5.9.3
Mounting positions and service plugs
Legend:
Vent / filler plug
5.9.3.1
Wormgears, Serie VF:
VF 27 _ ... VF 49 _
B3
A
B6
B3
N
B6
B3
V
B6
B3
P
B6
B3
F
B6
B3
U
B6
Base mounting position. Gearboxes are plated only for base mounting position (B3). They can
nevertheless also be installed in any of the derived positions (B6, B7, B8, V5, V6). Mounting
position may not be changed after installation.
32 / 64
IOM Manual VF-W_ATEX_gb - Translation of original instructions in Italian - Rev 03_0 - 30/09/16
B7
V5
B8
V6
B7
V5
B8
V6
B7
V5
B8
V6
B7
V5
B8
V6
B7
V5
B8
V6
B7
V5
B8
V6
Level plug
Drain plug
VFR 44 _ , VFR 49 _
HS
Plug in sight
Plug not in sight
S - P (IEC)
