- Page 1 We would like to thank you for choosing the motoimmobilizer and wish you many pleasant and safe drives! Revision No. 3 April 2017...
-
Page 2: Table Of Contents
Motoimmobilizer StarLine V66 Content General description ................3 Operation description ................6 Operation modes....................7 Security modes ..................... 9 Security mode switchover ....................9 Security activation ......................10 Security activation without tag ...................11 Simultaneous work with several tags (smartphones) ........12 Additional modes ....................12 Check of communication between tag and main unit ........ -
Page 3: General Description
Please read this instruction paying special attention to the sections ATTENTION! marked The StarLine V66 motoimmobilizer is intended for motor vehicle theft protection by engine blocking and alerting of the nearby people of security zone violation by sound and light signals. - Page 4 Motoimmobilizer StarLine V66 Advantages of StarLine V66: • the small dimensions of the main unit allow installing it in a place hard to reach for malefactors; • the sealed housing protects against the aggressive ambient impact; • the magnetic contact ensures reliable protection of the trunk;...
- Page 5 manual instruction The immobilizer delivery set includes a plastic card containing the following data: • Service code. It is intended for setting and programming of immobilizer parameters. The service code is provided in the open form. • Code of emergency security deactivation. Allows for driving the motorcycle in case of battery discharge or tag loss.
-
Page 6: Operation Description
Motoimmobilizer StarLine V66 Operation description For owner authorization, you should always carry along the tag (smartphone), because the immobilizer has two-level authorization: by presence of the tag (smartphone) and by a programmed event. ATTENTION! Presence of the tag (smartphone) does not deactivate the system security by itself, and the engine will be blocked in case of attempt at starting. -
Page 7: Operation Modes
• possibility of temporary switch-off of the shock sensor in the security mode; • indication of the current operation mode on the tag. Operation modes The StarLine V66 motoimmobilizer has the following structure of operation modes: Security on Security modes... - Page 8 Motoimmobilizer StarLine V66 The main differences between the modes are given in the table. Security modes Parameter security on without security on security off shock sensor according to the Indication selected security on the tag mode Entry tag+clutch* (brake) tag+clutch* (brake)
-
Page 9: Security Modes
manual instruction Security modes The immobilizer monitors the following security zones in the security modes: • motorcycle movement (movement sensor and tilt sensor); • reaction to shocks and jerks (two-level shock sensor); • motorcycle trunk state (magnetic contact); • ignition (monitoring of ignition switch-on input); • engine start (built-in blocking relay);... -
Page 10: Security Activation
Motoimmobilizer StarLine V66 Security activation Security activation and deactivation are possible by several methods: • Pressing on the clutch* (brake) handle with ignition switched-off in the tag presence; • Short pressing on the tag button near the motorcycle with ignition off;... -
Page 11: Security Activation Without Tag
manual instruction Security activation without tag In tag absence, security can be activated by the following method: 1) Switch on the ignition. 2) Hold the clutch* (brake) handle for 5 seconds. 3) A flash of light signals will follow. Release the clutch handle. -
Page 12: Simultaneous Work With Several Tags (Smartphones)
5 seconds. Mode “Telematic setting and software update” is intended for convenient setting and update of the immobilizer software by means of a computer. For this use the “StarLine Master” application. * Programmed by the installation specialist during mounting... -
Page 13: Check Of Communication Between Tag And Main Unit
manual instruction “Parameter programming” mode is intended for setting of immobilizer parameters by means of the tag. Transition to the “Parameter programming” mode is performed only from the mode “Security off”. “Device registration” mode is used for adding new devices (for instance, tag, smartphone). -
Page 14: Motoimmobilizer Light And Sound Indication
Motoimmobilizer StarLine V66 Motoimmobilizer light and sound indication Motorcycle light Event Siren sound signals signals “Security on” mode Mode “Security on without shock sensor” Service mode 1 – with trunk closed 1 – with trunk closed Security activation 4 – with trunk opened 4 –... -
Page 15: Change Of The Security Deactivation Code
manual instruction ATTENTION! If a tag or smartphone is present in the coverage range, the shock, tilt and movement sensors are switched off, is absent – switched on. ATTENTION! After security activation the maximum number of alarm activations is limited to 8 repetitions. Change of the security deactivation code Do as follows to change the code of security deactivation:... -
Page 16: Entry In The "Parameter Programming" Mode
Motoimmobilizer StarLine V66 1) Entry in the “Parameter programming” mode 1) Set the immobilizer to the “Security off” mode. 2) Press and hold the motorcycle clutch* (brake) handle for 5 seconds. 3) The marker lights will light up for 3 seconds. -
Page 17: Change Of The Security Deactivation Code
manual instruction 2) Change of the security deactivation code 1) 1) Make sure the tag LED is illuminated green. Press the tag button shortly while the LED is illuminated. A short green flash will follow. The LED color will change to red. 2) Press the tag button the number of times corresponding to the first digit of the current security deactivation code. - Page 18 Motoimmobilizer StarLine V66 6) Press the tag button the number of times corresponding to the first digit of the new security deactivation code. 7) Check presence of red sound signals corresponding to the number of pressings. 8) Enter the other digits of the new security deactivation code similarly to items 6-7.
-
Page 19: Device Registration
manual instruction Device registration Use the “Device registration” mode for registration of new components. To prevent unauthorized adding of new components, entry in the “Device registration” mode is possible only from the “Security off” mode. All the components should be registered in one cycle. In total, up to three devices can be registered in the system. - Page 20 Motoimmobilizer StarLine V66 3) Press the clutch* (brake) handle 7 times. 4) Switch on ignition and monitor presence of 7 light and sound confirmation signals. Exit from the “Device registration” mode is performed by ignition switch-off.
-
Page 21: Tag Registration
manual instruction Tag registration Switch over the immobilizer to the “Device registration” mode and do as follows: 1) Remove the batteries from the tag. 2) Press and hold the tag button and install the battery. The tag LED will light up red. 3) Release the button and check presence of a series of red flashes for 10 seconds. -
Page 22: Smartphone Registration
Motoimmobilizer StarLine V66 Smartphone registration The smartphone is registered in the system using the StarLine mobile application. As you exit from the mode, sound signals will follow, corresponding to the number of registered tags and smartphones. Discharge of the tag battery 6 sound signals at the time of security deactivation mean that the tag battery is discharged. -
Page 23: Emergency Security Deactivation
manual instruction Emergency security deactivation If the tag was lost or the tag battery is discharged, the alarm will be activated at ignition switch-on and the motorcycle engine will be blocked. To deactivate immobilizer security, enter the code of security deactivation given on the plastic card, by means of the clutch* (brake). - Page 24 Example of entry of the security deactivation code 5342. The manufacturer reserves the right to change the design and elements without prior notification Manufacturer: Limited Liability Company “Scientific and Production Association “StarLine” (LLC “SPA “StarLine”) 194044, Russia, Saint Petersburg, 9 Komissara Smirnova Str. 9, letter A, office 204...
