Download this manual See also: Instruction Manual
Modbus Manual
HASXEE-IM-MB
5/2017
Gas Analyzers
X-STREAM Enhanced Series
Modbus Manual
www.EmersonProcess.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Rosemount X-Stream Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Emerson Rosemount X-Stream Series

Summary of Contents for Emerson Rosemount X-Stream Series

  • Page 1 Modbus Manual HASXEE-IM-MB 5/2017 Gas Analyzers X-STREAM Enhanced Series Modbus Manual www.EmersonProcess.com...

  • Page 2: Table Of Contents

    1.5 List of Parameters and Registers - Sorted by Tag Name ...........1-6 1.6 List of Parameters and Registers - Sorted by Daniel Registers ......1-47 1.7 List of Bitfield States ....................1-86 edition, 5/2017 Emerson Process Management GmbH & Co. OHG Rosemount Analytical Process Gas Analyzer Center of Excellence Industriestrasse 1...

  • Page 3: Chapter 1 Modbus Functions

    Before using Modbus TCP/IP take care to to a DHCP server via ethernet, it will receive configure the communication properly: a valid IP address and become visible in the Instruction Manual HASXEE-IM-HS network. 6-94. If no DHCP server is available, configure the For Modbus TCP/IP the analyzer is factory IP address manually Instruction Manual configured to support DHCP servers: The mo- HASXEE-IM-HS 6-94. Emerson Process Management GmbH & Co. OHG...

  • Page 4: Supported Functions

    To calculate the related Modicon registers use the following table: Daniel Modicon Data type 8001 - 8499 equals 5001 - 5999 long word 9001 - 9999 equals 6001 - 7999 floating point 10001 - 10999 equals 16001 - 17999 floating point the following pages for comparisons of all Daniel and Modicon registers. Emerson Process Management GmbH & Co. OHG...

  • Page 5: Adressing

    32-bit register: ranges for those 32-Bit register types. • FLOAT: Single precision floating point • Modicon: Applies to the transmission according IEEE-754 modes 16BitLow and 16BitHigh. • DWORD: Unsigned 32 bit value or 32-bit • Daniel: Applies to the 32Bit transmission bitfield mode • LONG: Singed 32-bit value Emerson Process Management GmbH & Co. OHG...

  • Page 6: List Of Parameters And Registers - Sorted By Tag Name

    2077 2077 Boolean R/W comp5 0=open sample valve; 1=open span2 valve Control.ApplyGas.Span2Valve1 2062 2062 Boolean R/W comp1 0=open sample valve; 1=open span2 valve Control.ApplyGas.Span2Valve2 2066 2066 Boolean R/W comp2 0=open sample valve; 1=open span2 valve Control.ApplyGas.Span2Valve3 2070 2070 Boolean R/W comp3 0=open sample valve; 1=open span2 valve Control.ApplyGas.Span2Valve4 2074 2074 Boolean R/W comp4 Emerson Process Management GmbH & Co. OHG...
  • Page 7 Boolean R/W Span calibration comp5 (1=start) Control.Calibration.Span_All 2022 2022 Boolean R/W Span calibration all (1=start) Control.Calibration.Zero_1 2001 2001 Boolean R/W Zero calibration comp1 (1=start) Control.Calibration.Zero_2 2002 2002 Boolean R/W Zero calibration comp2 (1=start) Emerson Process Management GmbH & Co. OHG...
  • Page 8 Info.InterfaceID 4033 4033 Word 17=ETH1 18=ETH2) 4011… 4011… Info.ProgramVersion String software release version 4016 4016 Info.SensorVersion 4026 4026 Word Version number of sensor firmware 3141… 3141… Info.SerialNumber String serial number of the device 3147 3147 16141… Last valid Primary Variable 1 (Concentration PV_LV1 10071 Float 16142 in ppm) Emerson Process Management GmbH & Co. OHG...
  • Page 9 3141… 3141… Service.General.Identification.SerialNumber String serial number of the device 3147 3147 Service.General.ResetDevice 2100 2100 Boolean R/W Reset the device Service.IO.InputSimEnable1 3180 3180 Word Enable Inputs Simulation of XDIO Card #1 Service.IO.InputSimEnable2 3200 3200 Word Enable Inputs Simulation of XDIO Card #2 Service.IO.InputSimVal1 3235 3235 Word Simulation Input state of a XDIO Card #1 Service.IO.InputSimVal2 3250 3250 Word Simulation Input state of a XDIO Card #2 Emerson Process Management GmbH & Co. OHG...
  • Page 10 (0=Man 3427 3427 Word rAssign2 1=DSP_P1 2=DSP_P2 etc.) Service.Measurement.Compensation.PfactSenso- assign press-sensor of span comp3 (0=Man 3428 3428 Word rAssign3 1=DSP_P1 2=DSP_P2 etc.) Service.Measurement.Compensation.PfactSenso- assign press-sensor of span comp4 (0=Man 3429 3429 Word rAssign4 1=DSP_P1 2=DSP_P2 etc.) 1-10 Emerson Process Management GmbH & Co. OHG...
  • Page 11 9266 Float rature1 6532 comp1 Service.Measurement.Compensation.TfactTempe- 6533… temperature for span compensation of 9267 Float rature2 6534 comp2 Service.Measurement.Compensation.TfactTempe- 6535… temperature for span compensation of 9268 Float rature3 6536 comp3 Emerson Process Management GmbH & Co. OHG 1-11...
  • Page 12 Service.Measurement.Compensation.ToffTempe- 6529… temperature for zero compensation of 9265 Float rature5 6530 comp5 3571… 3571… LinCalc results (P1..P4) comp1 (0=NoCoeff Service.Measurement.Lin.CalcResults1 Word 3574 3574 1=Good 2=Busy ..) 3575… 3575… LinCalc results (P1..P4) comp2 (0=NoCoeff Service.Measurement.Lin.CalcResults2 Word 3578 3578 1=Good 2=Busy ..) 1-12 Emerson Process Management GmbH & Co. OHG...
  • Page 13 3570 Service.Measurement.Lin.Iterations1 3521 3521 Word Lin-computing iteration steps of comp1) Service.Measurement.Lin.Iterations2 3522 3522 Word Lin-computing iteration steps of comp1) Service.Measurement.Lin.Iterations3 3523 3523 Word Lin-computing iteration steps of comp1) Service.Measurement.Lin.Iterations4 3524 3524 Word Lin-computing iteration steps of comp1) Service.Measurement.Lin.Iterations5 3525 3525 Word Lin-computing iteration steps of comp1) Lin. status comp1 (0=Normal 1=Underflow Service.Measurement.Lin.LinearizerStatus1 3516 3516 Word 2=Overflow 3=Undefined) Emerson Process Management GmbH & Co. OHG 1-13...
  • Page 14 Float Lin-Overflow [%] for Range1..4 of comp1 7168 9584 7361… 9681… Service.Measurement.Lin.OverflowPerc2 Float Lin-Overflow [%] for Range1..4 of comp2 7368 9684 7561… 9781… Service.Measurement.Lin.OverflowPerc3 Float Lin-Overflow [%] for Range1..4 of comp3 7568 9784 7761… 9881… Service.Measurement.Lin.OverflowPerc4 Float Lin-Overflow [%] for Range1..4 of comp4 7768 9884 7961… 9981… Service.Measurement.Lin.OverflowPerc5 Float Lin-Overflow [%] for Range1..4 of comp5 7968 9984 1-14 Emerson Process Management GmbH & Co. OHG...
  • Page 15 Float Lin-Polynom. Set2-Coeffs (A0..4) for comp5 7940 9970 7141… 9571… Service.Measurement.Lin.Set3Coeffs1 Float Lin-Polynom. Set3-Coeffs (A0..4) for comp1 7150 9575 7341… 9671… Service.Measurement.Lin.Set3Coeffs2 Float Lin-Polynom. Set3-Coeffs (A0..4) for comp2 7350 9675 7541… 9771… Service.Measurement.Lin.Set3Coeffs3 Float Lin-Polynom. Set3-Coeffs (A0..4) for comp3 7550 9775 7741… 9871… Service.Measurement.Lin.Set3Coeffs4 Float Lin-Polynom. Set3-Coeffs (A0..4) for comp4 7750 9875 Emerson Process Management GmbH & Co. OHG 1-15...
  • Page 16 Float Linearization table Y-Values of comp4 7666 9833 7861… 9931… Service.Measurement.Lin.TableYValues5 Float Linearization table Y-Values of comp5 7866 9933 7169… 9585… Service.Measurement.Lin.UnderflowPerc1 Float Lin-Underflow [%] for Range1..4 of comp1 7176 9588 7369… 9685… Service.Measurement.Lin.UnderflowPerc2 Float Lin-Underflow [%] for Range1..4 of comp2 7376 9688 7569… 9785… Service.Measurement.Lin.UnderflowPerc3 Float Lin-Underflow [%] for Range1..4 of comp3 7576 9788 1-16 Emerson Process Management GmbH & Co. OHG...
  • Page 17 Float values for XSP's multiplexer value1..8 6356 9178 5311… 8156… Service.Status.DeviceStates.ChStateForce1 DWord Forcing for comp1's state bitfield (b0:..) 5320 8160 5321… 8161… Service.Status.DeviceStates.ChStateForce2 DWord Forcing for comp2's state bitfield (b0:..) 5330 8165 5331… 8166… Service.Status.DeviceStates.ChStateForce3 DWord Forcing for comp3's state bitfield (b0:..) 5340 8170 5341… 8171… Service.Status.DeviceStates.ChStateForce4 DWord Forcing for comp4's state bitfield (b0:..) 5350 8175 Emerson Process Management GmbH & Co. OHG 1-17...
  • Page 18 6120 6101… Setup.Calibration.CurrentZerogas1 9051 Float current zero gas of comp1 6102 6103… Setup.Calibration.CurrentZerogas2 9052 Float current zero gas of comp2 6104 6105… Setup.Calibration.CurrentZerogas3 9053 Float current zero gas of comp3 6106 1-18 Emerson Process Management GmbH & Co. OHG...
  • Page 19 Setup.Calibration.Range2Zerogas5 9128 Float zero gas of range2 of comp5 6256 6265… Setup.Calibration.Range3Spangas1 9133 Float span gas of range3 of comp1 6266 6273… Setup.Calibration.Range3Spangas2 9137 Float span gas of range3 of comp2 6274 Emerson Process Management GmbH & Co. OHG 1-19...
  • Page 20 2047 2047 Boolean R/W set) Reset span cal deviations of comp3 (1=re- Setup.Calibration.SpanCalDeviatReset3 2048 2048 Boolean R/W set) Reset span cal deviations of comp4 (1=re- Setup.Calibration.SpanCalDeviatReset4 2049 2049 Boolean R/W set) Reset span cal deviations of comp5 (1=re- Setup.Calibration.SpanCalDeviatReset5 2050 2050 Boolean R/W set) 16011… Setup.Calibration.SpanCalTolerance1 10006 Float span cal tolerance in % of comp1 16012 1-20 Emerson Process Management GmbH & Co. OHG...
  • Page 21 (0=Instant, 1=Sta- Setup.Calibration.ZeroMethod3 3303 3303 Word bility) zero cal method comp4 (0=Instant, 1=Sta- Setup.Calibration.ZeroMethod4 3304 3304 Word bility) zero cal method comp5 (0=Instant, 1=Sta- Setup.Calibration.ZeroMethod5 3305 3305 Word bility) Emerson Process Management GmbH & Co. OHG 1-21...
  • Page 22 Setup.Display.Component.PV_UnitOffset4 9158 Float 6316 unit4 6319… offset to convert ppm into displayed custom Setup.Display.Component.PV_UnitOffset5 9160 Float 6320 unit5 3012… 3012… Setup.Display.Component.PV_UnitString1 String unit displayed for comp1 3015 3015 3017… 3017… Setup.Display.Component.PV_UnitString2 String unit displayed for comp2 3020 3020 1-22 Emerson Process Management GmbH & Co. OHG...
  • Page 23 3137… 3137… Setup.Display.MeasDisplay.Dis2Label5 String displayed label of measure display 2, Line 5 3140 3140 Setup.Display.MeasDisplay.Dis2Line1 3096 3096 Word assigned signal of measure display 2, Line 1 Setup.Display.MeasDisplay.Dis2Line2 3097 3097 Word assigned signal of measure display 2, Line 2 Setup.Display.MeasDisplay.Dis2Line3 3098 3098 Word assigned signal of measure display 2, Line 3 Setup.Display.MeasDisplay.Dis2Line4 3099 3099 Word assigned signal of measure display 2, Line 4 Setup.Display.MeasDisplay.Dis2Line5 3100 3100 Word assigned signal of measure display 2, Line 5 Emerson Process Management GmbH & Co. OHG 1-23...
  • Page 24 3300 3300 Word fig) 6363… level where analoge output scaling ends on Setup.In/Outputs.AO.EndRange1 9182 Float 6364 output1 6371… level where analoge output scaling ends on Setup.In/Outputs.AO.EndRange2 9186 Float 6372 output2 6379… level where analoge output scaling ends on Setup.In/Outputs.AO.EndRange3 9190 Float 6380 output3 6387… level where analoge output scaling ends on Setup.In/Outputs.AO.EndRange4 9194 Float 6388 output4 1-24 Emerson Process Management GmbH & Co. OHG...
  • Page 25 (0=0..20mA 1=4-20mA) Setup.In/Outputs.AO.OutRange3 3282 3282 Word range of output3 (0=0..20mA 1=4-20mA) Setup.In/Outputs.AO.OutRange4 3287 3287 Word range of output4 (0=0..20mA 1=4-20mA) Setup.In/Outputs.AO.OutRange5 3292 3292 Word range of output5 (0=0..20mA 1=4-20mA) Emerson Process Management GmbH & Co. OHG 1-25...
  • Page 26 Word signal of DigInp5 / XDIO1 Inp5 Setup.In/Outputs.DI.Signal_DI6 3233 3233 Word signal of DigInp6 / XDIO1 Inp6 Setup.In/Outputs.DI.Signal_DI7 3234 3234 Word signal of DigInp7 / XDIO1 Inp7 Setup.In/Outputs.DI.Signal_DI8 3243 3243 Word signal of DigInp8 / XDIO2 Inp1 Setup.In/Outputs.DI.Signal_DI9 3244 3244 Word signal of DigInp9 / XDIO2 Inp2 Setup.In/Outputs.DO.Node_DO1 3151 3151 Word node of DigOut1 / XPSA Setup.In/Outputs.DO.Node_DO10 3166 3166 Word node of DigOut10 / XDIO1 Out6 1-26 Emerson Process Management GmbH & Co. OHG...
  • Page 27 Setup.In/Outputs.SHS.Node_Gas1 3201 3201 Word node of SHS GasOut1 Setup.In/Outputs.SHS.Node_Gas2 3202 3202 Word node of SHS GasOut2 Setup.In/Outputs.SHS.Node_Gas3 3203 3203 Word node of SHS GasOut3 Setup.In/Outputs.SHS.Node_Gas4 3204 3204 Word node of SHS GasOut4 Emerson Process Management GmbH & Co. OHG 1-27...
  • Page 28 6208 6147… Setup.Measurement.EndOfRange2_1 9074 Float end of range2 of comp1 6148 6163… Setup.Measurement.EndOfRange2_2 9082 Float end of range2 of comp2 6164 6179… Setup.Measurement.EndOfRange2_3 9090 Float end of range2 of comp3 6180 1-28 Emerson Process Management GmbH & Co. OHG...
  • Page 29 Manual Pressure of comp5 [Pa] 6130 Ranges available bitfield of Comp1 Setup.Measurement.RangeAvailable1 3441 3441 Word (b0=R1,b1=R2,b2=R3,b3=R4) Ranges available bitfield of Comp2 Setup.Measurement.RangeAvailable2 3442 3442 Word (b0=R1,b1=R2,b2=R3,b3=R4) Ranges available bitfield of Comp3 Setup.Measurement.RangeAvailable3 3443 3443 Word (b0=R1,b1=R2,b2=R3,b3=R4) Ranges available bitfield of Comp4 Setup.Measurement.RangeAvailable4 3444 3444 Word (b0=R1,b1=R2,b2=R3,b3=R4) Ranges available bitfield of Comp5 Setup.Measurement.RangeAvailable5 3445 3445 Word (b0=R1,b1=R2,b2=R3,b3=R4) Emerson Process Management GmbH & Co. OHG 1-29...
  • Page 30 6146 6161… Setup.Measurement.StartOfRange2_2 9081 Float start of range2 of comp2 6162 6177… Setup.Measurement.StartOfRange2_3 9089 Float start of range2 of comp3 6178 6193… Setup.Measurement.StartOfRange2_4 9097 Float start of range2 of comp4 6194 1-30 Emerson Process Management GmbH & Co. OHG...
  • Page 31 Compute cross interference factor comp4 Setup.Measurement.XIntf.ComputeFactor4 3479 3479 Word (0=Src1, 1=Src2 etc.) Compute cross interference factor comp5 Setup.Measurement.XIntf.ComputeFactor5 3480 3480 Word (0=Src1, 1=Src2 etc.) Enable cross interference compensation for Setup.Measurement.XIntf.Enable1 3471 3471 Word comp1 Emerson Process Management GmbH & Co. OHG 1-31...
  • Page 32 Cross interfere linearization references1..4 Setup.Measurement.XIntf.LinearReferences5 Float 6864 9432 for comp5 4051… 4051… Cross interfere signal value states1..4 for Setup.Measurement.XIntf.SignalStates1 Word 4054 4054 comp1 4055… 4055… Cross interfere signal value states1..4 for Setup.Measurement.XIntf.SignalStates2 Word 4058 4058 comp2 4059… 4059… Cross interfere signal value states1..4 for Setup.Measurement.XIntf.SignalStates3 Word 4062 4062 comp3 1-32 Emerson Process Management GmbH & Co. OHG...
  • Page 33 2146 Boolean R/W (1=reset) Reset span validation deviations of comp2 Setup.Validation.SpanValidDeviatReset2 2147 2147 Boolean R/W (1=reset) Reset span validation deviations of comp3 Setup.Validation.SpanValidDeviatReset3 2148 2148 Boolean R/W (1=reset) Reset span validation deviations of comp4 Setup.Validation.SpanValidDeviatReset4 2149 2149 Boolean R/W (1=reset) Reset span validation deviations of comp5 Setup.Validation.SpanValidDeviatReset5 2150 2150 Boolean R/W (1=reset) Emerson Process Management GmbH & Co. OHG 1-33...
  • Page 34 16106 16107… Status.Average4 10054 Float average of comp4 16108 16109… Status.Average5 10055 Float average of comp5 16110 6091… Status.CalcResultA 9046 Float Result of calculator A 6092 6093… Status.CalcResultB 9047 Float Result of calculator B 6094 1-34 Emerson Process Management GmbH & Co. OHG...
  • Page 35 Float range1..4 span cal deviation of comp1 16248 10124 16249… 10125… Status.Calibration.SpanCalDeviatRanges2 Float range1..4 span cal deviation of comp2 16256 10128 16257… 10129… Status.Calibration.SpanCalDeviatRanges3 Float range1..4 span cal deviation of comp3 16264 10132 16265… 10133… Status.Calibration.SpanCalDeviatRanges4 Float range1..4 span cal deviation of comp4 16272 10136 16273… 10137… Status.Calibration.SpanCalDeviatRanges5 Float range1..4 span cal deviation of comp5 16280 10140 Emerson Process Management GmbH & Co. OHG 1-35...
  • Page 36 16047… current range zero cal deviation sum of Status.Calibration.ZeroCalDeviationSum4 10024 Float 16048 comp4 16049… current range zero cal deviation sum of Status.Calibration.ZeroCalDeviationSum5 10025 Float 16050 comp5 5405… curr. range zero cal deviation epoch time Status.Calibration.ZeroCalDeviationTime1 8203 DWord 5406 stamp of comp1 5413… curr. range zero cal deviation epoch time Status.Calibration.ZeroCalDeviationTime2 8207 DWord 5414 stamp of comp2 1-36 Emerson Process Management GmbH & Co. OHG...
  • Page 37 Boolean RO Any calibration in progress Status.DeviceStates.AnyValid 1002 1002 Boolean RO Any validation in progress 5191… 8096… Status.DeviceStates.ChannelState1 DWord component1's state bitfield (b0:..) 5200 8100 5201… 8101… Status.DeviceStates.ChannelState2 DWord component2's state bitfield (b0:..) 5210 8105 5211… 8106… Status.DeviceStates.ChannelState3 DWord component3's state bitfield (b0:..) 5220 8110 Emerson Process Management GmbH & Co. OHG 1-37...
  • Page 38 6950 6963… Status.Diagnostics.BeforeLinConce5 9482 Float before linear. conc comp5 6964 6341… Status.Diagnostics.DSPMuxValue1 9171 Float DSP multiplexer value 1 6342 6343… Status.Diagnostics.DSPMuxValue2 9172 Float DSP multiplexer value 2 6344 6345… Status.Diagnostics.DSPMuxValue3 9173 Float DSP multiplexer value 3 6346 1-38 Emerson Process Management GmbH & Co. OHG...
  • Page 39 6032 6035… Status.Diagnostics.RawRefConce4 9018 Float raw ADC of reference side component4 6036 6039… Status.Diagnostics.RawRefConce5 9020 Float raw ADC of reference side component5 6040 6913… Status.Diagnostics.SpanCorrPress1 9457 Float Pressure span corr component1 6914 6927… Status.Diagnostics.SpanCorrPress2 9464 Float Pressure span corr component2 6928 Emerson Process Management GmbH & Co. OHG 1-39...
  • Page 40 Status.Diagnostics.ZeroCorrTemp5 9480 Float temp zero corr component5 6960 6071… Status.Flow1 9036 Float flow of comp1 6072 6073… Status.Flow2 9037 Float flow of comp2 6074 6075… Status.Flow3 9038 Float flow of comp3 6076 6077… Status.Flow4 9039 Float flow of comp4 6078 1-40 Emerson Process Management GmbH & Co. OHG...
  • Page 41 8033 DWord 5066 related 5073… NamurFailure alarms that are component4 Status.NamurStates.FailAlarmComp4 8037 DWord 5074 related 5081… NamurFailure alarms that are component5 Status.NamurStates.FailAlarmComp5 8041 DWord 5082 related 5041… Status.NamurStates.FailAlarmDev 8021 DWord NamurFailure alarms that are device related 5042 Emerson Process Management GmbH & Co. OHG 1-41...
  • Page 42 Status.NamurStates.MaintRequAlarmDev 8023 DWord 5046 related NAMUR sum state bit-field (b0:F b1:M b2:S Status.NamurStates.NamurAlarm 4001 4001 Word b3:C) comp1's NAMUR state bit-field (b0:F b1:M Status.NamurStates.NamurAlarmCh1 4003 4003 Word b2:S b3:C) comp2's NAMUR state bit-field (b0:F b1:M Status.NamurStates.NamurAlarmCh2 4004 4004 Word b2:S b3:C) comp3's NAMUR state bit-field (b0:F b1:M Status.NamurStates.NamurAlarmCh3 4005 4005 Word b2:S b3:C) 1-42 Emerson Process Management GmbH & Co. OHG...
  • Page 43 Boolean RO Result3 of PLC Status.PLC.PLCResult4 1014 1014 Boolean RO Result4 of PLC Status.PLC.PLCResult5 1015 1015 Boolean RO Result5 of PLC Status.PLC.PLCResult6 1016 1016 Boolean RO Result6 of PLC Status.PLC.PLCResult7 1017 1017 Boolean RO Result7 of PLC Status.PLC.PLCResult8 1018 1018 Boolean RO Result8 of PLC Emerson Process Management GmbH & Co. OHG 1-43...
  • Page 44 16094 comp2 16095… current range span validation deviation of Status.Validation.SpanValidDeviation3 10048 Float 16096 comp3 16097… current range span validation deviation of Status.Validation.SpanValidDeviation4 10049 Float 16098 comp4 16099… current range span validation deviation of Status.Validation.SpanValidDeviation5 10050 Float 16100 comp5 5403… curr. range span valid deviation epoch time Status.Validation.SpanValidDeviationTime1 8202 DWord 5404 stamp of comp1 1-44 Emerson Process Management GmbH & Co. OHG...
  • Page 45 Status.Validation.ZeroValidDeviation5 10045 Float 16090 comp5 5401… curr. range zero valid deviation epoch time Status.Validation.ZeroValidDeviationTime1 8201 DWord 5402 stamp of comp1 5409… curr. range zero valid deviation epoch time Status.Validation.ZeroValidDeviationTime2 8205 DWord 5410 stamp of comp2 5417… curr. range zero valid deviation epoch time Status.Validation.ZeroValidDeviationTime3 8209 DWord 5418 stamp of comp3 Emerson Process Management GmbH & Co. OHG 1-45...
  • Page 46 5457… 8229… range1..4 zero valid deviation epoch time Status.Validation.ZeroValidDeviatTimeRanges3 DWord 5464 8232 stamp of comp3 5465… 8233… range1..4 zero valid deviation epoch time Status.Validation.ZeroValidDeviatTimeRanges4 DWord 5472 8236 stamp of comp4 5473… 8237… range1..4 zero valid deviation epoch time Status.Validation.ZeroValidDeviatTimeRanges5 DWord 5480 8240 stamp of comp5 1-46 Emerson Process Management GmbH & Co. OHG...

  • Page 47: List Of Parameters And Registers - Sorted By Daniel Registers

    Boolean R/W Blowback procedure comp5 (1=start) 2021 2021 Control.Calibration.Zero_All Boolean R/W Zero calibration all (1=start) 2022 2022 Control.Calibration.Span_All Boolean R/W Span calibration all (1=start) 2023 2023 Control.Calibration.ZeroSpan_All Boolean R/W Zero+span calibration all (1=start) Emerson Process Management GmbH & Co. OHG 1-47...
  • Page 48 Boolean R/W 0=open sample valve; 1=open span3 valve comp5 2080 2080 Control.ApplyGas.Span4Valve5 Boolean R/W 0=open sample valve; 1=open span4 valve comp5 2081 2081 Control.ApplyGas.PumpState1 Boolean R/W Pump1 state (0=Off 1=On) 2082 2082 Control.ApplyGas.PumpState2 Boolean R/W Pump1 state (0=Off 1=On) 2091 2091 Control.Acknowledge.AllStates Boolean R/W 1=Acknowledge device's states; 0=no effect 1-48 Emerson Process Management GmbH & Co. OHG...

  • Page 49: Control.acknowledge.fctchecks 2095

    2137 Setup.Measurement.PeakReset2 Boolean R/W Reset capturing peaks of comp2 (1=reset) 2138 2138 Setup.Measurement.PeakReset3 Boolean R/W Reset capturing peaks of comp3 (1=reset) 2139 2139 Setup.Measurement.PeakReset4 Boolean R/W Reset capturing peaks of comp4 (1=reset) Emerson Process Management GmbH & Co. OHG 1-49...
  • Page 50 3040 3040 Setup.Display.Component.Precision5 Word decimal points displayed for component4 3041… 3041… Setup.Display.Component.Tag1 String displayed tag for component1 3045 3045 3046… 3046… Setup.Display.Component.Tag2 String displayed tag for component2 3050 3050 1-50 Emerson Process Management GmbH & Co. OHG...
  • Page 51 Setup.Display.MeasDisplay.Dis2Label2 String displayed label of measure display 2, Line 2 3128 3128 3129… 3129… Setup.Display.MeasDisplay.Dis2Label3 String displayed label of measure display 2, Line 3 3132 3132 3133… 3133… Setup.Display.MeasDisplay.Dis2Label4 String displayed label of measure display 2, Line 4 3136 3136 3137… 3137… Setup.Display.MeasDisplay.Dis2Label5 String displayed label of measure display 2, Line 5 3140 3140 3141… 3141… Info.SerialNumber String serial number of the device 3147 3147 Emerson Process Management GmbH & Co. OHG 1-51...
  • Page 52 Word signal of DigOut15 / XDIO2 Out2 3193 3193 Setup.In/Outputs.DO.Signal_DO16 Word signal of DigOut16 / XDIO2 Out3 3194 3194 Setup.In/Outputs.DO.Signal_DO17 Word signal of DigOut17 / XDIO2 Out4 3195 3195 Setup.In/Outputs.DO.Signal_DO18 Word signal of DigOut18 / XDIO2 Out5 3196 3196 Setup.In/Outputs.DO.Signal_DO19 Word signal of DigOut19 / XDIO2 Out6 3197 3197 Setup.In/Outputs.DO.Signal_DO20 Word signal of DigOut20 / XDIO2 Out7 3198 3198 Setup.In/Outputs.DO.Signal_DO21 Word signal of DigOut21 / XDIO2 Out8 1-52 Emerson Process Management GmbH & Co. OHG...
  • Page 53 Word node of DigInp10 / XDIO2 Inp3 3239 3239 Setup.In/Outputs.DI.Node_DI11 Word node of DigInp11 / XDIO2 Inp4 3240 3240 Setup.In/Outputs.DI.Node_DI12 Word node of DigInp12 / XDIO2 Inp5 3241 3241 Setup.In/Outputs.DI.Node_DI13 Word node of DigInp13 / XDIO2 Inp6 3242 3242 Setup.In/Outputs.DI.Node_DI14 Word node of DigInp14 / XDIO2 Inp7 3243 3243 Setup.In/Outputs.DI.Signal_DI8 Word signal of DigInp8 / XDIO2 Inp1 3244 3244 Setup.In/Outputs.DI.Signal_DI9 Word signal of DigInp9 / XDIO2 Inp2 Emerson Process Management GmbH & Co. OHG 1-53...
  • Page 54 Word Cut mode on output5 (0=Standard 1=Config) 3301 3301 Setup.Calibration.ZeroMethod1 Word zero cal method comp1 (0=Instant, 1=Stability) 3302 3302 Setup.Calibration.ZeroMethod2 Word zero cal method comp2 (0=Instant, 1=Stability) 3303 3303 Setup.Calibration.ZeroMethod3 Word zero cal method comp3 (0=Instant, 1=Stability) 1-54 Emerson Process Management GmbH & Co. OHG...
  • Page 55 Word ToffSensorAssign4 2=DSP_T2 etc. Service.Measurement.Compensation. assign temp-sensor of zero comp5 (0=None 1=DSP_T1 3410 3410 Word ToffSensorAssign5 2=DSP_T2 etc. Service.Measurement.Compensation. 3411 3411 Word enable temperature span compensation of comp1 TfactEnable1 Service.Measurement.Compensation. 3412 3412 Word enable temperature span compensation of comp2 TfactEnable2 Emerson Process Management GmbH & Co. OHG 1-55...
  • Page 56 Setup.Measurement.ZeroRangesMe- Method to zero cal/val the ranges of comp3 (0=separa- 3433 3433 Word thod3 tely, 1=toge Setup.Measurement.ZeroRangesMe- Method to zero cal/val the ranges of comp4 (0=separa- 3434 3434 Word thod4 tely, 1=toge Setup.Measurement.ZeroRangesMe- Method to zero cal/val the ranges of comp5 (0=separa- 3435 3435 Word thod5 tely, 1=toge Setup.Measurement.SpanRangesMe- Method to span cal/val the ranges of comp1 (0=separa- 3436 3436 Word thod1 tely, 1=toge 1-56 Emerson Process Management GmbH & Co. OHG...
  • Page 57 3468 SPMuxEnable1 3471 3471 Setup.Measurement.XIntf.Enable1 Word Enable cross interference compensation for comp1 3472 3472 Setup.Measurement.XIntf.Enable2 Word Enable cross interference compensation for comp2 3473 3473 Setup.Measurement.XIntf.Enable3 Word Enable cross interference compensation for comp3 Emerson Process Management GmbH & Co. OHG 1-57...
  • Page 58 5=Install 6=ToFile Service.Measurement.Lin.StartFunc- LinFct c5: 1=On/Off 2=Calc 3=ToUSB 4=FromUSB 3515 3515 Word tion5 5=Install 6=ToFile Service.Measurement.Lin.Linearizer- Lin. status comp1 (0=Normal 1=Underflow 2=Overflow 3516 3516 Word Status1 3=Undefined) Service.Measurement.Lin.Linearizer- Lin. status comp2 (0=Normal 1=Underflow 2=Overflow 3517 3517 Word Status2 3=Undefined) Service.Measurement.Lin.Linearizer- Lin. status comp3 (0=Normal 1=Underflow 2=Overflow 3518 3518 Word Status3 3=Undefined) 1-58 Emerson Process Management GmbH & Co. OHG...
  • Page 59 LinCalc results (P1..P4) comp4 (0=NoCoeff 1=Good Service.Measurement.Lin.CalcResults4 Word 3586 3586 2=Busy ..) 3587… 3587… LinCalc results (P1..P4) comp5 (0=NoCoeff 1=Good Service.Measurement.Lin.CalcResults5 Word 3590 3590 2=Busy ..) 4001 4001 Status.NamurStates.NamurAlarm Word NAMUR sum state bit-field (b0:F b1:M b2:S b3:C) Status.NamurStates.NamurAlarmDe- 4002 4002 Word device's NAMUR state bit-field (b0:F b1:M b2:S b3:C) vice 4003 4003 Status.NamurStates.NamurAlarmCh1 Word comp1's NAMUR state bit-field (b0:F b1:M b2:S b3:C) Emerson Process Management GmbH & Co. OHG 1-59...
  • Page 60 Namur Maintenance Request alarm bitfield 5006 5007… 8004 Status.NamurStates.FctCheckAlarm DWord Namur Function Check alarm bitfield 5008 5009… 8005 Status.NamurStates.FailureActive DWord Namur Failure active bitfield 5010 5011… 8006 Status.NamurStates.OffSpecActive DWord Namur Off-spec active bitfield 5012 5013… 8007 Status.NamurStates.MaintRequActive DWord Namur Maintenance Request active bitfield 5014 5015… 8008 Status.NamurStates.FctCheckActive DWord Namur Function Check active bitfield 5016 1-60 Emerson Process Management GmbH & Co. OHG...
  • Page 61 Namur Off-spec alarms that are component3 related 5068 Comp3 5069… Status.NamurStates.MaintRequAlarm- 8035 DWord Namur MaintRequ alarms that are component3 related 5070 Comp3 5071… Status.NamurStates.FctCheckAlarm- 8036 DWord Namur FctCheck alarms that are component1 related 5072 Comp3 Emerson Process Management GmbH & Co. OHG 1-61...
  • Page 62 8151… 5301… Service.Status.DeviceStates.DvcState- DWord Forcing for device (N0) state bitfield (b0:..) 8155 5310 Force 8156… 5311… Service.Status.DeviceStates.ChState- DWord Forcing for comp1's state bitfield (b0:..) 8160 5320 Force1 8161… 5321… Service.Status.DeviceStates.ChState- DWord Forcing for comp2's state bitfield (b0:..) 8165 5330 Force2 8166… 5331… Service.Status.DeviceStates.ChState- DWord Forcing for comp3's state bitfield (b0:..) 8170 5340 Force3 1-62 Emerson Process Management GmbH & Co. OHG...
  • Page 63 Status.Validation.SpanValidDeviation- curr. range span valid deviation epoch time stamp of 8218 DWord 5436 Time5 comp5 5437… Status.Calibration.ZeroCalDeviation- curr. range zero cal deviation epoch time stamp of 8219 DWord 5438 Time5 comp5 5439… Status.Calibration.SpanCalDeviation- curr. range span cal deviation epoch time stamp of 8220 DWord 5440 Time5 comp5 8221… 5441… Status.Validation.ZeroValidDeviatTime- range1..4 zero valid deviation epoch time stamp of DWord 8224 5448 Ranges1 comp1 Emerson Process Management GmbH & Co. OHG 1-63...
  • Page 64 Primary Variable 2 (Concentration in ppm) 6004 6005… 9003 Float Primary Variable 3 (Concentration in ppm) 6006 6007… 9004 Float Primary Variable 4 (Concentration in ppm) 6008 6009… 9005 Float Primary Variable 5 (Concentration in ppm) 6010 1-64 Emerson Process Management GmbH & Co. OHG...
  • Page 65 6044 tRange_1 6045… Setup.Measurement.StartOfCurren- 9023 Float start of current range of comp2 6046 tRange_2 6047… Setup.Measurement.EndOfCurren- 9024 Float end of current range of comp2 6048 tRange_2 Emerson Process Management GmbH & Co. OHG 1-65...
  • Page 66 Float temperature of comp5 6090 6091… 9046 Status.CalcResultA Float Result of calculator A 6092 6093… 9047 Status.CalcResultB Float Result of calculator B 6094 6095… 9048 Status.CalcResultC Float Result of calculator C 6096 1-66 Emerson Process Management GmbH & Co. OHG...
  • Page 67 6150 6151… 9076 Setup.Measurement.EndOfRange3_1 Float end of range3 of comp1 6152 6153… 9077 Setup.Measurement.StartOfRange4_1 Float start of range4 of comp1 6154 6155… 9078 Setup.Measurement.EndOfRange4_1 Float end of range4 of comp1 6156 Emerson Process Management GmbH & Co. OHG 1-67...
  • Page 68 6198 6199… 9100 Setup.Measurement.EndOfRange3_4 Float end of range3 of comp4 6200 6201… 9101 Setup.Measurement.StartOfRange4_4 Float start of range4 of comp4 6202 6203… 9102 Setup.Measurement.EndOfRange4_4 Float end of range4 of comp4 6204 1-68 Emerson Process Management GmbH & Co. OHG...
  • Page 69 9123 Setup.Calibration.Range1Zerogas4 Float zero gas of range1 of comp4 6246 6247… 9124 Setup.Calibration.Range2Zerogas4 Float zero gas of range2 of comp4 6248 6249… 9125 Setup.Calibration.Range3Zerogas4 Float zero gas of range3 of comp4 6250 Emerson Process Management GmbH & Co. OHG 1-69...
  • Page 70 9145 Setup.Calibration.Range3Spangas4 Float span gas of range3 of comp4 6290 6291… 9146 Setup.Calibration.Range4Spangas4 Float span gas of range4 of comp4 6292 6293… 9147 Setup.Calibration.Range1Spangas5 Float span gas of range1 of comp5 6294 1-70 Emerson Process Management GmbH & Co. OHG...
  • Page 71 6332 6333… 9167 Service.Measurement.AbsMinRange4 Float absolute minimum range of comp4 6334 6335… 9168 Service.Measurement.AbsMaxRange4 Float absolute maximum range of comp4 6336 6337… 9169 Service.Measurement.AbsMinRange5 Float absolute minimum range of comp5 6338 Emerson Process Management GmbH & Co. OHG 1-71...
  • Page 72 6374 6375… 9188 Setup.In/Outputs.AO.AdjustEnd2 Float fine adjustment for end range of output2 6376 6377… 9189 Setup.In/Outputs.AO.StartRange3 Float level where analoge output scaling starts on output3 6378 6379… 9190 Setup.In/Outputs.AO.EndRange3 Float level where analoge output scaling ends on output3 6380 6381… 9191 Setup.In/Outputs.AO.AdjustStart3 Float fine adjustment for start range of output3 6382 6383… 9192 Setup.In/Outputs.AO.AdjustEnd3 Float fine adjustment for end range of output3 6384 1-72 Emerson Process Management GmbH & Co. OHG...
  • Page 73 9249… 6497… Service.Measurement.Compensation. Float polynom coeffs for conc correction of temp factor comp3 9252 6504 TfactConcCoeffs3 9253… 6505… Service.Measurement.Compensation. Float polynom coeffs for conc correction of temp factor comp4 9256 6512 TfactConcCoeffs4 Emerson Process Management GmbH & Co. OHG 1-73...
  • Page 74 (mA) for analog output2 6588 6589… 9295 Setup.In/Outputs.AO.LowCutOff3 Float lower cut off (mA) for analog output3 6590 6591… 9296 Setup.In/Outputs.AO.HighCutOff3 Float higher cut off (mA) for analog output2 6592 1-74 Emerson Process Management GmbH & Co. OHG...
  • Page 75 6805… Setup.Measurement.XIntf.LinearPoly- Float Cross interfere linearization references1..4 for comp4 9406 6812 Coeffs4 9421… 6841… Setup.Measurement.XIntf.SignalVa- Float Cross interfere signal values1..4 for comp5 9424 6848 lues5 9425… 6849… Setup.Measurement.XIntf.InterfereF- Float Cross interfere factors1..4 for comp5 9428 6856 actors5 Emerson Process Management GmbH & Co. OHG 1-75...
  • Page 76 Temperature for zero corr component3 6934 6935… 9468 Status.Diagnostics.BeforeLinConce3 Float before linear. conc comp3 6936 6937… 9469 Status.Diagnostics.AfterLinConce3 Float after linear. conc component3 6938 6939… 9470 Status.Diagnostics.SpanCorrTemp3 Float Temp span corr component3 6940 1-76 Emerson Process Management GmbH & Co. OHG...
  • Page 77 6976 VARawValue3 6977… Service.Measurement.Simulation.SimP- 9489 Float simulation value for rawPVA of comp4 6978 VARawValue4 6979… Service.Measurement.Simulation.SimP- 9490 Float simulation value for rawPVA of comp5 6980 VARawValue5 9491… 6981… Service.Measurement.Simulation.SimX- Float simulation value for XSP's multiplexer value1..8 9498 6996 SPMuxValue1 9501… 7001… Service.Measurement.Lin.TableXVa- Float Linearization table X-Values of comp1 9503 7006 lues1 Emerson Process Management GmbH & Co. OHG 1-77...
  • Page 78 Service.Measurement.Lin.Overflow- Float Lin-Overflow [%] for Range1..4 of comp2 9684 7368 Perc2 9685… 7369… Service.Measurement.Lin.Underflow- Float Lin-Underflow [%] for Range1..4 of comp2 9688 7376 Perc2 7381… 9691 Service.Measurement.Lin.MinValue2 Float Linearizer Minimum Value of comp2 7382 7383… 9692 Service.Measurement.Lin.MaxValue2 Float Linearizer Maximum Value of comp2 7384 7385… 9693 Service.Measurement.Lin.CutOff2 Float Linearizer Cut-off value of comp1 7386 1-78 Emerson Process Management GmbH & Co. OHG...
  • Page 79 Lin-Polynom. Set3-Coeffs (A0..4) for comp4 9875 7750 9876… 7751… Service.Measurement.Lin.Set4Coeffs4 Float Lin-Polynom. Set4-Coeffs (A0..4) for comp4 9880 7760 9881… 7761… Service.Measurement.Lin.Overflow- Float Lin-Overflow [%] for Range1..4 of comp4 9884 7768 Perc4 9885… 7769… Service.Measurement.Lin.Underflow- Float Lin-Underflow [%] for Range1..4 of comp4 9888 7776 Perc4 7781… 9891 Service.Measurement.Lin.MinValue4 Float Linearizer Minimum Value of comp4 7782 Emerson Process Management GmbH & Co. OHG 1-79...
  • Page 80 16004 16005… 10003 Setup.Calibration.ZeroCalTolerance3 Float zero cal tolerance in % of comp3 16006 16007… 10004 Setup.Calibration.ZeroCalTolerance4 Float zero cal tolerance in % of comp4 16008 16009… 10005 Setup.Calibration.ZeroCalTolerance5 Float zero cal tolerance in % of comp5 16010 16011… 10006 Setup.Calibration.SpanCalTolerance1 Float span cal tolerance in % of comp1 16012 16013… 10007 Setup.Calibration.SpanCalTolerance2 Float span cal tolerance in % of comp2 16014 1-80 Emerson Process Management GmbH & Co. OHG...
  • Page 81 16048 16049… Status.Calibration.ZeroCalDeviationS- 10025 Float current range zero cal deviation sum of comp5 16050 16051… Status.Calibration.SpanCalDeviationS- 10026 Float current range span cal deviation sum of comp1 16052 16053… Status.Calibration.SpanCalDeviationS- 10027 Float current range span cal deviation sum of comp2 16054 16055… Status.Calibration.SpanCalDeviationS- 10028 Float current range span cal deviation sum of comp3 16056 16057… Status.Calibration.SpanCalDeviationS- 10029 Float current range span cal deviation sum of comp4 16058 Emerson Process Management GmbH & Co. OHG 1-81...
  • Page 82 16092 16093… 10047 Status.Validation.SpanValidDeviation2 Float current range span validation deviation of comp2 16094 16095… 10048 Status.Validation.SpanValidDeviation3 Float current range span validation deviation of comp3 16096 16097… 10049 Status.Validation.SpanValidDeviation4 Float current range span validation deviation of comp4 16098 16099… 10050 Status.Validation.SpanValidDeviation5 Float current range span validation deviation of comp5 16100 16101… 10051 Status.Average1 Float average of comp1 16102 1-82 Emerson Process Management GmbH & Co. OHG...
  • Page 83 16136 16137… 10069 Status.StdDeviation4 Float standard deviation of comp4 16138 16139… 10070 Status.StdDeviation5 Float standard deviation of comp5 16140 16141… 10071 PV_LV1 Float Last valid Primary Variable 1 (Concentration in ppm) 16142 16143… 10072 PV_LV2 Float Last valid Primary Variable 2 (Concentration in ppm) 16144 16145… 10073 PV_LV3 Float Last valid Primary Variable 3 (Concentration in ppm) 16146 Emerson Process Management GmbH & Co. OHG 1-83...
  • Page 84 10165… 16329… Status.Calibration.SpanCalDeviatSum- Float range1..4 span cal deviation sum of comp2 10168 16336 Ranges2 10169… 16337… Status.Calibration.SpanCalDeviatSum- Float range1..4 span cal deviation sum of comp3 10172 16344 Ranges3 10173… 16345… Status.Calibration.SpanCalDeviatSum- Float range1..4 span cal deviation sum of comp4 10176 16352 Ranges4 10177… 16353… Status.Calibration.SpanCalDeviatSum- Float range1..4 span cal deviation sum of comp5 10180 16360 Ranges5 1-84 Emerson Process Management GmbH & Co. OHG...
  • Page 85 10205… 16409… Status.Validation.SpanValidDeviatRan- Float range1..4 span validation deviation of comp2 10208 16416 ges2 10209… 16417… Status.Validation.SpanValidDeviatRan- Float range1..4 span validation deviation of comp3 10212 16424 ges3 10213… 16425… Status.Validation.SpanValidDeviatRan- Float range1..4 span validation deviation of comp4 10216 16432 ges4 10217… 16433… Status.Validation.SpanValidDeviatRan- Float range1..4 span validation deviation of comp5 10220 16440 ges5 Emerson Process Management GmbH & Co. OHG 1-85...

  • Page 86: List Of Bitfield States

    32-Bit-LongWord Modbus-Register (D) 8002 32-Bit-LongWord Bit0 reserved reserved Bit4 Primary Variable Clipped NAM_PV_CLIPPED Bit19 Unspecified Out of Specification NAM_OSPEC_UNSPECIF Bit21 Secondary Variable Compensation Failed NAM_SV_COMPENSATION Bit22 Environment Out Of Specified Range NAM_ENVIRONMENT Bit23 Measurement Range NAM_MEASURE_RANGE reserved Bit31 reserved 1-86 Emerson Process Management GmbH & Co. OHG...
  • Page 87 Modbus-Register (M) 5007..5008 32-Bit-LongWord Modbus-Register (D) 8004 32-Bit-LongWord Bit0 Unspecified Function Check NAM_FCHK_UNSPECIF Bit1 Simulation Activated NAM_SIMULATION Bit2 Device Being Serviced NAM_DEVICE_SERVICED Bit3 Sample Not From Process NAM_NOTFROM_PROCESS Bit6 Startup Phase NAM_STARTUP reserved Bit31 reserved Bit31 reserved Emerson Process Management GmbH & Co. OHG 1-87...
  • Page 88 Cfg file write error NAM_MEMORY_MEDIUM FATAL: FRAM read/write error NAM_MEMORY_MEDIUM DISK free space warning NAM_MEMORY_MEDIUM DISK full NAM_DEVICE_SERVICED Device not in service NAM_MAINT_UNSPECIF Operation hours exceeded NAM_NOTFROM_PROCESS Zeroing started NAM_NOTFROM_PROCESS Spanning started DO – NOT - APPLY NAM_NOTFROM_PROCESS SCAL zeroing NAM_NOTFROM_PROCESS SCAL spanning NAM_NOTFROM_PROCESS SCAL zeroing & spanning NAM_NOTFROM_PROCESS SCAL program sequence NAM_NOTFROM_PROCESS SCAL blowback NAM_NOTFROM_PROCESS SCAL test valve 1-88 Emerson Process Management GmbH & Co. OHG...
  • Page 89 NAM_PV_CLIPPED Limitation Analog Output4 NAM_PV_CLIPPED Limitation Analog Output5 NAM_PV_CLIPPED Limitation Analog Output6 NAM_PV_CLIPPED Limitation Analog Output7 NAM_PV_CLIPPED Limitation Analog Output8 NAM_FAIL_UNSPECIF External Failure NAM_MAINT_UNSPECIF External MaintRequ NAM_FCHK_UNSPECIF External FctCheck NAM_OSPEC_UNSPECIF External OffSpec DO – NOT – APPLY NAM_SIMULATION Input Simulation On XDIO 1 NAM_SIMULATION Input Simulation On XDIO 2 NAM_SIMULATION Input Simulation On XDIO 3 NAM_SIMULATION Input Simulation On XDIO 4 DO – NOT – APPLY Emerson Process Management GmbH & Co. OHG 1-89...
  • Page 90 Calculator C High-High Calculator D Low-Low Calculator D Low Calculator D High Calculator D High-High Analog Input 1 Low-Low Analog Input 1 Low Analog Input 1 High Analog Input 1 High-High Analog Input 2 Low-Low Analog Input 2 Low Analog Input 2 High Analog Input 2 High-High DO – NOT – APPLY NAM_NOTFROM_PROCESS SCAL zero validation in progress NAM_NOTFROM_PROCESS SCAL zero validation in progress NAM_NOTFROM_PROCESS SCAL zero & span validation in progress 1-90 Emerson Process Management GmbH & Co. OHG...
  • Page 91 32-Bit-LongWord – Array[5] Bitfield-value whose single bits indicate states that are related to a certain channel Description (1..5). They can be source for certain NAMUR states and are identified by its acronym identicator then. Bit 0 DO – NOT - APPLY DO – NOT - APPLY NAM_MAINT_UNSPECIF Operation hours exceeded NAM_NOTFROM_PROCESS Zeroing started NAM_NOTFROM_PROCESS Spanning started NAM_CALIB_NOTDONE Tolerance check failed NAM_CALIB_NOTDONE Unstable measurement NAM_NOTFROM_PROCESS No sample gas Emerson Process Management GmbH & Co. OHG 1-91...
  • Page 92 NAM_SENSOR_ENGINE Sensor failure NAM_STARTUP Warming up NAM_SV_COMPENSATION Sensor Temperature NAM_FLOW_FAILURE Sensor Flow NAM_SV_COMPENSATION Sensor Pressure NAM_FLOW_ALARM External Flow Alarm NAM_SENSOR_ENGINE Sensor Chopper NAM_SENSOR_ENGINE Sensor Detector NAM_SENSOR_ENGINE Sensor Source- NAM_SENSOR_ENGINE Sensor Source+ NAM_SENSOR_ENGINE Sensor ADC 1-92 Emerson Process Management GmbH & Co. OHG...
  • Page 93 NAM_MEASURE_RANGE Linearizer overflow NAM_STARTUP PAUSE Status NAM_STARTUP STANDBY Status NAM_STARTUP Startup Phase DO – NOT - APPLY NAM_FAIL_UNSPECIF External Failure NAM_MAINT_UNSPECIF External MaintRequ NAM_FCHK_UNSPECIF External FctCheck NAM_OSPEC_UNSPECIF External OffSpec obsolete DO – NOT - APPLY obsolete DO – NOT - APPLY DO – NOT - APPLY NAM_CALIB_NOTDONE GainOverRange NAM_CALIB_NOTDONE GainUnderRange DO – NOT - APPLY Emerson Process Management GmbH & Co. OHG 1-93...
  • Page 94 Temperature Low Temperature High NAM_SV_COMPENSATION Temperature High-High Pressure Low-Low Pressure Low Pressure High Pressure High-High NAM_FLOW_FAILURE Flow Low-Low NAM_FLOW_ALARM Flow Low NAM_FLOW_ALARM Flow High NAM_FLOW_FAILURE Flow High-High DO – NOT - APPLY NAM_CALIB_NOTDONE ZeroSamplingFail NAM_CALIB_NOTDONE SpanSamplingFail NAM_NOTFROM_PROCESS Zero Validation in progress 1-94 Emerson Process Management GmbH & Co. OHG...
  • Page 95 32-Bit-LongWord – Array[5] Bitfield-value whose single bits indicate states that are related to a certain channel Description (1..5). They can be source for certain NAMUR states and are identified by its acronym identicator then. NAM_NOTFROM_PROCESS Span Validation in progress NAM_VALID_NOTDONE Zero Validation Tolerance failed NAM_VALID_NOTDONE Span Validation Tolerance failed NAM_VALID_NOTDONE Unstable measurement DO – NOT - APPLY NAM_VALID_NOTDONE Sampling for Zero validation failed NAM_VALID_NOTDONE Sampling for Span validation failed DO – NOT - APPLY DO – NOT - APPLY Emerson Process Management GmbH & Co. OHG 1-95...
  • Page 96 © 2017 Emerson. All rights reserved. The Emerson logo is a trademark and service mark of Emerson Electric Co. Rosemount is a mark of one of the Emerson family of companies. All other marks are the property of their respective owners. The contents of this publication are presented for information purposes only, and while effort has been made to ensure their accuracy, they are not to be construed as warranties or guarantees, express or implied, regarding the products or services described herein or their use or applicability. All sales are governed by our terms and conditions, which are available...
