SECTION 7: SERVICE

Review the troubleshooting and procedures in this section if a problem develops with your machine. If
you need replacement parts or additional help with a procedure, call our Technical Support. Note: Please
gather the serial number and manufacture date of your machine before calling.
Motor & Electrical
Symptom Possible Cause
Machine does not 1. OFF/STOP button not reset.
start or a breaker
2. Incorrect power supply voltage/circuit size.
trips immediately
3. Power supply circuit breaker tripped/fuse
after startup.
blown.
4. Motor wires connected incorrectly.
5. Wiring open/has high resistance.
6. ON button at fault.
7. Centrifugal switch at fault.
8. Start capacitor at fault.
9. Motor at fault.
Machine stalls or is 1. Workpiece material not suitable.
underpowered.
2. Excessive feed rate.
3. Excessive cutting depth.
4. Dull knives/inserts.
5. Dust collection problem, causing internal
components to clog up with shavings.
6. Belt slipping; oil/grease on belt.
7. Pulley loose or not properly aligned.
8. Motor overheated.
9. Motor wires connected incorrectly.
10. Plug/receptacle at fault.
11. Run capacitor at fault.
Machine has 1. Motor or other component loose.
vibration or noisy
operation.
2. Belt worn/loose; belt slapping cover.
3. Pulley loose or not properly aligned.
4. Motor fan rubbing on fan cover.
5. Foot-pedal caster engaged.
6. Knives/inserts at fault.
7. Cutterhead bearings at fault.
8. Centrifugal switch at fault.
9. Motor bearings at fault.
Model G0656W/G0656XW (Mfd. Since 08/16)

Troubleshooting

Possible Solution
1. Press OFF/STOP button in fully to reset switch.
2. Ensure correct power supply voltage/circuit size.
3. Ensure circuit is sized correctly and free of shorts.
Reset circuit breaker or replace fuse.
4. Correct motor wiring connections (Page 47).
5. Check/fix broken, disconnected, or corroded wires.
6. Test/replace switch.
7. Adjust/replace centrifugal switch if available.
8. Test/replace capacitor.
9. Test/repair/replace.
1. Ensure workpiece is suitable for jointing (Page 26).
2. Reduce feed rate.
3. Reduce cutting depth (Page 27).
4. Sharpen/replace knives; rotate/replace insert(s)
(Pages 39–41).
5. Clear blockages; move machine closer to dust
collector; upgrade dust collector.
6. Tension/replace belt (Page 46); clean belt; ensure
pulleys are aligned (Page 19).
7. Re-align pulleys; replace shaft key; tighten pulley
set screw.
8. Clean motor, let cool, and reduce depth of cut.
9. Correct motor wiring connections (Page 47).
10. Test for good contacts/correct wiring.
11. Test/repair/replace.
1. Replace damaged bolts/nuts; retighten loose bolts/
nuts. Use thread-locking fluid if condition repeats.
2. Tension/replace belt (Page 46).
3. Re-align pulleys; replace shaft key; tighten pulley
set screw.
4. Fix/replace fan cover; replace loose/damaged fan.
5. Release foot-pedal caster to stabilize machine.
6. Sharpen/replace knives; set knife alignment/height
correctly; rotate/replace inserts (Pages 39–41).
7. Replace bearing(s)/realign cutterhead.
8. Replace.
9. Test by rotating shaft; rotational grinding/loose shaft
requires bearing replacement.
