About Ondago Ondago At A Glance; Acomdata Ondago Features Explored; Firewire - Acomdata Ondago User Manual

A O
BOUT NDAGO
Ondago
at a Glance
Silicone Rubber Sleeve
Offers shock and water resistance.
Power/Data Indicator
Lights up blue when
the Drive is powered
on. Flashes red when
reading/writing data.
PushButton
Press to run PushButton™
Backups. Requires installation
of included software. See the Push-
Button Backup User's Guide.
Back Panel
Power Port
Used with the optional AC adapter
or the optional PS2/USB power
adapter (sold separately).
mini-USB Port
FireWire Ports
Two ports allow other FireWire devices
to be daisy-chained to the Drive.
– 14 –
AcomData Ondago
Features Explored
For a description of PushButton™ Backup, refer to the PushBut-
ton™ Backup User's Guide.

FireWire

FireWire is a serial data input/output technology developed
by Apple Computer and Texas Instruments. The first FireWire
standard was approved by the Institute of Electrical and
Electronic Engineers (IEEE) in 1995.
Data transfers at up to 400 Mbps (50 MB/s)
FireWire 400 can transmit data at up to 400 Mbps (50 MB/s).
FireWire supports both isochronous and asynchronous data
transfers. Isochronous mode provides guaranteed transmission
of data at defined intervals; it's used when delayed or out-
of-order data frames are unacceptable, such as for capturing
digital video. In asynchronous mode, the intervals between
transmissions can vary, and data can be resent if missed.
Asynchronous mode is used for routine data transfers.
Supports up to 63 devices
FireWire devices can be linked in a daisy-chain, where the
devices are connected to each other in series. A hub is only
required when a very large number of devices will share the
same FireWire bus. With the use of FireWire hubs, up to 63
devices can be linked on a single FireWire bus.
Peer-to-peer architecture
FireWire devices are host-independent, meaning data
transmissions between FireWire devices on the same bus
can take place without the need for input from the host
– 15 –
