- Page 1 Parts Manual for 21" VARIABLE SPEED REAR DISCHARGE EUROPEAN MOWERS MODEL ESPV21675 (7800253) Briggs & Stratton Yard Power Products Group 535 Macon Road Manual No. 7006158 McDonough, GA, 30253 U.S.A. 800-935-2967 Revision IR, 7/1/2008 TP 400-5403-IR-WB-N...
-
Page 3: Table Of Contents
Table Of Contents PAGE GROUP Handles and Controls Front and Rear Wheels Deck Assembly Engine and Blade Assembly Transmission Decals 21" VARIABLE SPEED Manual No. 7006158 TP 400-5403-IR-WB-N... - Page 4 Manual No. 7006158 21" VARIABLE SPEED TP 400-5403-IR-WB-N...
-
Page 5: Handles And Controls
7101312 HANDLE, Plastic Upper, WBM 7101321BH BAIL, Plastic Handle, WBM 7101416 ASSY, Control Head, 21” WBM, RD, Snapper (includes cable & lever) 7090015 BOLT, 1/4-20 x 1-3/4” Round Head Square Neck, GR 2 7024649 WIRE TIE, 11 Inch Standard Black Nylon 7091508 BOLT, 5/16-18 x 3/4”... -
Page 6: Front And Rear Wheels
Front and Rear Wheels Manual No. 7006158 21" VARIABLE SPEED TP 400-5403-IR-WB-N... - Page 7 7100820 GEAR, Pinion 7014341 RETAINING RING Waldes #5133-50 or equiv. 7500540 ASSY, Wheel, 8 x 2 Idle, Snapper Tread, Charcoal Gray 7500647 ASSY, Wheel, 9” Snapper Tread w/Bearing Charcoal Gray incl 2 ball bearings, p/n 7101380 7100914 GEAR, External Wheel...
-
Page 8: Deck Assembly
Deck Assembly Manual No. 7006158 21" VARIABLE SPEED TP 400-5403-IR-WB-N... - Page 9 Deck Assembly Item Part No Description Note 7101490 CHUTE, 21” Side Discharge 7091020 PUSHNUT, 1/4” 7101471 ROD, Pivot, Mulch Cover 722507 SPRING, Torsion, Chute 722848 SCREW, 1/4-20 x 11/16” Pan Head Torx, Self-Tap 7101437 COVER, 21” Mulching 7300590D BRACKET, Chute Deflector 7091286 SCREW, #10-24 x 1/2”...
- Page 10 Deck Assembly Manual No. 7006158 21" VARIABLE SPEED TP 400-5403-IR-WB-N...
- Page 11 Deck Assembly Item Part No Description Note 7300585D BAFFLE, Front 21” WBM, RD 724970 LEVER, Spring Height-of-Cut 724887 GRIP, Height-of-Cut Footnotes: 21" VARIABLE SPEED Manual No. 7006158 TP 400-5403-IR-WB-N...
-
Page 12: Engine And Blade Assembly
Engine and Blade Assembly Manual No. 7006158 21" VARIABLE SPEED TP 400-5403-IR-WB-N... - Page 13 Engine and Blade Assembly Item Part No Description Note * ENGINE, B&S, 675 Series Euro Mod. 126T02-0180-B1 7090324 SCREW, 3/8-16 x 1” Hex Washer Self-Tap 7300725D BELT GUARD 7300724D COVER, Belt 7091200 SCREW, 1/4-20 x 1/2” Pan Head Self-Tap, Torx 7100437 PULLEY, Engine 7092086...
-
Page 14: Transmission
Transmission Manual No. 7006158 21" VARIABLE SPEED TP 400-5403-IR-WB-N... - Page 15 Section 3L, 32.86 effective length 1960251 NUT, 3/8-16 Hex Center Lock Jam, Black 7100240 PULLEY, Trans Var Speed, LC WBM 7101245 TRANSMISSION, 21” WBM, RD, Snapper 7900032 SCREW, 7mm x 1 x .550 AB Point Footnotes: 21" VARIABLE SPEED Manual No.
-
Page 16: Decals
Decals Manual No. 7006158 21" VARIABLE SPEED TP 400-5403-IR-WB-N... - Page 17 Decals Item Part No Description Note 7101540 DECAL, Front Cover, 21” RD, Snapper 7102153 DECAL, Briggs Engine, Snapper 7101536 DECAL, Control Head, VS, Snapper 7102381 DECAL, Engine, TP, 675 Snapper euro 7101084 DECAL, Warning, Euro, Multi-Panel Footnotes: 21" VARIABLE SPEED Manual No.
- Page 20 OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS Briggs & Stratton Yard Power Products Group 535 Macon Road McDonough, GA, 30253 U.S.A. 800-935-2967 Manual No. 7006158 www.snapper.com Revision IR, 7/1/2008 Copyright © 2008 Briggs & Stratton Corporation TP 400-5403-IR-WB-N Milwaukee, WI USA. All Rights Reserved...
