Summary of Contents for Enfora Enabler IIIE
- Page 1 SDK Guide EDG0308SD001 Enabler IIIE SDK Guide Revision 1.00 EDG0308IG001 Page 1 Rev. 1.00 – 04/08/2008...
- Page 2 All specifications are subject to change without notice and do not represent a commitment on the part of Enfora, Inc. Enfora, Inc. will not be responsible for any loss or damages incurred related to the use of information contained in this document.
- Page 3 The Enfora SDK (Software Developer’s Kit) is designed to allow Enfora partners to evaluate the Enfora Enabler III module and develop their own applications that will use the Enfora Enabler module. Quad Band GSM/GPRS Enabler Antenna Module SIM Holder J3D1 Current...
- Page 4 Switches and Jumpers Switch Functionality Default Position SW200 Turn modem power on from Off - Once a power supply power connectors J202 or has been applied to J202 or P200 P200 it may be placed in the on position to power on SDK and/or modem SW201 Momentary switch:...
- Page 5 The debug serial port (J502) is used for modem debugging and is for Enfora use only. There is no control of the modem through the debug serial port.
- Page 6 To use some features on the SDK, jumpers must be placed on the debug headers to link in the feature. Removal of the jumper will isolate the SDK feature from the module to allow for external circuitry to be added via the headers without interference from the SDK.
- Page 7 Configuring the Enfora module To communicate with, and configure the Enfora module, connect the serial connector of the SDK to the serial port of a PC. From a Windows PC, you can use HyperTerminal to configure the module. Please follow these instructions to correctly configure HyperTerminal: a.
- Page 8 5. In the Connect Using field, make sure the correct Com port is selected. 6. Click OK. 7. The next window is the Port Settings window. EDG0308IG001 Page 6 Rev. 1.00 – 06/26/2008...
- Page 9 8. Make sure the settings match the example. 9. Click OK. 10. Now the Main Program Window should appear. 11. Terminal Setup Testing. a. Make sure the cursor is in the main window. b. Type “AT” and press “Enter” c. You should see the modem respond back with “OK” in the Main Window d.
- Page 10 The SDK includes: The SDK Board and AC/DC “Wall-Pack” Power Supply. (Note: The AC/DC Adapter is only supplied in the United States.) There are optional accessories that you may need in addition to the Enfora module. Some examples of these accessories are listed below. Please contact your Enfora sales representative for specific part information, and ordering information.
