Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901

Product Dimensions:

Weight.............................................................................................................................................................. 231 lbs.
Length/Width/Height................................................................................................................. 46 x 21-1/4 x 37-3/4 in.
Foot Print (Length/Width)................................................................................................................ 17-1/8 x 14-1/8 in.

Shipping Dimensions:

Type............................................................................................................................................................. Cardboard
Content............................................................................................................................................................ Machine
Weight.............................................................................................................................................................. 240 lbs.
Length/Width/Height................................................................................................................. 48-5/8 x 21 x 15-1/2 in.

Electrical:

Switch............................................................................................................ Push Button with Oversized OFF Button
Switch Voltage...................................................................................................................................................... 110V
Cord Length............................................................................................................................................................ 8 ft.
Cord Gauge....................................................................................................................................................14 guage
Minimum Circuit Size........................................................................................................................................ 20 amp
Plug Included.......................................................................................................................................................... Yes

Motors:

Main
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower.................................................................................................................................................1 HP
Voltage........................................................................................................................................................110V
Prewired......................................................................................................................................................110V
Phase........................................................................................................................................................ Single
Amps.............................................................................................................................................................14A
Speed.................................................................................................................................................3450 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ............................................................................................................................... V-Belt Drive
Bearings....................................................................................................................... Shielded and Lubricated

Main Specifications:

Fence Information
Fence Length....................................................................................................................................... 29-3/8 in.
Fence Width......................................................................................................................................... 1-3/16 in.
Fence Height..........................................................................................................................................4-1/2 in.
Fence Stops........................................................................................................................ 45, 90 and 135 deg.

Cutting Capacities

Bevel Jointing...................................................................................................................... Left & Right 45 deg.
Maximum Width of Cut................................................................................................................................. 6 in.
Maximum Depth of Cut..............................................................................................................................1/8 in.
Maximum Rabbeting Depth.......................................................................................................................1/2 in.
Number of Cuts Per Minute.......................................................................................................................14400
The information contained herein is deemed accurate as of 10/7/2008 and represents our most recent product specifications.
Model G0654
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
MODEL G0654 6" X 46" JOINTER
MACHINE DATA
SHEET
PAGE 1 OF 2
