Connections

1
1
Accepts a standard, grounded IEC power
1 . AC Power Connector—
cord. Operates over a range of 100 to 240 volts and 50 to 60 Hz.
For bidirectional MIDI communication with a computer. The
2 . USB—
Prophet Rev2 is a Class Compliant USB device and does not require
additional drivers when used with Mac OS or Windows. See "Using
USB" on page 70 for more information.
Standard 5-pin MIDI DIN connectors.
3 . MIDI In, Out, and Thru—
Accepts a momentary, normally open or normally closed
4 . Sequencer—
footswitch to turn the sequencer or arpeggiator on and off. Alternatively, an
audio signal connected to this jack can be used to either control sequencer/
arpeggiator playback, or to gate the filter and amplifier envelopes while
notes are held. See Pedal/CV on page 13 for more information about
choosing the appropriate mode for these behaviors.
Audio signals used to drive the arpeggiator/sequencer should not exceed 5
volts peak-to-peak.
Accepts a momentary, normally open or normally closed
5 . Sustain—
footswitch to control sustain.
12 Connections
PEDAL/CV
2 3 4
2 3 4 5 6
6 . Pedal/CV—
resistor on a TRS (tip-ring-sleeve) ¼ inch phone plug. Once connected,
you can use the modulation matrix to route the pedal to control a variety
of things such as volume or filter cutoff frequency to add expressiveness
to live performance.
7 . B Audio Outputs—
cables to these jacks if you want separate stereo outputs for Layer B. If
no cables are connected, Layer B is output on the Main A Outputs.
8 . Main/ A Audio Outputs—
are the main stereo outputs for the synth. They carry Layer A and also
Layer B if no cables are connected to the "B Audio Outputs" jacks.
9 . Headphones—
controlled by the
Sequential Prophet Rev2 User's Guide
B OUTPUT MAIN A OUTPUT
B OUTPUT MAIN A OUTPUT
PEDAL/CV
5 6 7 8
7 8 9
Accepts a standard expression pedal that has a variable
Unbalanced, ¼ inch audio outputs. Connect audio
Unbalanced, ¼ inch audio outputs. These
A ¼ inch stereo headphone jack. Headphone volume is
knob on the front panel.
master volume
9
Connections 13
