Impedance Test

Specifications:
Input Impedance
Test Devices: Fluke 9500B or Digital Multimeter and BNC (male) to Dual-banana Plug Cable. In this
manual, the test device is Fluke 9500B.
Test Procedures:
1. Impedance test of CH1 and CH2
1) Connect the active head of Fluke 9500B to CH1 of the oscilloscope.
2) Configure the oscilloscope:
Press CH1 in the vertical control area (VERTICAL) at the front panel to enable CH1.
a)
Rotate VERTICAL
b)
3) Enable the Fluke 9500B and select the resistance measurement function, read and record
the resistance measurement value.
Rotate VERTICAL
4)
and record the resistance measurement value.
5) Turn CH1 off. Repeat the above test steps to test CH2 and record the test results.
2. Impedance test of [EXT TRIG] channel
1) Disconnect the connections of the two input channels.
2) Connect the active head of Fluke 9500B to the external trigger channel [EXT TRIG].
3) Enable the Fluke 9500B and select the resistance measurement function, read and record
the resistance measurement value.
Test Record Form:
Channel Vertical Scale
100 mV/div
CH1
500 mV/div
100 mV/div
CH2
500 mV/div
EXT TRIG
2-2
1 MΩ ±2% (0.98 MΩ to 1.02 MΩ)
SCALE to set the vertical scale of CH1 to 100 mV/div.
SCALE to adjust the vertical scale of CH1 to 500 mV/div; then, read
Test Result
--
Chapter 2 Performance Calibration Test
Limit
≥ 0.98 MΩ and ≤ 1.02 MΩ
