Received NRPN Messages
Status Second Third
1011 nnnn 0110 0011 0vvvvvvv
1011 nnnn 0110 0010 0vvvvvvv
1011 nnnn 0000 0110 0vvvvvvv
1011 nnnn 0010 0110 0vvvvvvv
1011 nnnn 0110 0000 0xxxxxxx
1011 nnnn 0110 0001 0xxxxxxx
1011 nnnn 0010 0101 0111111
1011 nnnn 0010 0100 0111111
88 Appendix E: MIDI Implementation
Description
NRPN parameter number MSB CC
NRPN parameter number LSB CC
NRPN parameter value MSB CC
NRPN parameter value LSB CC
NRPN parameter value Increment
NRPN parameter value Decrement
RPN parameter number MSB CC - Reset NRPN param-
eter number (when both MSB and LSB received)
RPN parameter number LSB CC - Reset NRPN param-
eter number (when both MSB and LSB received)
Sequential
Global Parameter Data
The table shows the global data sent and received on global parameter
dumps, and corresponding NRPN number when sent/received individually.
NRPN Range Description
4097 0-24 Master Coarse Tune
4096 0-50 Master Fine Tune
4098 0-16 MIDI Channel
0 = All
4099 0-4 MIDI Clock Mode
0 = Off
1 = Master
2 = Slave
3 = Slave Thru
4100 0-1 MIDI Clock Cable
0 = MIDI Port
1 = USB
4101 0-2 MIDI Param Send*
0 = NRPN
1 = CC
2= Off
4102 0-2 MIDI Param Receive†
0 = NRPN
1 = CC
2= Off
4103 0-1 MIDI Control Enable
0 = Off
1 = On
4104 0-1 MIDI SysEx Cable
0 = MIDI
1 = USB
4105 0-2 MIDI Out Select
0 = Off
1 = MIDI
2 = USB
3 = MIDI+USB
4107 0-1 Local Control*
0 = Off
1 = On
4109 0-2 Pot Mode
0 = Relative
1= PassThru
2 = Jump
4111 0-3 Seq Pedal Mode
0 = normal
1= trigger
2= gate
3= trigger+gate
Prophet Rev2 User's Guide
NRPN Range Description
4112 0-1
Sustain Polarity
0 = normally open
1= normally closed
2= Sustain Normally Open/
Sequencer Normally Closed
3= Sustain Normally Closed/
Sequencer Normally Open
4113 0-7
Velocity Curve
4114 0-3 Pressure Curve
4115 0-1 Mono/Stereo
Mono/Stereo
0 = Stereo
1 = Mono
4116 0-16 Alt. Tunings
4118 0-1 MIDI Prog Enable
0 = Off
1 = On
4119 0-1 Multi Mode
0 = Off
1 = On
4120 0-1 Screen Saver
0 = Off
1 = On
4121 0-1 Sustain/Arp
4190 0-1 Layer A/B Switch
*Controller received, but not transmitted.
†Controller transmitted, but ignored when received.
