- Page 1 Integration Guide: GSM0308IG002 Enfora Enabler IIIG M2M Integration Guide Version: 1.05 www.agelectronica.com www.agelectronica.com...
- Page 2 All specifications are subject to change without notice and do not represent a commitment on the part of Enfora, Inc. Enfora, Inc. will not be responsible for any loss or damages incurred related to the use of information contained in this document.
-
Page 3: Table Of Contents
............................5 EVISION ISTORY 3.2..........................6 EFERENCE OCUMENTS 3.2.1. Enfora Enabler IIIG Product Documentation ..................6 3.2.2. GSM Device Specifications ........................7 3.2.3. US Government ............................7 3.2.4. Federal Communications Commission (FCC) ..................7 ... - Page 4 ARRIER 6.7.1. SIM Integration for the Enfora Enabler IIIG Module ................. 55 6.7.2. Using a Remote SIM with the Enfora Enabler IIIG Module (Pins 76, 78, 80, 82, 84) ......55 6.7.2.1. Remote SIM Component Information ......................57 GSM/GPRS MODES OF OPERATION ......................
- Page 5 10.2. GSM/SMS E ..........................69 XAMPLES 10.2.1. Initialize the Enfora Enabler IIIG Module to Send and Receive SMS Text Messages ......69 10.2.2. Managing SMS Messages ........................69 10.2.3. Data Call Configuration ........................69 ...
-
Page 6: Safety Precautions
• Save this manual: it contains important safety information and operating instructions. • Do not expose the Enfora Enabler IIIG product to open flames. • Ensure that liquids do not spill onto the devices. •... - Page 7 Enfora Enabler IIIG M2M Modem Integration Guide • Unintentional emissions, FCC Part 15; results do not have to be submitted to the FCC unless requested, although the test provides substantiation for required labeling (see below). • ERP and EIRP measurements for FCC Parts 22 and 24, alternatively a full retest on FCC Parts 22 and 24 can be performed.
- Page 8 Enfora Enabler IIIG M2M Modem Integration Guide • Any antenna used with the modem must be approved by the FCC or as a Class II Permissive Change (including MPEL or SAR data as applicable). The "professional installation" provision of FCC Part 15.203 does not apply.
-
Page 9: Disclaimer
PTCRB, R&TTE, IMEI and other applicable codes that are in effect at the time of publication. Enfora disclaims all responsibility for any act or omissions, or for breach of law, code or regulation, including local or state codes, performed by a third party. -
Page 10: Manual Overview
Enfora Enabler IIIG M2M Modem Integration Guide 3. Manual Overview This document describes the available hardware interface of the Enabler IIIG modem. The purpose of this document is to define the electrical, mechanical and software interfaces while providing detailed technical information in order to streamline the process of hardware and system integration. -
Page 11: Reference Documents
Modem Integration Guide 3.2. Reference Documents 3.2.1. Enfora Enabler IIIG Product Documentation Manuals • GSM0308AT001 - Enfora GSM/GPRS OEM Module AT Command Set Reference • GSM0308UG001 - Enfora GSM-GPRS Family API Reference Application Notes • GSM0000AN001 - Enabler-G PPP Configuration for Windows 98 •... -
Page 12: Gsm Device Specifications
Enfora Enabler IIIG M2M Modem Integration Guide 3.2.2. GSM Device Specifications • 3GPP TS 51010-1 (850, 900,1800,1900 MHz devices) To view the latest release, go to: http://www.3gpp.org/ftp/Specs/html-info/51010-1.htm 3.2.3. US Government 3.2.4. Federal Communications Commission (FCC) Internet: http://www.fcc.gov/ •... -
Page 13: Mechanical Specifications
Enfora Enabler IIIG M2M Modem Integration Guide 3.2.8. Mechanical Specifications • ASTM D999 • ASTM D775 • IEC 68-2-27 • Bellcore Gr-63-CORE • ETS 300 019-1-1 Class 1.2 • ETS 300 019-1-2 Class 2.1 • ETS 300 019-1-3 Class 3.1 3.2.9. -
Page 14: Introduction
GSM services. The Enfora Enabler IIIG module is a fully Type-approved GSM/GPRS device, enabling application-specific, two-way communication and control. The small size of the Enfora Enabler IIIG module allows it to be integrated easily into the application and packaging. 4.2. -
Page 15: Table 1 - Enabler Iiig Key Features
Enfora Enabler IIIG M2M Modem Integration Guide • GSM/GPRS Mobile-originated and mobile-terminated SMS messages: up to 140 bytes or Functionality up to 160 GSM 7-bit ASCII characters. • Reception of Cell Broadcast Message • SMS Receipt acknowledgement •... -
Page 16: Providing Multi-Band Operation
4.3. Providing Multi-Band Operation The Enfora Enabler IIIG module provides 4 frequency bands for compatibility with worldwide frequency standards. 850/1900 frequency bands are primarily used in North and South America, while 900/1800 bands are used throughout the world. The Enabler III offers all four bands for use worldwide. -
Page 17: Summary Of Features For The Enabler Iiig Module
Enfora Enabler IIIG M2M Modem Integration Guide 4.5. Summary of Features for the Enabler IIIG Module The following summarizes the main features of the Enfora Enabler IIIG Module. Mechanical Dimensions ........27.0 mm x 28.0 mm x 2.50 mm Weight .......... 3.6g Packet Data Transfer: Protocol……………………………………………GPRS Release 97 and 99... - Page 18 Enfora Enabler IIIG M2M Modem Integration Guide Application Interface: Host Protocol ........ Enfora Packet API and AT Commands Internal Protocols ......UDP stack, TCP/IP stack, PPP, PAD, and CMUX Physical Interface ......1 serial (primaryDefault rate auto baud, ), I USB (debug) MCSI (PCM Audio only) Audio Interface ......
-
Page 19: General Design Guidelines For Utilizing Enfora Gsm Modules
1800/1900 MHz ......<-106 dBm, GPRS Coding Scheme 1 (CS1) 850/900 MHz ........ <-106 dBm, GPRS Coding Scheme 1 (CS1) 4.6. General design guidelines for utilizing Enfora GSM modules The following guidelines are provided in an effort to allow Enabler IIIG module users to successfully implement their PCB layout to obtain the best performance. -
Page 20: Advanced Tips For An Rf Friendly Layout
Enfora Enabler IIIG M2M Modem Integration Guide 4.6.1. Advanced tips for an RF friendly layout 4.6.1.1. Ground Plane To ensure the lowest possible EMI emissions and maximum thermal conductivity, it is recommended that all metal tabs on the GSM module shield must be soldered down onto a continuous ground plane that runs under the entire module. -
Page 21: Figure 2 - Example Of A Poor Rf Thermal Relief
Enfora Enabler IIIG M2M Modem Integration Guide frequency applications. However, such thermal relief structures should be avoided for applications where high current and/or high frequency is involved, such as those using the Enabler Module. Depending on the frequency of operation, the long narrow thermal relief traces between the pad and the ground plane act like an RF choke. -
Page 22: Antenna And Rf Signal Trace
Enfora Enabler IIIG M2M Modem Integration Guide GOOD RF thermal relief Figure 3 - Example of a GOOD RF Thermal Relief 4.6.1.3. Antenna and RF Signal Trace The PCB trace that feeds the RF output port must be designed for a 50 ohm characteristic impedance, coplanar, or routed into internal layers to keep the top layer continuous around and underneath the Enabler module. -
Page 23: Vbat Input
Enfora Enabler IIIG M2M Modem Integration Guide 4.6.1.4. Vbat Input The Enabler Vbat input can have a relative high current draw that can fluctuate rapidly, especially when transmitting at max power and burst mode. The Vbat interface must be designed to provide the required instantaneous voltage and current with minimal voltage droop. -
Page 24: Figure 5 - Example Of Good Vbat Layout
Enfora Enabler IIIG M2M Modem Integration Guide impedance and should utilize multiple vias to the internal ground plane close to the capacitor as well. Vbat trace Figure 5 - Example of GOOD Vbat layout GSM0308IG002 Version 1.05 – 11/13/08 www.agelectronica.com... -
Page 25: Audio Reference Design
Enfora Enabler IIIG M2M Modem Integration Guide 4.6.2. Audio Reference Design The audio quality is very dependent on the circuit design and layout. As an aid to obtaining good audio quality, a reference design has been included below. It has been proven to provide good performance on the SDK module. -
Page 26: Audio Layout
Enfora Enabler IIIG M2M Modem Integration Guide 4.6.2.2. Audio Layout Layout plots for the audio section of the SDK are available upon request. GSM0308IG002 Version 1.05 – 11/13/08 www.agelectronica.com www.agelectronica.com... -
Page 27: Technical Specifications
Enfora Enabler IIIG M2M Modem Integration Guide 5. Technical Specifications 5.1. Detailed Product Specifications Physical Dimensions and Weight Size (L x W x H) 27.0 mm x 28.0 mm x 2.50 mm Weight Without SIM Connector – < 3.6 grams With SIM Connector (no SIM inserted) –... -
Page 28: Operating Power
Enfora Enabler IIIG M2M Modem Integration Guide 5.2. Operating Power The Enfora Enabler IIIG module requires an input voltage of 3.3 Vdc to 4.5 Vdc. 5.2.1. Typical Input Current Test Conditions: Typical Results @ 3.8 V, 20 deg C, with 2000 μF at connector input on V and RF terminated into a 50 Ω... -
Page 29: Physical Interfaces
Enfora Enabler IIIG M2M Modem Integration Guide 6. Physical Interfaces (Dimensions are in millimeters.) Figure 7 – Front of Module (Board-to-Board RF Conn. Version) GSM0308IG002 Version 1.05 – 11/13/08 www.agelectronica.com www.agelectronica.com... -
Page 30: Figure 8 - Pin 1 Reference, 100-Pin I/O Connector
Enfora Enabler IIIG M2M Modem Integration Guide Figure 8 - Pin 1 Reference, 100-Pin I/O Connector GSM0308IG002 Version 1.05 – 11/13/08 www.agelectronica.com www.agelectronica.com... -
Page 31: Figure 9 - Front Of Module (Coaxial Rf Conn. Version)
Enfora Enabler IIIG M2M Modem Integration Guide Figure 9 – Front of Module (Coaxial RF Conn. Version) GSM0308IG002 Version 1.05 – 11/13/08 www.agelectronica.com www.agelectronica.com... -
Page 32: Figure 10 - Back Of Module (Option Sim Shown)
Enfora Enabler IIIG M2M Modem Integration Guide Figure 10 - Back of Module (Option SIM Shown) GSM0308IG002 Version 1.05 – 11/13/08 www.agelectronica.com www.agelectronica.com... -
Page 33: Module Mounting To Host Board (Reference)
Enfora Enabler IIIG M2M Modem Integration Guide 6.1. Module Mounting to Host Board (Reference) The module provides mounting tabs that must be soldered to a PCB. These tabs provide circuit grounding for the module. Figure 11 – Module Mounting GSM0308IG002 Version 1.05 –... -
Page 34: Figure 12 - Host Pads For Board-To-Board Rf Connector
Enfora Enabler IIIG M2M Modem Integration Guide Figure 12 - Host Pads for Board-To-Board RF Connector GSM0308IG002 Version 1.05 – 11/13/08 www.agelectronica.com www.agelectronica.com... -
Page 35: Figure 13 - Modem Mounting Pads
Enfora Enabler IIIG M2M Modem Integration Guide Figure 13 – Modem Mounting Pads GSM0308IG002 Version 1.05 – 11/13/08 www.agelectronica.com www.agelectronica.com... -
Page 36: Connectors
Enfora Enabler IIIG M2M Modem Integration Guide 6.2. Connectors On The Modem: 100-Pin I/O Connector, Plug, SMT, Dual Row, 0.4 mm Pitch Enfora PN = CON-1040-0100 Molex PN = 55909-1074 On The Host: 100-Pin I/O Connector, Socket, SMT, Dual Row, 0.4 mm Pitch (Mate to module) -
Page 37: I/O Connector Pin Assignments
Enfora Enabler IIIG M2M Modem Integration Guide 6.3.3. I/O Connector Pin Assignments The following table shows the pin assignments for the input/output connector. Table 2 - Enabler IIIG Pin Assignments Pin # Serial Enabler IIIG Description/Comments (Default Function / Secondary... - Page 38 Enfora Enabler IIIG M2M Modem Integration Guide Pin # Serial Enabler IIIG Description/Comments (Default Function / Secondary Function RESERVED RESERVED RESERVED RESERVED HSMICBIAS Headset microphone bias System ground HSMIC Microphone input (Headset) CLK32K_BUF 32.768 kHz out, only buffered by 10 kΩ resistor HSOL 32 kΩ...
-
Page 39: Circuit Protection
Enfora Enabler IIIG M2M Modem Integration Guide 6.4. Circuit Protection Other than very low level ESD protection within the module’s integrated circuits, the module does not have any protection against ESD events or other excursions that exceed the specified operating parameters. -
Page 40: Antenna
6.6.1. Module Power (Pins 85, 87, 89, 91, 93, 95, 97, 99) The Enfora Enabler IIIG module uses a single voltage source of VCC=+3.3V to 4.5V. (The exact values of the uplink currents are shown in the tables in section 5.3.1.) -
Page 41: Reset Signal (Pin 37)
Enfora Enabler IIIG M2M Modem Integration Guide 6.6.2. Reset Signal (Pin 37) The Reset signal is used to force the modem to start at a known state. When the Reset is pulled low the modem will immediately suspend any function and will not exit the reset state until the Reset signal is released to be pulled high. -
Page 42: Power Control (Pin 35) (Pwr_Ctl)
Enfora Enabler IIIG M2M Modem Integration Guide 6.6.3. Power Control (Pin 35) - (PWR_CTL) The input is equivalent to a “phone ON-button”. A falling-edge on this Active-Low input will switch-ON the module or switch-OFF the module after a delay . -
Page 43: Using The Power Control Signal
Enfora Enabler IIIG M2M Modem Integration Guide 6.6.3.3. Using the Power Control Signal Typical use powering module on/off with a switch: Figure 14 – Power Control Switch GSM0308IG002 Version 1.05 – 11/13/08 www.agelectronica.com www.agelectronica.com... -
Page 44: Figure 15 - External Power Control Signal (No External Processor)
Float RESET Figure 16 - External Power Control Signal (no external processor) shows a typical connection to the Enfora Enabler IIIG module in a machine-to-machine application using the external PWR_CTL signal, when there is not an external processor controlling the power on/off states. The RTC deep sleep functions will NOT function since the PWR_CTL pin is tied low, the processor will never stay in a “RTC Sleep”... -
Page 45: Figure 16 - Power Control Signal (Using External Processor)
Figure 16 - Power Control Signal (using external processor) shows a typical connection from an external processor to the Enfora Enabler IIIG module, using the external PWR_CTL signal. The Enfora Enabler IIIG can be powered on by using the PWR_CTL signal, and reset with the RESET signal. When using PWR_CTL, the I/O or serial lines can be at any voltage state desired. -
Page 46: Level Translation Reference Power (Pin 77)
Output voltage V LOW POWER mode 1.65 1.95 Rated output current I ON mode LOW POWER mode 6.6.5. USB (Pins 1, 3, 5, 7, 9) This is for Enfora Debug only Pin Name Signal Description Number Direction USB_VBUS 1, 3 5 V tolerant power Supply VBUS line;... - Page 47 Enfora Enabler IIIG M2M Modem Integration Guide 5V Tolerant Transceiver Parameter/Conditions Units Input Voltage 4.65 5.25 Output voltage High (Driven) Transceiver D+/- μA Leakage Current GSM0308IG002 Version 1.05 – 11/13/08 www.agelectronica.com www.agelectronica.com...
-
Page 48: General Purpose Input/Output Interface
Enfora Enabler IIIG M2M Modem Integration Guide 6.6.6. General Purpose Input/Output Interface GPIO number Pin number Secondary Function GPIO 1 GPIO 2 GPIO 3 GPIO 4 GPIO 5 GPIO 6 GPIO 7 GPIO 8 GPIO 9 MCSI_CLK GPIO 10... -
Page 49: Rtc Sleep
Enfora Enabler IIIG M2M Modem Integration Guide The below table shows the factory default modem GPIO configuration: PU/PD PU/DN PU/PD Iout Notes Enabled setting capability Value Value KOhm KOhm PU/PD Pulldown Modem PU/PD PU/PD PU/PD PU/PD PU/PD PU/PD... -
Page 50: Serial Interfaces & Handshake (Pins 11, 13, 15, 17, 19, 21, 23, 25)
The pin naming for TX/RX/RTS/CTS/DTR/DSR is referenced as a DTE .The DTE device should match their input pins to the Enfora outputs and vice-versa. Additionally, there are AT commands that may need to be executed in order to insure proper operation. See the chart below. -
Page 51: Ring Indicate (Pin 23)
Enfora Enabler IIIG M2M Modem Integration Guide For a minimal Serial implementation use one of the following two configurations: • Connect RxData (pin 15) and TxData (pin 21) to the COM port serial data lines. • DTR (pin 17) and RTS (pin 11) be pulled up through a 100K resistor if not used. -
Page 52: Figure 17 - Ring Indicate Timing
Enfora Enabler IIIG M2M Modem Integration Guide When an incoming SMS is received, Ring indicate goes low for 1 second, then returns to a high state. See below logic diagram. Ring 1 second Figure 17 - Ring Indicate Timing Serial I/O &... -
Page 53: Mcsi - Multi-Channel Serial Interface (Pins 12, 14, 16, 18)
Enfora Enabler IIIG M2M Modem Integration Guide 6.6.9. MCSI – Multi-Channel Serial Interface (Pins 12, 14, 16, 18) This port is only available in Master mode and to be used for PCM digital audio. Below are the settings... -
Page 54: Vbackup Input (Pin 83)
Enfora Enabler IIIG M2M Modem Integration Guide 6.6.10. VBACKUP Input (Pin 83) The backup battery can be recharged from the main battery. A programmable voltage regulator powered by the main battery allows recharging the backup battery. The backup battery charge starts when the... -
Page 55: Analog-To-Digital Input (Pin 74)
Enfora Enabler IIIG M2M Modem Integration Guide 6.6.13. Analog-To-Digital Input (Pin 74) The monitoring ADC (MADC) consists of a successive approximation 10–bit analog–to–digital converter (ADC). Analog-To-Digital Input Parameter/Conditions Units ADC Binary Resolution Bits BRES ADC Reference Voltage 1.75 ADC Range 1.75... - Page 56 Enfora Enabler IIIG M2M Modem Integration Guide Handset Spkr Output Parameter/Conditions Units Maximum Differential Output Swing 3.9 V Ω Resistive Load Output Swing 1.5 V Ω Maximum Differential Capacitive Load Common Mode At Internal Speaker (+) or (-) kΩ...
-
Page 57: Headset Microphone Input (Pin 55)
Enfora Enabler IIIG M2M Modem Integration Guide 6.6.17. Headset Microphone Input (Pin 55) Mic Input Parameter/Conditions Units The headset differential inputs HSMIC and AUXI can be amplified by the differential handset microphone amplifier. This amplifier has two different gains 4.9 dB or 25.6 dB and a bias... -
Page 58: Headset Speaker Output Left & Right (Pins 57, 59)
Enfora Enabler IIIG M2M Modem Integration Guide 6.6.19. Headset Speaker Output Left & Right (Pins 57, 59) Pin Name Pin Number Signal Direction Description HSOL Headset Out 32Ω Speaker Left HSOR Headset Out 32Ω Speaker Right HSOVMID Headset Out pseudo ground return The left and right headset amplifiers provide the stereo signal on terminals HSOL and HSOR. -
Page 59: Headset Detect (Pin 47)
Enfora Enabler IIIG M2M Modem Integration Guide 6.6.21. Headset Detect (Pin 47) Headset Plug/Unplug detection. This pin is used to automatically switch to the headset audio path when enabled with AT$VSELECT=3. The device will default to handset when no Headset is detected. -
Page 60: Subscriber Identity Module (Sim) Carrier (Pins 76, 78, 80, 82, 84)
Note: The SIM is not provided with the Enfora Enabler IIIG module. The SIM must be obtained from the GSM service provider and must be provisioned by the operator for data and/or voice. -
Page 61: Figure 18 - Remote Sim Interface
Enfora Enabler IIIG M2M Modem Integration Guide <25.4 cm (10 in) Enabler IIIG Remote SIM module SIM_VDD Interface SIM_RST SIM_CLK SIM_DTC SIM_I/O Figure 18 - Remote SIM Interface Pin Name Pin Number Signal Direction Description SIM_VDD SIM VDD... -
Page 62: Remote Sim Component Information
Enfora Enabler IIIG M2M Modem Integration Guide USIM Parameter/Conditions Units SIM VDD voltage 1.65 1.95 2.85 2.95 High level input voltage 1.15 Low level input voltage 0.61 High level output voltage, IO = 4 mA Vdd-0.45 Low level output voltage, IO = 1 mA Input leakage current ±1... -
Page 63: Gsm/Gprs Modes Of Operation
The Enfora Enabler IIIG module has full voice capabilities, provided the necessary connections have been made for the speaker and microphone pins on the 100-pin I/O connector. The Enfora Enabler- IIIG AT Command Set Reference - GSM0308AT001 has the entire list of commands that can be used to control the voice functionality. -
Page 64: Sms: Short Message Services
Modem Integration Guide 7.4. SMS: Short Message Services • Short Message Services (SMS) is a feature-rich GSM service. The Enfora Enabler IIIG module can perform the following tasks: • Sending and receiving binary messages of up to 160 characters (7-bit characters) Sending and receiving text messages of up to 140 bytes (8-bit data) •... -
Page 65: Sim Operation
Mobile-terminated (MT): allows receiving a service request (such as, receiving a phone call or an SMS) It is imperative for the Enfora Enabler IIIG module that the SIM be configured for the optional services that are required for the application. -
Page 66: Selecting The Gsm Modes Of Operation
Enfora Enabler IIIG M2M Modem Integration Guide 8.4. Selecting the GSM Modes of Operation When provisioning the SIM for the Enfora Enabler IIIG module, enable the following modes of operation: • Voice calls: configure the SIM for both MO and MT service (to send and receive) SMS: configure the SIM either for MT alone (to receive) or for both MO and MT (to send and •... -
Page 67: Software Interface
Enfora GSM-GPRS Family API Reference GSM0308UG001. The AT command driver of the Enfora Enabler IIIG module never exits the Command state, that is, it never enters the On-line mode. Although the host interface may not be able to access the AT command interpreter, it is always running and is available via the API Mode over a PPP connection and/or via the RF interface. -
Page 68: Format For The At Commands
AT commands are not case sensitive: use either capital letters or lower-case letters for the AT command. Note: Some AT Command parameter values ARE case sensitive and are documented in the Enfora Enabler-IIIG AT Command Set Reference – GSM0308AT001. GSM0308IG002 Version 1.05 – 11/13/08 www.agelectronica.com... -
Page 69: Enfora At Command Set
Modem Integration Guide 9.3. Enfora AT Command Set For a full description of the AT commands, refer to the Enfora GSM0308AT001 - Enabler-III AT Command Set. Note: A command description that includes an *asterisk denotes that the GSM service provider must enable supplementary services functionality before the command is available. -
Page 70: Setup And Initialization
Enfora Enabler IIIG M2M Modem Integration Guide 10. Setup and Initialization 10.1. General Setup The GPRS modem is controlled through the Modem RS232 port on the development board. Connect a nine pin straight through serial cable from the Modem RS232 connector to the serial port on the controlling computer. -
Page 71: Initialization (At Command Interface)
In the following examples, “Entry” refers to the application. The following convention describes the direction of the data exchange: • The data exchange from the customer application to the Enfora Enabler IIIG module is designated as: Entry The data exchange from the Enfora Enabler IIIG module to the customer application is... -
Page 72: Initial Response To The At Command
Modem Integration Guide 10.1.3. Initial Response to the AT Command After power is applied to the Enfora Enabler IIIG module, the module performs a power-up self- test. The self-test completes within one (1) second. When queried with the AT command, the... -
Page 73: Setting Up The Communication Mode For The Enfora Enabler Iiig Module
Modem Integration Guide 10.1.5. Setting Up the Communication Mode for the Enfora Enabler IIIG Module The following example sequence provides the AT command and response for setting the Enfora Enabler IIIG module for full phone functionality, automated operator selection, 9600 baud, non- transparent mode. -
Page 74: Querying The Status Of The Enfora Enabler Iiig Module
This topic is addressed in the Enfora Application Note GSM0000AN007 - Enabler-G Status Reporting. 10.2. GSM/SMS Examples 10.2.1. Initialize the Enfora Enabler IIIG Module to Send and Receive SMS Text Messages This topic is addressed in the Enfora Application Note GSM0000AN004 - Enabler-G SMS Configuration and Use. 10.2.2. Managing SMS Messages This topic is addressed in the Enfora Application Note GSM0000AN004 - Enabler-G SMS Configuration and Use. -
Page 75: Integration And Testing
Modem Integration Guide 11. Integration and Testing The Enfora Enabler IIIG module has been designed to minimize the amount of time required for integration and testing the application. By being fully certified by the appropriate bodies, the Enfora Enabler IIIG module provides seamless integration into the GSM network. - Page 76 Filter the SIM VCC signal with a 10 uf / 10 V capacitor to help with the line length. Primary and The Enfora Enabler IIIG module uses a 1.8V digital interface. The RS-232 secondary serial signals must be level-shifted to get standard levels. These signals must be Interfaces ESD-protected.
-
Page 77: Appendix A - Limited Warranty
12.1. Scope Enfora warrants to the original purchaser of the product that, for a period of one (1) year from the date of product purchase, the product hardware, when used in conjunction with any associated software (including any firmware and applications) supplied by Enfora, will be free from defects in material or workmanship under normal operation. -
Page 78: Other Considerations
Exceptions and Disclaimers Enfora shall have no obligation under this limited warranty for (a) normal wear and tear, (b) the cost of procurement of substitute products or (c) any defect that is (i) discovered by purchaser during the... -
Page 79: Appendix B - Regulations And Compliance
13.2. Electromagnetic Compatibility (EMC) and Safety Requirements The Enfora Enabler IIIG module has been tested and approved for application in the United States of America (US) and the European Union (EU). The compliance details for each of these markets follow. For other markets, additional or alternative regulatory approvals may be required. Always ensure that all rules and regulations are complied with in every country that the OEM application is to be operated. -
Page 80: Human Exposure Compliance Statement
Regulations, including those that implement the National Environmental Policy Act of 1969 (Part 1, Subpart I), with specific regard to antenna sitting and human exposure to radio frequency radiation. For further guidance, consult the FCC Rules, a certified FCC test house, or Enfora. 13.5. -
Page 81: Unintentional Radiators , Part 15
Equipment designated as Class A is intended for use in a commercial, industrial or business environment. The Enfora Enabler IIIG module has been tested and found to comply with the limits for a Class A digital device and can be integrated into equipment or applications intended for use in commercial, industrial or business environments. -
Page 82: Instructions To The Original Equipment Manufacturer (Oem)
Both of these documents are available via the Internet at the OET web site: http://www.fcc.gov/oet The Enfora Enabler IIIG products are GSM radio transceivers, which operate under the authority of 47 CFR Part 24, Subpart E and Part 22 of the FCC Rules and Regulations. When installed and operated in accordance with the instructions provided in this manual, these devices comply with current FCC regulations regarding human exposure to radio frequency radiation. - Page 83 Enfora Enabler IIIG M2M Modem Integration Guide Note: Additional care must be taken by the installer and/or user of the Enfora Enabler IIIG products to ensure proper antenna selection and installation. Adherence to the above conditions is necessary to comply with FCC requirements for safe operation regarding exposure to RF radiation.
-
Page 84: Oem Responsibilities For All Products Containing The Enabler Iiig Module
For fixed applications (2 meter separation) the antenna gain can be as much as 26 dBi. radiation Modifications and/or additions to the Enfora Enabler IIIG GSM transceiver, including use of antennas with higher gain than those authorized by the FCC, are prohibited... -
Page 85: Specific Oem Responsibilities For Portable Products And Applications
Current FCC regulations limit the EIRP of mobile devices to 2 W. Because the nominal RF output power of the Enfora Enabler IIIG GSM1900 GSM transceiver is 1.0 W (31 dBm), antenna gain for mobile products and applications cannot exceed 2 dBi. -
Page 86: Emc/Safety Requirements For The Countries Of The European Union (Eu)
In most other countries that have not been listed above there are similar rules and regulations that must be met for importing the Enfora Enabler IIIG module. Each may require a different mark of approval (for example, the CB Scheme) as an acceptance requirement. For each of these cases the country should identified, and the appropriate steps should be taken to meet the requirements set forth in the intended market. -
Page 87: Appendix C - Glossary And Acronyms
Application Programming Interface. App Application Refers to the Application which sends or receives commands/responses from the Enfora Enabler IIIG Module AT Command Set Commands issued by intelligent device to a modem to perform functions, such as to initiate call, to answer call, or to transmit data. - Page 88 Enfora Enabler IIIG M2M Modem Integration Guide IMEI A unique number for each GSM Terminal tracked by the GSM operators in International Mobile their Equipment Identity Register (EIR) database. Equipment Identity IMSI A unique number identifying the subscriber stored in the SIM card. Number International Mobile is used in conjunction with the network for call routing.
-
Page 89: Appendix D - Tables And Figures
Enfora Enabler IIIG M2M Modem Integration Guide 15. APPENDIX D – Tables and Figures TABLES Table 1 - Enabler IIIG Key Features ......................10 Table 2 - Enabler IIIG Pin Assignments ...................... 32 FIGURES Figure 1 - Example of good ground plane for GSM modules ..............15 ... -
Page 90: Appendix E - Contacting Enfora
16. APPENDIX E - Contacting Enfora For technical support and customer service dealing with the modem itself, contact the company where you purchased the product. If you purchased the product directly from Enfora, visit the SUPPORT page on the Enfora website: http://www.enfora.com/support_newissue.asp...
