Summary of Contents for Starline S96
- Page 1 BT GSM-GPS PRO StarLine S6 ECO StarLine S6 BT ECO StarLine S6 StarLine S9 ECO StarLine S9 BT ECO StarLine S9 ECO GPS StarLine S9 BT ECO GSM StarLine S9 BT ECO GPS StarLine S9 StarLine S9 GPS StarLine S9 GSM-GPS StarLine S9 PRO StarLine S9 GPS PRO StarLine S9 GSM-GPS PRO...
- Page 2 User manual...
- Page 3 User manual Safety measures during the operation of the security system Prior to operation of the security complex carefully read this manual paying special attention to the Screenshot 2023-11-28 163123.png sections marked ( ) and determine whether this Image not found or type unknown security complex is suitable for your car, for which following the car manufacturer’s requirements and the car operation manual.
- Page 4 The service life of the security system is 5 years, provided that the product is installed and operated in accordance with operating instructions, installation and wiring diagram. If your security complex has a remote key or a wireless tag: Do not carry the remote key or tag on the same bundle with the car keys Always switch over the complex to the service mode when handing the car over for maintenance or washing.
-
Page 5: Safety Precautions During Charging Of Your Car's Storage Battery
Safety precautions during charging of your car’s storage battery Remember that any battery charging process implies supply of voltage exceeding the rated 12 V to the storage battery and accordingly to the car circuit, which may damage the car electronic equipment and additional installed equipment in your car. -
Page 7: General Description
Use the tag or a smartphone supporting the BLE protocol and registered in the complex using the StarLine mobile application for authorization. The complex is controlled by SMS commands, voice menu, wireless tag, from the StarLine mobile application or from the personal account on the website starline.online. To enter the personal account use the login and password given on the owner’s plastic card included in the delivery set. - Page 8 It is used for emergency security deactivation. Service code — the code is given on the owner’s plastic card. It is used for entry in the StarLine Master application. ATTENTION! Do not tell the code of emergency security deactivation to anybody! Remember that a malefactor, knowing the code, may deactivate the protective functions.
- Page 9 2 level — press and hold the tag button, followed by two short flashes and one long one, and again a series of short flashes — release the button. Command Duration of pressing Arm / Disarm 1 short Enable / Disable «Anti-hijack by the tag» long (1 level) Enable / Disable Service mode long (2 level)
-
Page 10: Specifications
Radio exchange protocol Bluetooth Smart Interfaces • 2 CAN • 2 LIN • 1 universal code bus StarLine Bus • 1 USB • 18 reconfigurable channels: • 17 outputs of OC (open collector) ОК –0,2А • 2 outputs 2А • 3 positive inputs •... -
Page 11: Light And Sound Indication
User manual Light and sound indication The security complex informs about its status by means of sound (horn) and light signals (turn signals): icon-short.png — short signal; Image not found or type unknown icon-long.png — long signal. Image not found or type unknown Event Light signals Horn... -
Page 13: Operation Modes
User manual Operation modes Security modes Security on Security off Alarm Panic Additional modes «Slave» Hands free Service mode Device registration mode Telematic setting mode The security modes protect the car against theft. The additional modes are intended for setting of the complex parameters (telematic setting mode), adding of new devices (device registration mode), deactivation of protective functions for car handover for maintenance (service mode) and convenient complex control («Slave»... - Page 14 11 from the voice menu; from the StarLine mobile application; from the personal account on the website starline.online; by activation of standard system security in the «Slave» mode; in case of tag loss or touch of the door handle sensor in the «Hands free» mode;...
-
Page 15: Alarm Mode
31 from the voice menu; from the StarLine mobile application; from the personal account on the website starline.online. Upon command reception the complex will issue warning signals of upcoming engine blocking by the horn and light emergency alarm for 30 seconds. At speed decrease below 30 km/h the engine will be blocked. -
Page 16: Slave Mode
card. - Page 17 51 from the voice menu; from the StarLine mobile application; from the personal account on the website starline.online. Switchover to the service mode will be confirmed by yellow indication of the tag LED. In the service mode, transition to the other additional modes is prohibited! Exit from the service mode is performed by one of the following methods: holding of the tag button for 5 seconds;...
- Page 18 Engine starting at engine temperature decrease below the specified value. The temperature value is set in the StarLine application or in the personal account on the website starline.online; according to value of storage battery voltage. Engine starting at storage battery voltage decrease.
- Page 19 Engine starting with the preset operation period after the preset recurrent time interval. The interval and period are set in the StarLine application or the personal account on the website starline.online; by alarm clock. Engine starting at the preset time.
- Page 20 Time of preheater operation in this mode is 20 minutes. It can be changed in the personal account on the website starline.online or in the StarLine mobile application. If the starting preheater has normal settings, differing from those set in the personal account, operation time may differ from the specified one.
- Page 21 Operation time and switch-off temperature threshold of the starting preheater can be changed in the personal account on the website starline.online or in the StarLine mobile application. Function «Turbotimer» Use the function «Turbotimer» for turbocharged cars for engine turbine cooling.
- Page 22 The maximum turbine cooldown time is 5 minutes.
-
Page 23: Gsm Control Commands
User manual GSM control commands Complex control by means of GSM commands is only possible if the GSM module is available. The telephone number, from which the first call to the complex number was made, will be recorded automatically as the owner’s main number. All commands from this number are sent without a GSM-password. - Page 24 SMS command text Command meaning Switch on of the starting pre-start engine heater 30 XXXX Deactivation of the «Anti hijack» mode, where хххх is the code of emergency security deactivation is given on the owner’s plastic card A-XXXX Activation of «Anti hijack» mode Car coordinate request Car state request AUTO...
-
Page 25: Change Settings
User manual Change settings Change of user settings is available in the personal account on the website starline.online. image.png Image not found or type unknown... -
Page 26: Registration Of Tags And Smartphones
User manual Registration of tags and smartphones Use the «Device registration» mode for registration of new tags and smartphones. To prevent unauthorized adding of new components, entry in the device registration mode is possible only from the «Security off» mode. Tags and smartphones shall be registered in one cycle. - Page 27 Image not found or type unknown 5. Repeat items 1-3 for the remaining tags. Smartphone registration Register the smartphone using the StarLine mobile application (see the application menu «Smartphone as a tag»). image.png Image not found or type unknown Exit from the device registration mode Exit from the device registration mode is performed automatically in 5 minutes or at ignition...
- Page 28 Registration of StarLine R4 code relay If the code relay StarLine R4 was purchased separately, it must be registered in the memory of the main unit, having first connected it according to the instruction: 1. Disarm the security system. Turn off the ignition if it was on.
-
Page 29: Emergency Security Deactivation
User manual Emergency security deactivation If the tag was lost, the tag battery has discharged, there is no access to the mobile application or the «Anti hijack» mode is on, use the code of emergency security deactivation given on the plastic card. -
Page 31: Change Of Owner Authorization Code
The owner authorization code consists of a code sequence, containing from 5 to 30 pressings of the standard buttons. The list of standard buttons supported by the car is given on the website can.starline.ru If a light signal does not follow after pressing of a standard button, the button is not supported in the given car. - Page 32 10. Exit from the registration mode will be confirmed by 2 light signals of the LED on the service button and by signals the number whereof corresponds to the total number of registered tags and smartphones.
- Page 33 User manual Owner authorization code This section is completed by an installer...
-
Page 34: Connection Diagram
Connection diagram image.png Image not found or type unknown image.png Image not found or type unknown... - Page 35 Installiation manual An installiation manual is available at the link(to do). The connection diagram is available in the current instructions on the ‘Connection Diagram’ page.
- Page 36 Software All descriptions of software versions for the main unit, remote keys, and tags are available at the link: Software(to do)
