D
C
(Note)
Pod interface cable B
Note: The D connector is an extension connector used to connect a pod with a D connector.
CONNECTIONS
READY POWER ERROR
Main unit
B
A
Pod

Fig. 3.1 Connection of Pod Interface Cables

3-4
B
A
Pod interface cable A
Pod interface cable C
