AUTOMATE
AC MECHANICAL LIMIT TUBULAR MOTOR
AUTOMATE
| mechanical limit AC motors come in 35mm and 45mm diameters with
™
various torque and speeds, including models with Quiet Operation. A "Slim Head" design
minimizes light gap.
FEATURES:
• Line Voltage (available for both 100V-120V & 220V-240V applications)
• "Slim Head" design minimizes light gap
• Low Operating Noise Levels.
• Mechanical Limits
™
MECHANICAL
LIMIT
OPERATION
QUIET

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AUTOMATE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for rollease acmeda AUTOMATE

Summary of Contents for rollease acmeda AUTOMATE

  • Page 1 AUTOMATE ™ AC MECHANICAL LIMIT TUBULAR MOTOR MECHANICAL QUIET LIMIT OPERATION AUTOMATE | mechanical limit AC motors come in 35mm and 45mm diameters with ™ various torque and speeds, including models with Quiet Operation. A “Slim Head” design minimizes light gap.
  • Page 2 NOTES 2 | Automate ROLLEASE ACMEDA Programming Instructions | AC Mechanical ™...

  • Page 3: Table Of Contents

    ADJUSTING LIMITS: REVERSE ROLL, LEFT MOUNT 5.1 Adjusting Upper Limit 5.2 Adjusting Lower Limit ADJUSTING LIMITS: REVERSE ROLL, RIGHT MOUNT 6.1 Adjust Upper Limit 6.2 Adjust lower limit TROUBLESHOOTING 3 | Automate ROLLEASE ACMEDA Programming Instructions | AC Mechanical ™...
  • Page 4 Keep antenna straight and clear from metal objects • Do not cut the antenna. • Use only Rollease Acmeda hardware. • Before installation, remove any unnecessary cords and disable any equipment not needed for powered operation. • Ensure torque and operating time is compatible with end application.

  • Page 5: Assembly

    ASSEMBLY Please refer to Rollease Acmeda System Assembly Manual for full assembly instructions relevant to the hardware system being used. Step 1. Cut roller tube to required length. Step 2. Ensure roller tube is clean and free from burrs. Step 3.

  • Page 6: Wiring

    Connect the motor according to the information in the table below. Range Neutral Live 1 Live 2 Earth 220-240V Blue Brown Black Yellow / Green 100-120V White Black Green Ensure cable is kept clear of fabric. 6 | Automate ROLLEASE ACMEDA Programming Instructions | AC Mechanical ™...

  • Page 7: Adjusting Limits: Front Roll, Left Mount

    To raise the limit, turn bottom adjuster To lower the limit, turn lower adjuster clockwise countercockwise towards the “+”. towards the “-”. Motor Response Motor Response Lower limit will raise. Lower limit will become lower. 7 | Automate ROLLEASE ACMEDA Programming Instructions | AC Mechanical ™...

  • Page 8: Adjusting Limits: Front Roll, Right Mount

    To raise the limit, turn upper adjuster To lower the limit, turn upper adjuster clockwise towards the “-”. counterclockwise towards the “+”. Motor Reponse Motor Reponse Lower limit will raise. Lower limit will become lower. 8 | Automate ROLLEASE ACMEDA Programming Instructions | AC Mechanical ™...

  • Page 9: Adjusting Limits: Reverse Roll, Left Mount

    To raise the limit, turn upper adjuster To lower the limit, turn upper adjuster counterclockwise towards the “+”. clockwise towards the “-”. Motor Response Motor Response Lower limit will raise Lower limit will become lower. 9 | Automate ROLLEASE ACMEDA Programming Instructions | AC Mechanical ™...

  • Page 10: Adjusting Limits: Reverse Roll, Right Mount

    To raise the limit, turn upper adjuster To lower the limit, turn upper adjuster counterclockwise towards the “+”. clockwise towards the “-”. Motor Response Motor Response Lower limit will raise. Lower limit will become lower. 10 | Automate ROLLEASE ACMEDA Programming Instructions | AC Mechanical ™...

  • Page 11: Troubleshooting

    TROUBLESHOOTING Problem Cause Remedy Check that wiring is connected Motor is not responding Incorrect wiring correctly (refer to motor installation instructions) 11 | Automate ROLLEASE ACMEDA Programming Instructions | AC Mechanical ™...
  • Page 12 T +1 203 964 1573 | F +1 203 964 0513 ROLLEASE ACMEDA EUROPE Via Conca Del Naviglio 18, Milan (Lombardia) Italy T +39 02 8982 7317 | F +39 02 8982 7317 info@rolleaseacmeda.com rolleaseacmeda.com 12 | Automate Programming Instructions | AC Mechanical ™...
