Do not mix oils of different makes or specifications. Make sure also that the oil is highly resistant
to foaming and is EP (Extreme Pressure) rated.
If you do not have the same type of oil, completely drain the gearbox and flush it out thoroughly with the
new oil to remove all traces of the old oil and any contaminants from inside the casing before filling the
gearbox with the new oil.
Oil level can be checked by removing the oil level check plug and checking that the oil spills from the
bottom edge of the hole.
Only use recommended oils to fill and top up the gearbox.
5.9.1 Recommended / permitted lubricants
When using a lubricant other than the recommended SHELL lubricant, be sure it is a synthetic lubricant
with equivalent viscosity and composition and added with adequate anti-foaming agents.
Lubricants for ATEX-specified gearboxes
Greases:
• Klüber Asonic GHY 72
• Klüber Klüberquiet BQ 72-72
• Klüberpaste 46 MR 401
• ITP Fluorocarbon gel 880
Oils (alternatives to Shell Omala S4 WE 320 - standard supply):
• Shell:
• Klüber:
• Total:
• Mobil:
• Castrol
28 / 64
IOM Manual VF-W_ATEX_gb - Translation of original instructions in Italian - Rev 03_0 - 30/09/16
WR 63...WR 86
Helical
reduction
VFR 44...VFR 250
WR 110
W 63...W 110
Worm gear unit
VF 44...VF 250
Worm gear unit
W 63...W 110
c/w torque
VF 44...VF 49
limiter
(for bearings)
(for bearings)
(for easy engagement of cylindrical couplings)
(for lubricating sliding seals)
Tivela Oil S320
Klübersynth GH 6 320
Carter SY 320
Glygoyle 320
Alphasyn PG 320
mounting position
B3 - B6 - B7 - B8 - V5
OMALA S4 WE 320
OMALA S4 WE 320
OMALA S4 WE 320
OMALA S4 WE 460
V6
GADUS S5 V142W 00
