Effects Parameters

Turns the effect on or off. On stacked or split sounds, enable the
On/Off:
button to affect Layer B.
edit layer b
Selects the effect type.
Select:
—Sets the balance between the processed (wet) signal
Mix: 0...127
and unprocessed (dry) signal. Full left is completely dry. Full right is
completely wet.
—When a delay effect is chosen, this enables syncing of
Clk Sync: On, Off
the timed delay repeats (feedback) to the arpeggiator, sequencer, or MIDI
clock. When is on, delay time (parameter 1) provides the
clk sync
following values:
Value
Whole
Half dot
Half
Quarter dot
Quarter
Quarter triplet
8th dot
8th
8th triplet
16th dot
16th
Maximum delay time is 1 second. The combination of longer synced delay
times with slower tempos can result in delay times that would be greater than 1
second. When that happens, the delay time is divided by 2 until it no longer exceeds
the 1 second limit. For example, if the BPM is set to 60 and Delay Time (Parameter 1)
is set to Half, the expected delay time would be 2 seconds. The actual delay time will
be 1 second (i.e. 2 seconds divided by 2).
38 Effects
Delay Time
4 beats
3 beats
2 beats
1 1/2 beats
1 beat
1 1/3 beats
3/4 of 1 beat
1/2 of 1 beat
1/3 of 1 beat
3/8 of 1 beat
1/4 of 1 beat
Sequential
Parameter 1:
Variable, depending on the effect
parameter 1 for the chosen effect. Each effect has two adjustable param-
eters, which differ depending on the effect.
Parameter 2:
Variable, depending on the effect
parameter 2 for the chosen effect. Each effect has two adjustable param-
eters, which differ depending on the effect.
Effect Type Parameter 1
mono delay delay time
DDL stereo delay time
BBD delay delay time
chorus rate
phaser high rate
phaser low rate
phaser mst rate
flanger 1 rate
flanger 2 rate
reverb time
ring mod ring mod tuning
distortion gain
HP filter cutoff
To recreate a classic bucket-brigade time-shifting effect, try adjusting the delay
time parameter in real time.
The ring modulator's mode of operation is determined by Parameter 2, (pitch
tracking) which can be set to either
on
tor functions like the original Oberheim unit. In this mode, pitch tracking is off, and
Parameter 1 sets the modulation frequency, which remains the same regardless of
what note you play on the keyboard. With parameter 2 on, the ring modulator tracks
the pitch of the lowest note that you play on the keyboard. In this case the Parameter
1 sets a ratio between the lowest note that you play and the modulator note (instead of
setting a fixed frequency). The modulation frequency will then change as you change
the lowest note that you're playing, so that the ratio will remain constant between
the note that you play and note of the modulator. If you are only playing one note at
a time, then the ring modulator will modulate with the same ratio as you play up and
down the keyboard. Set Parameter 2 to the "on" position to get more musical results.
Prophet Rev2 User's Guide
—This knob adjusts
—This knob adjusts
Parameter 2
feedback amount
feedback amount
feedback amount
depth
depth
depth
depth
depth
depth
color
low-note pitch
tracking on/off
tone
resonance
or . With this parameter off, the ring modula-
off
