NRPN Layer NRPN Layer Value Description
A B
182 2230 0-4 Gated Seq. Mode
183 2231 0-1 Gated Seq. on/off
184 2232 0-52 Seq. 1 Destination
185 2233 0-53 Seq. 2 Destination
(slew)
186 2234 0-52 Seq. 3 Destination
187 2235 0-53 Seq. 4 Destination
(slew)
192-207 2240-2255 0-127 Gated Seq Track 1
Step 1-16
208-223 2256-2271 0-127 Gated Seq Track 2
Step 1-16
224-239 2272-2287 0-127 Gated Seq Track 3
Step 1-16
240-255 2288-2303 0-127 Gated Seq Track 4
Step 1-16
276-339 2324-2387 0-127 Seq Step 1-64
Note 1
340-403 2388-2451 128-255 Seq Step 1-64
Velocity 1
404-467 2452-2515 0-127 Seq Step 1-64
Note 2
468-531 2516-2579 128-255 Seq Step 1-64
Velocity 2
532-595 2580-2643 0-127 Seq Step 1-64
Note 3
596-659 2644-2707 128-255 Seq Step 1-64
Velocity 3
660-723 2708-2771 0-127 Seq Step 1-64
Note 4
724-787 2772-2835 128-255 Seq Step 1-64
Velocity 4
788-851 2836-2899 0-127 Seq Step 1-64
Note 5
852-915 2900-2963 128-255 Seq Step 1-64
Velocity 5
916-979 2964-3027 0-127 Seq Step 1-64
Note 6
980-1043 3028-3091 128-255 Seq Step 1-64
Velocity 6
94 Appendix E: MIDI Implementation

Control NRPN Data

The following table lists the Rev2's control NRPN data. It is received
and transmitted but not saved as part of a program.
NRPN
1088
16383

SysEx Messages

Universal System Exclusive Message (Device Inquiry)
Status
1111 0000
0111 1110
0vvv vvvv
0000 0110
0000 0001
1111 0111
The Rev2 responds with:
Status
1111 0000
0111 1110
0vvv vvvv
0000 0110
0000 0010
0000 0001
0010 1111
0000 0001
0000 0000
0000 0000
0jjj nnnn
1111 0111
Sequential Prophet Rev2 User's Guide
Value Description
0-1 Seq Play/Stop
0-1 Seq Rec On/Off
Description
System Exclusive (SysEx)
Non-realtime message
If MIDI channel is set to 1 - 16, 0vvvvvvv must match (unless MIDI Channel = ALL); always
responds if 0vvvvvvv = 0111 1111.
Inquiry Message
Inquiry Request
End of Exclusive (EOX)
Description
System Exclusive (SysEx)
Non-realtime message
If MIDI Channel = ALL, 0vvvvvvv = 0111 1111. Otherwise 0vvvvvvv = Channel Number
0 - 15.
Inquiry Message
Inquiry Reply
DSI ID
Rev2 ID (Family LS)
Family MS
Family Member LS
Family Member MS
Main Software version: jjj - Minor rev; nnnn - Major rev
End of Exclusive (EOX)
Appendix E: MIDI Implementation 95
