTALLATION, OPERATION
AND MAINTENANCE MANUAL
1 Piece Ball Valve Reduce Bore.
Ref. GENEBRE: 2035 – 2036 – 2037
GENEBRE S.A.
FECHA DE REVISIÓN: 23/06/2010
NUMERO DE REVISIÓN: 1
1
Advertisement
Table of Contents
Related Manuals for Genebre 2035
Summary of Contents for Genebre 2035
- Page 1 Edificio Genebre. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es INSTRUCTIONS FOR INSTALLATION, OPERATION AND MAINTENANCE MANUAL 1 Piece Ball Valve Reduce Bore. Ref. GENEBRE: 2035 – 2036 – 2037 GENEBRE S.A. FECHA DE REVISIÓN: 23/06/2010...
- Page 2 Edificio Genebre. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es Installation, operation and maintenance manual 1. Parts diagram..................3 1.1 Parts list..................... 3 2. Safety Instructions..................4 3. Installation..................4 4.
-
Page 3: Parts List
Edificio Genebre. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es 1. Parts Diagram. 1.1 Parts List. Name Nº Material Surface Treatment Body Carbon Steel DIN St-37 Painted Extension Pipes Carbon Steel DIN St-37... -
Page 4: Safety Instructions
Edificio Genebre. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es 2. Safety Instructions. IMPORTANT REMARK: Before setting up or handling these valves, READ CAREFULLY this user’s guide and OBSERVE all the contained information. In case you don’t understand some information, please contact with GENEBRE, S.A. - Page 5 3.5 Do not remove the protective covers of the connections until just before installation 4. Welding. 4.1 Is necessary a clean area for work. 4.2 Genebre, S.A. recommends the use of electric welding methods (TIG, MIG). 4.3 Use cooling during the welding process. 4.4 Welding to be performed by a qualified welder.
- Page 6 4.8 Do no open/close the valve immediately after welding. Wait the valve cool before operating it. 4.9 If is necessary to make the pressure test Genebre, S.A. recommend use the instruction of European Standard EN 12.266 part. I. Hydraulic test from seat should be 1,1 PN with closed valve position.
- Page 7 The same at other models of ball valves from Genebre, S.A. the operation is: CLOCKWISE for closed valve. COUNTER CLOCKWISE for open valve.
- Page 8 Edificio Genebre. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es 6. Maintenance. The valves do not need extra service at the normal conditions. 7. Pressure temperature rating. DN 10 - 50 DN 65 - 300...
