...to side-discharge:
3
To convert to side-discharge:
• Make sure the mulching plug is installed in the
rear of the mower.
• Lift the mulching cover (A, Figure 10).
• Install the side discharge deflector (B) onto
the mower deck. Make sure the upper tabs
(A, Figure 11) of the deflector are hooked
behind the mulching cover rod, and the deck
tab sticks up through the locking slot (B).
• Release the mulching cover (it will lay
on top of the side discharge deflector).
B
Figure 10
A
B
Figure 11
A
7
