Additional Continuous Controllers Transmitted/Received
The following table details how MIDI Continuous Controllers (CCs) are
mapped to Rev2 controls. They are transmitted when Param Xmit is set
to CC, and recognized/received when MIDI Rcv Receive is set to CC.
CC# Param
Mod Wheel
1
3 FX Type
Glide Mode
5
Master Volume
7
8 Sub Oscillator
Osc. Slop
9
10 Pan Mod Mode
12 FX Param 1
FX Param 2
13
14 BPM
Clock Divide
15
FX On/Off
16
17 FX Mix
A/B Mode
18
19 Sequencer Type
20 Osc 1 Frequency
Osc 1 Fine Tune
21
22 Osc 1 Shape
Osc 1 Glide Rate/Time
23
Osc 2 Frequency
24
25 Osc 2 Fine Tune
Osc 2 Shape
26
27 Osc 2 Glide Rate/Time
28 Osc Mix
Noise Level
29
30 Osc 1 Shape Mod
Osc 2 Shape Mod
31
Arp On/Off
33
34 Arp Mode
Arp Range
35
36 Arp Repeats
37 Voice Volume
86 Appendix E: MIDI Implementation
CC# Param
39 Split Point
Sustain Pedal
64
65 Glide On/Off
75 Amp Sustain
Amp Release
76
77 Env 3 Sustain
78 Env 3 Release
Env 3 Destination
85
86 Env 3 Amount
Env 3 Velocity
87
88 Env 3 Delay
89 Env 3 Attack
Env 3 Decay
90
102 Filter Frequency
103 Resonance
Filter Key Amount
104
105 Filter Audio Mod
Filter Env. Amount
106
107 Filter Env. Velocity
108 Filter Delay
Filter Attack
109
110 Filter Decay
111 Filter Sustain
Filter Release
112
113 VCA Level
114 Pan Spread
Amp Env. Amount
115
Amp Env. Velocity
116
117 Amp Delay
Amp Attack
118
Amp Decay
119
Sequential

NRPN Messages

The Non-Registered Parameter Number (NRPN) MIDI messages are
used to transmit and receive both global and program parameters. They
are transmitted when MIDI Parameter Send is set to NRPN in
and received when MIDI Parameter Receive is set to NRPN in
The messages are handled in standard MIDI format using the NRPN CC
commands in running status byte format. Below is the format used for
transmitting a NRPN parameter.
Transmitted NRPN Messages
Status Description
1011 nnnn Control Change
0110 0011 NRPN parameter number MSB CC
0vvv vvvv Parameter Number MSB
0110 0010 NRPN parameter number LSB CC
0vvv vvvv Parameter Number LSB
0000 0110 NRPN parameter value MSB CC
0vvv vvvv Parameter value MSB
0010 0110 NRPN parameter value LSB CC
0vvv vvvv Parameter value LSB
The parameter number can be found in the two tables below, one for
global parameters, and the other for program parameters. The parameter
numbers and the parameter values are broken into two 7-bit bytes for
MIDI transmission; the LSB has the seven least-significant bits, and the
MSB has the seven most-significant bits, though in most cases the MSB
will be zero or one, and never more than two.
When receiving an NRPN, all messages do not necessarily need to be
transmitted, since the synth will track the most recent NRPN number,
though it is usually good practice to send the entire message above.
Once an NRPN is selected, the synth will also respond to NRPN Data
Increment and Decrement commands, which some controllers utilize.
Finally, it responds to one RPN (Registered Parameter Number)
command, the RPN/NRPN Reset command, which can be handy for
resetting the currently selected parameter to a known state.
