S – Scrambler ZT – Zero Turn Thank you for buying a SNAPPER Product! Before operating your SCRAMBLER, read this manual carefully and pay particular attention to the “IMPORTANT SAFETY INSTRUCTIONS” on Pages 2 - 4. Remember that all power equipment can be dangerous if used improperly. Also keep in mind that SAFETY requires careful use in accordance with the operating instructions and common sense! NOTE: Specifications are correct at time of printing and are subject to change without notice.
If you have any questions pertaining to your machine which your dealer cannot answer to your satisfaction, call or write the Customer Service Department at SNAPPER, McDonough, Georgia 30253. Phone: (1-800-935-2967).
14. Exercise CAUTION when pulling loads. Limit loads to those you can safely control and attach loads to hitch plate as specified with SNAPPER attachment instructions. 15. On slopes, the weight of the towed equipment may cause loss of traction and loss of control.
14. Have machine serviced SNAPPER dealer at least once a year and have the dealer install any new safety devices. MAINTENANCE (Continued From Previous Column) 15. Maintain or replace safety and instruction labels 16.
For the nearest SNAPPER dealer in your area, check the yellow pages under the heading LAWN MOWERS. For engine parts and service, look for the engine manufacturer’s dealers under the heading, ENGINES - gasoline.
Page 7
Section 1 - FAMILIARIZATION 1.3 BASIC CONTROLS AND THEIR FUNCTIONS The figures below identify each of the operator controls and their basic function. Controls will be described in greater detail further on in this manual. 1.3.1. IGNITION SWITCH (Left Control Panel) Starts and stops engine.
Section 2 - OPERATING INSTRUCTIONS WARNING DO NOT attempt to operate the machine until you have read this manual thoroughly and become familiar with all controls and operating procedures. Serious injury or damage can result. 2.1 PRE-START CHECK LIST Make the following checks and perform the service required before each start-up.
Section 2 - OPERATING INSTRUCTIONS 2.3 MOTION CONTROL IMPORTANT: This machine is equipped with hydrostatic drive. The direction and speed of movement are controlled by dual motion control levers. A small amount of movement of either lever may cause the machine to move instantly, and can result in severe injury or damage.
Section 2 - OPERATING INSTRUCTIONS 2.3.4. CONVENTIONAL TURNING 1. To turn left, slowly ease back on the left lever while keeping or increasing pressure on the right lever. See Figure 2.6. The more you ease off on the left lever and/or push on the right lever, the tighter the turn.
Blades must stop rotating in 5 seconds or less after blade switch has been turned off. DO NOT operate machine unless blade brake is functioning properly. If adjustment or repair is necessary, refer to Section “Blade SNAPPER dealer for assistance. engage latch. DETENT PLATE...
Perform the following interlock system checks periodically during the operating season. Contact your authorized Snapper dealer if you have questions. WARNING DO NOT operate machine if any safety interlock or safety device is not in place and functioning properly.
3.1 INTRODUCTION To retain the quality of the SCRAMBLER, use genuine SNAPPER replacement parts only. SNAPPER dealer for parts and service assistance. For the correct part or information for a particular mower, always mention the model and serial number. 3.2 SERVICE - AFTER FIRST 5 HOURS...
Section 3 - MAINTENANCE WARNING DO NOT attempt any adjustments, maintenance, service or repairs with the engine running. Stop engine. Stop blade. Engage parking brake. Remove key. Remove spark plug wire from spark plug and secure away from plug. Engine and components are HOT.
Section 3 - MAINTENANCE WARNING DO NOT attempt any adjustments, maintenance, service or repairs with the engine running. Stop engine. Stop blade. Engage parking brake. Remove key. Remove spark plug wire from spark plug and secure away from plug. Engine and components are HOT.
Page 16
Section 3 - MAINTENANCE WARNING DO NOT attempt any adjustments, maintenance, service or repairs with the engine running. Stop engine. Stop blade. Engage parking brake. Remove key. Remove spark plug wire from spark plug and secure away from plug. Engine and components are HOT.
If there is any problem: leakage, malfunction or etc. return the SCRAMBLER immediately to the nearest authorized Snapper dealer for service. 3.4.6. Fuel Filter Service fuel filter as instructed below. Close fuel valve in fuel line.
Section 4 - ADJUSTMENTS & REPAIR WARNING DO NOT attempt any adjustments, maintenance, service or repairs with the engine running. Stop engine. Stop blade. Engage parking brake. Remove key. Remove spark plug wire from spark plug and secure away from plug. Engine and components are HOT.
However, if there is difficulty in achieving these adjustments and repairs, it is recommended that these repairs be made by an authorized SNAPPER dealer. 4.3.1. MOWER DRIVE BELT ADJUSTMENT The 33” and 38” mower deck drive belts do not require any adjustment.
GUIDE PULLEY FIGURE 4.4 4.3.5. BLADE BRAKE ADJUSTMENT The SNAPPER SCRAMBLER is equipped with an electric clutch/brake that should stop blade rotation in 5 seconds or less after being turned off. If blades continue adjustment or replacement is required. When properly adjusted, a .010”...
Section 4 - ADJUSTMENTS & REPAIR WARNING DO NOT attempt any adjustments, maintenance, service or repairs with the engine running. Stop engine. Stop blade. Engage parking brake. Remove key. Remove spark plug wire from spark plug and secure away from plug. Engine and components are HOT.
Section 4 - ADJUSTMENTS & REPAIR WARNING DO NOT attempt any adjustments, maintenance, service or repairs with the engine running. Stop engine. Stop blade. Engage parking brake. Remove key. Remove spark plug wire from spark plug and secure away from plug. Engine and components are HOT.
It is set to maintain the deck in the same attitude through all heights of cut. If the timing rod requires SNAPPER dealer for service. See Figure 4.13. ADJUSTING 1. Remove rear hanger chains. 2. Turn each hanger pivot the same number of rotations on the eye-bolt to raise or lower the rear of the deck.
Section 4 - ADJUSTMENTS & REPAIR WARNING DO NOT attempt any adjustments, maintenance, service or repairs with the engine running. Stop engine. Stop blade. Engage parking brake. Remove key. Remove spark plug wire from spark plug and secure away from plug. Engine and components are HOT.
Section 4 - ADJUSTMENTS & REPAIR WARNING DO NOT attempt any adjustments, maintenance, service or repairs with the engine running. Stop engine. Stop blade. Engage parking brake. Remove key. Remove spark plug wire from spark plug and secure away from plug. Engine and components are HOT.
Section 4 - ADJUSTMENTS & REPAIR 4.6.5. BATTERY TESTING There are two types of battery tests: Unloaded and Loaded. The unloaded test is the procedure that will be discussed. It’s the simplest and most commonly used. An unloaded test is made on a battery without discharging current.
CORRECTIVE ACTION 1. Service battery. 2. Replace fuse. 3. Clean and check connections for good contact. 4. Contact authorized SNAPPER dealer. 5. Push blade engagement switch in to “OFF”. 6. Lift levers into neutral lock position. 7. Engage park brake.
SAFETY ALERT SYMBOL. OBSERVE AND FOLLOW ALL SAFETY INSTRUCTIONS. KEEP HANDS AND FEET AWAY FROM ROTATING BLADES UNDER DECK. BE AWARE OF THE PRESENCE OF CHILDREN WHEN OPERATING MOWER. DO NOT OPERATE ON SLOPES GREATER THAN 10°. (1) WARNING INSTRUCTIONS (FLOOR PAN) (2) WARNING (FLOOR PAN): Read, understand and follow instructions and warnings in operator’s manuals,...
(4) WARNING (LEFT SIDE OF MOWER DECK; ALSO DISCHARGE CHUTE): It advises operator of the danger of the rotating blade. (5) CUTTING HEIGHT ADJUSTMENT (FLOOR PAN): demonstrates operation Adjustment Handle. DECAL IDENTIFICATION WARNING DECAL 22841 (6) PARKING BRAKE ENGAGE (PARKING BRAKE): Indicates direction in which parking brake is engaged.
For two (2) years from purchase date for the original purchaser's residential, non-commercial use, SNAPPER, through any authorized SNAPPER dealer will replace, free of charge (except for taxes where applicable), any part or parts found upon examination by the factory at McDonough, Georgia, to be defective in material or workmanship or both.
Page 36
Read, Understand, and Follow all warnings and instructions in this manual, the engine manual, and on the machine, engine and attachments. If you have any questions about your Snapper product, contact your local authorized Snapper dealer or contact Snapper Customer Service at Snapper, McDonough, GA.
