- Page 1 Assembly Instructions WorkZone Desking System ® November 2012...
- Page 2 WorkZone Basic Worksurface ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
- Page 3 WorkZone Basic Worksurface ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
- Page 4 #12 x 1 ” screws (Figure 1). Note: Starter/finisher modesty panels are longer than standard WorkZone modesty panels, and are shorter than adder modesty panels. 4. Set a starter/finisher modesty panel between the two installed Starter/Adder/Finisher Worksurface Assem legs over mounting holes in worksurface as illustrated.
- Page 5 WorkZone Starter/Adder/Finisher Worksurface ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
- Page 6 Note: Starter/finisher modesty adder worksurfaces following panels are longer than standard the steps above. WorkZone modesty panels, and #12 x screw are shorter than adder modesty panels. Figure 3 - Finisher Worksurface 9. Position a starter/finisher...
- Page 7 11.Carefullly turn the finisher worksurface assembly to the upright position and set the no-leg end of the WorkZone Starter/Adder/Finisher Worksurface ® adder surface onto the shared-leg Assembly Instructions bracket of the adder worksurface assembly (Figure 5). 12. Twist in four #12 x 1” screws through the shared-leg bracket of the Assemble units as described herein only.
- Page 8 WorkZone Starter/Adder/Finisher Worksurface ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
- Page 9 WorkZone Desks - 24”, 30” x 30” through 54” Tops with Power & Data ® Assembly Instructions WARNING: Assembly of all mechanical Assemble units as described herein only. To do otherwise frame components must be completed may result in instability. All screws, nuts and bolts must be before making any electrical connections.
- Page 10 (single cut-out) to the worksurface. Tighten all screws to explained in instructions 14 through 17. transitional WorkZone Desks - 24”, 30” x 30” through 54” Tops with Power & Data ® ecure the leg sets and modesty panel igure 1).
- Page 11 Failure to assemble properly, or to secure parts may result in assembly failure and personal injury. WorkZone with Power & Data - Assembly Instructions Note: All table connections must be securely fastened...
- Page 12 Note: The conduit and power source by a qualified connector assembly has been UL electrician who must also check Listed in KI’s UL file to meet the the electrical integrity of the liquidtight conduit requirements of UL 1286 finished system. These steps are (to power source) “Office Furnishings”.
- Page 13 WorkZone Desks - 24”, 30” x 60”, 66” & 72” Tops with Power & Data ® Assembly Instructions WARNING: Assembly of all mechanical Assemble units as described herein only. To do otherwise frame components must be completed may result in instability. All screws, nuts and bolts must be before making any electrical connections.
- Page 14 (two cut-outs) WorkZone Desks - 24”, 30” x 60”, 66” & 72” Tops with Power & Data ® oles that correspond with worksurface run of worksurfaces, the vertical wireway oles.
- Page 15 WorkZone Desks - 24”, 30” x 60”, 66” & 72” Tops with Power & Data ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly.
- Page 16 10-wire wireway UL Listed in KI’s UL file to meet power source by a qualified the requirements of UL 1286 electrician who must also “Office Furnishings”. The 90° check the electrical integrity...
- Page 17 Figure 1 in place of steps 14 #12 AWG minimum. through 17 of the rectangular Data - Assembly Instructions WorkZone with Power & Data C. Each branch circuit must be fused Assembly Instructions. 5. Make standard wire connections to the...
- Page 18 WorkZone Stand Alone Corner Worksurface with Keyboard Pad ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
- Page 19 WorkZone Stand Alone Corner Worksurface with Keyboard Pad ® Assembly Instructions Keyboard Pad Assemble units as described herein only. To do otherwise mbly right side up may result in instability. All screws, nuts and bolts must be into the two...
- Page 20 Transitional Worksurface - Keyboard Pad & Corner ® Assembly Instructions Assembly Instructions WorkZone Transitional Worksurface Keyboard Pad & Corner Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly.
- Page 21 WorkZone Transitional Worksurface - Keyboard Pad, Square & Rectangle & Corner ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly.
- Page 22 WorkZone - Corner Transitional & End-of-Run Corner Worksurface with Power & Data ® Assembly Instructions WARNING: Assembly of all mechanical Assemble units as described herein only. To do otherwise frame components must be completed may result in instability. All screws, nuts and bolts must be before making any electrical connections.
- Page 23 Tighten all oriented as shown. Secure the corner leg WorkZone - Corner Transitional and End-of-Run Corner Worksurface with Power & Data ® screws that secure the modesty panels to the worksurface with four #12 x 1”...
- Page 24 WorkZone - Corner Transitional and End-of-Run Corner Worksurface with Power & Data ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly.
- Page 25 WorkZone Desks - “810” 10-Wire Electrical System ® DataLink Training Table Syste ® ble System - "810" 10-Wire Electrical System Assembly Instructions Assembly Instructions Assemble units as described herein only. To do otherwise assemble units as described herein on ed herein only . To do otherwise may result in instability .
- Page 26 ® Assembly Instructions Assembly Instructions Assemble units as described herein only. To do otherwise WorkZone Transitional Worksurface may result in instability. All screws, nuts and bolts must be Square/Rectangular Surface tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
- Page 27 WorkZone Transitional Worksurface - Square/Rectangular Surface ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
-
Page 28: Side Mounting
Assembly Instructions assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury. WorkZone Peninsula Worksurface Side Mounting #12 x 1" screw #10 x ½" screw Tools Required •... - Page 29 WorkZone Peninsula Worksurface ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
- Page 30 ® Assembly Instructions Assembly Instructions Assemble units as described herein only. To do otherwise WorkZone Peninsula Worksurface may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after Center Mounting assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
- Page 31 Peninsula Worksurface - End Mounting ® Assembly Instructions Assembly Instructions WorkZone Peninsula Worksurface Assemble units as described herein only. To do otherwise End Mounting may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly.
-
Page 32: Peninsula Worksurface
Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after WorkZone Peninsula Worksurface assembly. Failure to assemble properly, or to secure parts 5. Position two splice plates to mounting may result in assembly failure and personal injury. - Page 33 Assembly Instructions WorkZone Conference End Worksurface WorkZone Conference End Worksurface ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly.
- Page 34 WorkZone Guest Modesty Panel ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
- Page 35 WorkZone Mobil Tables - Tear Drop & Semi Circle ® Assembly Instructions WorkZone Mobil Tables Tear Drop & Semi-Circle Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly.
- Page 36 1330 Bellevue Street P .O. Box 8100 Green Bay, Wisconsin 54308-8100 1-800-424-2432 www.ki.com Ki is a registered trademark of Krueger International, Inc. © 2012 KI All Rights Reserved Litho in USA. Code KI-60456R4/KI/GT/1112...
