EOS2 SAFETY LIGHT CURTAIN
Electrical connections
Layout of the connectors on MASTER/SLAVE light curtain
8540738 • 05/12/2017 • Rev.20
SLAVE
SLAVE 2
Figure 16 - Connector layout
SLAVE primary connector
SLAVE2 secondary connector
SLAVE2 primary connector
MASTER secondary connector
MASTER
MASTER primary
connector
15
