KI WorkZone Series Disassembly Instructions

Disassembly Instructions
Workzone® Basic Worksurfaces

Material Type:

A .Steel
C
All fasteners not explicitly
tagged or shown are
Material Type A: Steel
Required
Tools
Safety Glasses
KI · 1330 Bellevue Street · P.O. Box 8100 · Green Bay, WI 54308-8100 · 1-800-424-2432 · www.ki.com
B. Wood / Particle Board
C
B
C
A
Gloves
#2 Philips Screwdriver
C. Plastic
C
C
C
Pry Bar

Procedure:

1. Pry off the plastic covers from the sides of each leg and pull
out the plastic grommets from the worksurface.
2. Remove the screws holding the legs and modesty panel to the
worksurface and remove the worksurface.
3. Remove the screws holding the modesty panel to the legs and
remove the panel from the legs.
(continued on next page)

General Notes:

1. Disassembly time: 10-15 minutes
2. This procedure assumes basic familiarity with hand tools and
furniture terminology: no specialized training is required
3. All materials removed and disassembled shall be sorted and
segregated with like materials and disposed of or recycled
according to recycling availability or waste acceptance
4. For items to be recycled, refer to KI's End of Life Recycling
Matrix and KI's End of Life Recovery Options Matrix, available
at www.ki.com
Flat Screwdriver
©2013 Krueger International, Inc. All Rights Reserved · P0033-0082 Rev. 0 Page 1 of 2
