3-In-1: Convert From Mulching To Bagging - Snapper ESPV21675 Quick Setup Instructions Manual

3-in-1: Convert from mulching to bagging...

1
For mulching:
• Leave the mulching cover and the installed
mulching plug in place (Figure 6).
2
To convert to bagging:
• Lift the rear door, and remove the installed
mulching plug (Figure 7).
• Holding the rear door open, attach the grass
catcher (Figure 8) to the rear of the mower.
• Make sure the hooks (A, Figure 9) on either
side of the catcher frame hook onto the rear
door rod (B).
• Release the rear door (it will lay on top of the
grass catcher).
6
Figure 6
Figure 7
Figure 8
B
Figure 9
www.snapper.com
A
