Related Manuals for DFI PIC-Q170
Summary of Contents for DFI PIC-Q170
- Page 1 PIC-Q170/H110 Full Size PICMG 1.3 User’s Manual Preliminary Version A51900852 Chapter 1 Introduction www.dfi .com...
-
Page 2: Copyright
Copyright FCC and DOC Statement on Class B This publication contains information that is protected by copyright. No part of it may be re- This equipment has been tested and found to comply with the limits for a Class B digital produced in any form or by any means or used to make any transformation/adaptation without device, pursuant to Part 15 of the FCC rules. -
Page 3: Table Of Contents
Table of Contents Audio Connector ..................23 Expansion Slot .................... 24 Copyright Battery ....................... 24 ......................2 Trademarks ......................2 FCC and DOC Statement on Class B ............. 2 Warranty ......................4 Static Electricity Precautions ..............4 Safety Measures ....................4 Before Using the System Board ............... -
Page 4: Warranty
Warranty Static Electricity Precautions 1. Warranty does not cover damages or failures that arised from misuse of the product, It is quite easy to inadvertently damage your PC, system board, components or devices even inability to use the product, unauthorized replacement or alteration of components and before installing them in your system unit. -
Page 5: Before Using The System Board
Before Using the System Board Before using the system board, prepare basic system components. If you are installing the system board in a new system, you will need at least the following internal components. • A CPU • Memory module •... -
Page 6: Chapter 1 - Introduction
1 x PCIe x16 Gen. 3 4 x PCIe x1 Gen. 3 4 x PCI 1 x M.2 M key 2280 (PCIe/SATA3.0) (Q170 only) ETHERNET Controller/ PIC-Q170: ® 1 x Intel I211AT PCIe (10/100/1000Mbps) 1 x Intel ® I219LM PCIe with iAMT11.6 (10/100/1000Mbps) (only Core i7/i5 supports iAMT) -
Page 7: Features
Chapter 1 • Wake-On-PS/2 Features This function allows you to use the PS/2 keyboard or PS/2 mouse to power-on the system. • Watchdog Timer • Wake-On-USB The Watchdog Timer function allows your application to regularly “clear” the system at the set time interval. -
Page 8: Chapter 2 - Hardware Installation
Chapter 2 Chapter 2 - Hardware Installation Board Layout LAN 1 Standby Power LED LGA 1151 Intel LAN 2 Buzzer DVI-D (opt.) I211AT SMBus Intel ASM1085 Flash Audio BIOS NCT6106D Chassis Q170/H110 Intrusion CPU FAN +12V Power M.2 M Key TPM 2.0 (Q170 only) USB 1... -
Page 9: System Memory
Chapter 2 The system board supports the following memory interface. Important: Electrostatic discharge (ESD) can damage your board, processor, disk drives, add-in Single Channel (SC) boards, and other components. Perform installation procedures at an ESD workstation only. If such a station is not available, you can provide some ESD protection by wear- Data will be accessed in chunks of 64 bits (8B) from the memory channels. -
Page 10: Installing The Dimm Module
Chapter 2 Installing the DIMM Module 6. Grasping the module by its edges, position the module above the socket with the “notch” in the module aligned with the “key” on the socket. The keying mechanism ensures the module can be plugged into the socket in only one Note: way. -
Page 11: Cpu
Chapter 2 Installing the CPU 1. Make sure the PC and all other peripheral devices connected to it has been powered down. The system board is equipped with a surface mount LGA 1151 socket. This socket is exclu- sively designed for installing a LGA 1151 packaged Intel CPU. 2. - Page 12 Chapter 2 Load lever 7. Insert the CPU into the 5. Lifting the load lever will at the same time lift the load socket. The gold triangular mark on the CPU must plate. align with the corner of Lift the load lever up to the CPU socket shown on the angle shown on the the photo.
-
Page 13: Installing The Fan And Heat Sink
Chapter 2 Installing the Fan and Heat Sink 8. Close the load plate then push the load lever down. The CPU must be kept cool by using a CPU fan with heat sink. Without sufficient air circula- While closing the load tion across the CPU and heat sink, the CPU will overheat damaging both the CPU and system plate, make sure the front board. -
Page 14: Jumper Setting
Chapter 2 Jumper Setting 4. Rotate each push-pin ac- cording to the direction of the arrow shown on top of Clear CMOS the pin. Push down two pushpins that are diagonally across the heat sink. Perform the same procedure for the other two push-pins. -
Page 15: Rare Panel I/O Ports
Chapter 2 Rear Panel I/O Ports VGA Port USB 1 USB 2 LAN 1 LAN 1 LAN 2 LAN 2 The rear panel I/O ports consist of the following: • 2 LAN ports • 1 VGA port • 2 USB 3.0 ports The VGA port is used for connecting a VGA monitor. -
Page 16: Usb Ports
The LAN ports allow the system board to connect to a local area network by means of a net- work hub. The PIC-Q170 is equipped with two onboard USB 3.0 ports (USB 1&2). The three 10-pin con- nectors allow you to connect 6 additional USB 2.0 ports (USB 1-2/3-4/5-6). The one 20-pin BIOS Setting connector allows you to connect 2 additional USB 3.0 ports (USB 3-4). -
Page 17: I/O Connectors
Chapter 2 I/O Connectors COM 1/2 COM (Serial) Ports RS232 RS422 Full Duplex RS485 DCD- TXD- DATA- TXD+ DATA+ RXD+ N.C. DTR- RXD- N.C. DSR- N.C. N.C. RTS- N.C. N.C. COM 4 DCD- SIN- COM 3 CTS- N.C. N.C. DTR- COM 2 DSR- N.C. -
Page 18: Digital I/O Connector
Chapter 2 Digital I/O Connector SATA (Serial ATA) Connectors Digital I/O SATA 1 SATA 3 SATA 2 SATA 0 SATA 3.0 6Gb/s Features • SATA 0, SATA 1, SATA 2 and SATA 3 support data transfer rate up to 6Gb/s The 8-bit Digital I/O connector provides powering-on function to external devices that are connected to these connectors. -
Page 19: Cooling Fan Connectors
Chapter 2 Cooling Fan Connectors Chassis Intrusion Connector Chassis CPU fan Intrusion System Fan 1 Ground Power Sense Ground Sense Power Signal Speed Control Ground The board supports the chassis intrusion detection function. Connect the chassis intrusion sensor cable from the chassis to this connector. When the system’s power is on and a chassis intrusion occurred, an alarm will sound. -
Page 20: Front Panel Connector
Chapter 2 Front Panel Connector LPT Connector PWR-LED ATX-SW The LPT port is for interfacing your PC to a parallel printer. It supports SPP, ECP and EPP. Allows normal speed operation but in one (Standard Parallel Port) direction only. HD-LED RESET Allows parallel port to operate in bidirectional HD-LED - HDD LED mode and at a speed faster than the SPP’s data... -
Page 21: Dvi-D Connector (Optional)
Chapter 2 DVI-D Connector (optional) KB/MS Connector KB/MS DVI-D MSCLK KBCLK MSDATA KBDATA The DVI-D connector is used to connect a digital LCD monitor or LCD TV. Connect the display KBMS POWER KBMS POWER device’s cable to the connector. BIOS Setting The Keyboard/Mouse connector is used to connect PS/2 keyboard and PS/2 mouse by means of a PS/2 cable. -
Page 22: Lpc Connector
Chapter 2 LPC Connector SMBus Connector SMBus SMB_Data SMB_Alert SMB_CLK 3V3DU The Low Pin Count Interface was defined by Intel ® Corporation to facilitate the industry’s tran- sition towards legacy free systems. It allows the integration of low-bandwidth legacy I/O com- ponents within the system, which are typically provided by a Super I/O controller. -
Page 23: Audio Connector
Chapter 2 12V Power Connector Audio Connector 12V Power Audio AUD LINK BCLK +12V Ground AUD LINK RST- AUD LINK SDI0 AUD LINK SDO AUD LINK SYNC The audio connector allows you to connect to the audio header on the board via the audio cable. -
Page 24: Expansion Slot
Chapter 2 Expansion Slot Battery Battery M.2 with PCIe/SATA 3.0 signals The lithium ion battery powers the real-time clock and CMOS memory. It is an auxiliary source of power when the main power is shut off. M.2 M Key 2280 Socket (Q170 only) Safety Measures The M.2 M key 2280 socket is the Next Generation Form Factor (NGFF) which is designed to support multiple modules and make the M.2 more suitable in application for solid-state stor-...
