10.0 Data sheet

Housing made of black plastic:
Dimensions [LxWxH
Degree of protection
Temperature
Air humidity
Printed circuit board dimensions
]
[LxWxH
Line voltage
Power limit
Quiescent current
Max. current
Programmable pulse width
Output relay type
Output relay continuous current
Output relay switch on current
Output relay switching voltage
Output relay switching capacity
Multifunction connections: F1, F2, F3
Vibrations
SmartRelay: SREL, SREL.ZK, SREL.ADV
]
72 x 57 x 25.5 mm
(approximately 2.8 x 2.2 x 1.0 inches)
IP 20 (NEMA1), not tested for outside use
Operation at: -31°F to +131°F
(-22°C to +55°C)
Storage at: 32°F to +104°F
(0°C to +40°C)
<95% without moisture condensation
50 x 50 x 14 mm
(approximately 2.0 x 2.0 x 0.6 inches)
12 VAC or 5-24 VDC
(no reverse voltage protection)
Power supply must be limited to 15 VA
< 5 mA
< 100 mA
0.1 to 25.5 seconds
Change-over
Max. 1.0 A
Max. 2.0 A
Max. 24 V
6
10 operations at 30 VA
Max. 24 VDC, max. 50mA
15G for 11 ms,
6 shocks according to IEC 68-2-27
Not released for continuous used under
Vibrations
