Parts Manual for
EUROPEAN ZERO TURN HYDRO DRIVE
18.5 HP 42"
150Z SERIES
MODEL
EZT18542150ZBVE (2690612)
McDonough, GA, 30253 U.S.A.
Briggs & Startton Yard Power Products Group
Manual No.
7006466
Copyright ©
2007
Briggs & Startton Corporation
Milwaukee, WI USA. All Rights Reserved
Revision 1,
10/15/2007
TP 400-5259-1-HZ-N
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Snapper EZT18542150ZBVE (2690612)
Summary of Contents for Snapper EZT18542150ZBVE (2690612)
- Page 1 Parts Manual for EUROPEAN ZERO TURN HYDRO DRIVE 18.5 HP 42" 150Z SERIES MODEL EZT18542150ZBVE (2690612) McDonough, GA, 30253 U.S.A. Briggs & Startton Yard Power Products Group Manual No. 7006466 Copyright © 2007 Briggs & Startton Corporation Milwaukee, WI USA. All Rights Reserved Revision 1, 10/15/2007 TP 400-5259-1-HZ-N...
-
Page 3: Table Of Contents
PAGE GROUP Frame, Body & Seat Group Engine Group Carrier & Transmission Group Controls Group Wheel & Tire Group Decals Group 42" Mower Deck - Clutch & Support Group 42" Mower Deck - Height Adjustment Group 42" Mower Deck - Housing & Arbor Group Electrical Group EUROPEAN ZERO TURN HYDRO DRIVE 150Z SERIES... - Page 4 Manual No. 7006466 EUROPEAN ZERO TURN HYDRO DRIVE TP 400-5259-1-HZ-N 150Z SERIES...
-
Page 5: Frame, Body & Seat Group
Frame, Body & Seat Group Item Part No Description 1726018 SEAT ASSEMBLY, with Arm Rests 1687021 ARM REST KIT, (L.H. & R.H.) 1727332A SUPPORT, Seat 1960694 NUT, Hex Flange ESNA, 1/4-20 1960738 CAPSCREW, Hex Head Whiz Lock Dog Point, 5/16-18 x 3/4 1726649 DECK, Seat 1960715... - Page 6 Frame, Body & Seat Group Manual No. 7006466 EUROPEAN ZERO TURN HYDRO DRIVE TP 400-5259-1-HZ-N 150Z SERIES...
- Page 7 Frame, Body & Seat Group Item Part No Description 1716066 ARM, Caster, R.H. 1664847 SCREW, Hex Washer Head Taptite, 5/16-18 x 3/4 1726024A BRACKET, Footrest Support 1960368 NUT, Speed Lug Type, 1/4-20 1930641 NUT, Hex Flange Whiz Lock, 1/4-20 1930644 NUT, Hex Flange Two-Way Lock, 1/2-13 1709235 SPACER...
-
Page 8: Engine Group
Engine Group Manual No. 7006466 EUROPEAN ZERO TURN HYDRO DRIVE TP 400-5259-1-HZ-N 150Z SERIES... - Page 9 Engine Group Item Part No Description * ENGINE, 18.5HP B&S Intek Model 31Q777-0113-B1 1732257A SHIELD, Heat Inner 1936228 CAPSCREW, Hex Socket Head, 5/16-18 x 3/4, G8 1917356 LOCKWASHER, Spring 5/16 1732259 PIPE, Exhaust B&S Intek 1731214 GASKET, Exhaust B&S 1960295 CAPSCREW, Hex Whiz Lock Flange, 1/4-20 x 5/8 1927557 NUT, Hex Flange Whiz Lock, 5/16-18 Large...
-
Page 10: Carrier & Transmission Group
Carrier & Transmission Group Manual No. 7006466 EUROPEAN ZERO TURN HYDRO DRIVE TP 400-5259-1-HZ-N 150Z SERIES... - Page 11 Carrier & Transmission Group Item Part No Description 1960687 NUT, Hex Flange ESNA, 3/8-16 1960684 NUT, Hex Keps, 5/16-18 1703900 SPACER 1960223 CARRIAGE BOLT, 5/16-18 x 1, G5 1727555 ROD, Control, L.H. 1919381 WASHER, 5/16 1728060 HYDRO SEAL KIT 1727831 BOLT, Shoulder, 7/16-14, G5 1727556 ROD, Control, R.H.
- Page 12 Carrier & Transmission Group Manual No. 7006466 EUROPEAN ZERO TURN HYDRO DRIVE TP 400-5259-1-HZ-N 150Z SERIES...
- Page 13 Carrier & Transmission Group Item Part No Description 1930644 NUT, Hex Flange, 1/2-13, Two-Way Lock 1924361 WASHER, 1/2 1727807 TRANSMISSION, Hydro Gear, R.H. 1732224 V-BELT 1924940 WASHER, 3/8 1960734 NUT, Hex Centerlock Jam, 7/16-14 1717024 CLIP, Rod End Clevis R.H. 1930633 NUT, Hex Head Center Lock 1728073...
-
Page 14: Controls Group
Controls Group Manual No. 7006466 EUROPEAN ZERO TURN HYDRO DRIVE TP 400-5259-1-HZ-N 150Z SERIES... - Page 15 Controls Group Item Part No Description 1725927 SHAFT, Cross 1960027 WASHER, 1/2 1703805 RING, Klipring Extension 1921977 CAPSCREW, Hex Head, 5/16-18 x 1-1/4, G5 1920161 NUT, Hex Jam, 5/16-18 1960717 NUT, Speed, 5/16-18 Lug Type 1960686 NUT, Hex Flange, 5/16-18 ESNA 1728009A BRACKET, L.H.
- Page 16 Controls Group Manual No. 7006466 EUROPEAN ZERO TURN HYDRO DRIVE TP 400-5259-1-HZ-N 150Z SERIES...
- Page 17 Controls Group Item Part No Description 1921319 WASHER, 1/4 1727669 ROD, Pivot 1733357 ROD, 1/4-20 x 2 1709314 SPRING, Extension 1727814A BRACKET, Duel Brake 1729277 SPRING, Compression 1960694 NUT, Hex Flange, 1/4-20 ESNA 1925003 SCREW, Hex Washer Head Taptite, 1/4-20 x 1/2 Footnotes: EUROPEAN ZERO TURN HYDRO DRIVE 150Z SERIES...
-
Page 18: Wheel & Tire Group
Wheel & Tire Group Manual No. 7006466 EUROPEAN ZERO TURN HYDRO DRIVE TP 400-5259-1-HZ-N 150Z SERIES... - Page 19 Wheel & Tire Group Item Part No Description 1722675 CAP, Hub, 1-1/2 ID Gray Poly 1.3 HI 2830647 NUT, Hex Lock Pal, 9/16-18 SAE 1050 2860183 WASHER, 3/4, .83 ID x 1.62 OD x .06 THK 1726383 WHEEL & TIRE ASSEMBLY, Rear 1611710 RING, Klipring for 3/4 DIA Shaft 2860202...
-
Page 20: Decals Group
Decals Group Manual No. 7006466 EUROPEAN ZERO TURN HYDRO DRIVE TP 400-5259-1-HZ-N 150Z SERIES... - Page 21 Decals Group Item Part No Description 1731955 DECAL, Snapper 1733541 DECAL, Snapper, 150Z 7073905 DECAL, Snapper Logo 7073905 DECAL, Snapper Logo 1733537 DECAL, Operating Instructions ZT Export 2007 1726638 DECAL, Tracking Adjustment ZT 7000 1722806 DECAL, Ignition Switch Symbols White/Black...
-
Page 22: 42" Mower Deck - Clutch & Support Group
42" Mower Deck - Clutch & Support Group Manual No. 7006466 EUROPEAN ZERO TURN HYDRO DRIVE TP 400-5259-1-HZ-N 150Z SERIES... - Page 23 42" Mower Deck - Clutch & Support Group Item Part No Description 1713578 ROD, 7-5/8 Long 2176012 RETAINER, Pin Spring 1728124A HITCH, Mower 1726012 ROD, ZTR 1960519 NUT, Push 1/2 Stud Capped 1919439 NUT, Hex Lock ESNA Light, 3/8-16 NC3B 1732225D HITCH, Mower Front 42”...
-
Page 24: 42" Mower Deck - Height Adjustment Group
42" Mower Deck - Height Adjustment Group Manual No. 7006466 EUROPEAN ZERO TURN HYDRO DRIVE TP 400-5259-1-HZ-N 150Z SERIES... - Page 25 42" Mower Deck - Height Adjustment Group Item Part No Description 2108765 BOLT, Wheel, 3/8-16 x 2-25/32 3/4 Thread 1960170 WASHER, 1/2 1714760 GAUGE WHEEL 1731403D BRACKET, Gauge Wheel LH Back 1960687 NUT, Hex Flange ESNA, 3/8-16 1732258D BRACKET, Gauge Wheel LH Front 1732244D BRACKET, Rear LH 42”...
- Page 26 42" Mower Deck - Height Adjustment Group Manual No. 7006466 EUROPEAN ZERO TURN HYDRO DRIVE TP 400-5259-1-HZ-N 150Z SERIES...
- Page 27 42" Mower Deck - Height Adjustment Group Item Part No Description 1714084 KNOB, Spinner 1960093 NUT, Push Pal, 3/8 1731402D SUPPORT, Gauge Wheel R.H. Front 1931352 CARRIAGE BOLT, 3/8-16 x 1-1/2, G5 1728109A ARM, Pitch 1930645 NUT, Hex FlangeTwo-Way Lock, 3/8-16 GA 1674440 SPACER 1922755...
-
Page 28: 42" Mower Deck - Housing & Arbor Group
42" Mower Deck - Housing & Arbor Group Manual No. 7006466 EUROPEAN ZERO TURN HYDRO DRIVE TP 400-5259-1-HZ-N 150Z SERIES... - Page 29 42" Mower Deck - Housing & Arbor Group Item Part No Description 1960576 NUT, Hex Lock ESNA Light. 5/8-18 1734064 PULLEY, 7” 7072440 SPACER, Pulley 7012491 RETAINING RING, External 1-3/4 2108202 BEARING, Ball 1731372Z TUBE & PLATE ASSEMBLY, Spindle 1704314 LUBE FITTING, 1/4 Drive w/Check Ball 7072537 SHAFT, Spindle...
-
Page 30: Electrical Group
Electrical Group Manual No. 7006466 EUROPEAN ZERO TURN HYDRO DRIVE TP 400-5259-1-HZ-N 150Z SERIES... - Page 31 Electrical Group Item Part No Description 1732006 SWITCH, Push Button 1686734 SWITCH ASSEMBLY, Ignition 1960547 LOCKWASHER, Internal Tooth, Ignition Switch 1717549 NUT, Hex Flange, 5/8-32, Ignition Switch 1717550 COVER, Ignition Switch 1717163 KEYS 1731185 METER, Hour Digital with Oil & Lube Alarms 1722611 PLUG, Hole 1722887...
- Page 34 Parts Manual for EUROPEAN ZERO TURN HYDRO DRIVE 18.5 HP 42" 150Z SERIES IT IS THE POLICY OF BRIGGS & STRATTON CORP TO IMPROVE ITS PRODUCTS WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS Briggs &...
