- Page 1 StarLine S96v2, S9v2, E96v2 GSM User manual Safety precautions for operating the Security System General Description Technical Specifications Light and sound indication Controlling the system using a remote key Controlling the System using a Wireless Tag (Transponder) Operating Modes GSM control commands...
- Page 2 User manual...
- Page 3 User manual Safety precautions for operating the Security System Please read carefully! Before operating the security system, carefully read this manual and pay special attention to Screenshot 2023-11-28 163123.png sections marked with an exclamation point . In Image not found or type unknown order to check whether this security system is suitable for your car, refer to the vehicle manufacturer's requirements and operating instructions.
- Page 4 The service life of the security system is 5 years provided that the product is installed and operated in accordance with the operating instructions, installation guidelines, and wiring diagram. If your security system includes a remote key or wireless tag(transponder): Do not carry a remote key or tag on the same keychain with your car keys.
- Page 5 Safety Precautions When Charging Your Vehicle's Battery Keep in mind that any battery charging process involves supplying a voltage higher than the nominal 12V to the battery and, consequently, to the vehicle's electrical system. This can damage the vehicle's electronic equipment and any additional equipment installed on your vehicle. Do not use battery chargers or jump-start devices to charge the battery directly on the vehicle without disconnecting the battery terminals from the vehicle's electrical system in the following modes:...
-
Page 6: General Description
Global Positioning System (GPS) satellites. Depending on delivery set, the system can be controlled using a remote key, SMS commands, voice menu, wireless tag, the StarLine mobile application, or through the personal account on the starline.online website. - Page 7 Emergency Disarm Code: Intended for emergency deactivation of the security system. Login and Password: Used for logging into the personal account on the starline.online website and in the StarLine mobile application. Complex Phone Number: The phone number of the SIM chip integrated into the security complex.
-
Page 8: Technical Specifications
-148 dBm (Cold Start) -163 dBm (Hot Start) -165 dBm (Tracking Mode) Interfaces 2 CAN 4 LIN 1 Universal StarLine Bus 1 USB 16 Configurable Channels: 15 Outputs (0.2 A) 2 Outputs (2 A) 3 Positive Inputs 3 Negative Inputs... -
Page 9: Light And Sound Indication
User manual Light and sound indication The security system provides various options for indicating modes such as "Disarmed", "Armed", and "Alarm": Hidden: Light and sound indicators are disabled. Silent: Only light indicators are enabled. Sound: Only sound indicators are enabled. Full: Both light and sound indicators are enabled. -
Page 10: Led Indicator
icon-short.png icon-short.png Image not found or type unknown Image not found or type unknown Disarming (one of the zones was icon-short.png Image not found or type unknown violated in the security cycle) icon-short.png Image not found or type unknown icon-short.png icon-short.png Image not found or type unknown... - Page 11 Event Sound Indicator Waiting for Authorization 10 seconds icon-short.png icon-short.png icon-short.png Image not found or type unknown Image not found or type unknown Image not found or type unkno Remote Key Battery Low (when ignition is turned on) icon-short.png icon-short.png Successful Owner Authorization Code Input Image not found or type unknown Image not found or type unknown...
-
Page 12: Remote Key
User manual Controlling the system using a remote key The presence of a remote key depends on the delivery set of the security system. Remote Key 2-way remote key with LCD (liquid crystal display). image.png image.png Image not found or type unknown Image not found or type unknown The remote key with LCD uses a AAA 1.5 V battery. -
Page 13: Security Zones
Автомобиль под охраной _ 2.png Image not found or type unknown Armed Режим «Свободные руки».png Image not found or type unknown "Hands-Free" mode Сервисный режим.png Image not found or type unknown Service mode Режим настроек и программирования.png Image not found or type unknown Programming mode button lock.png Remote key's button lock... -
Page 14: Additional Information
Сработал тревожный уровень датчика удара.png Image not found or type unknown Alarm level of shock sensor triggered Датчик удара отключен.png Image not found or type unknown Shock sensor disabled Additional Information Icon Meaning Передача данных_2.png Image not found or type unknown Data Transmission Замените... - Page 15 Long Press Pressing and holding a button or two buttons until a melodic sound signal and vibration signal appear. Two levels of long press are provided: First-level long press — pressing a button until the first sound signal. Examples: icon-long-1.png Image not found or type unknown icon-note-1.png Image not found or type unknown...
- Page 16 icon-short-3.png Request vehicle statuses (engine and cabin temperature, Image not found or type unknown battery voltage, fuel level). During remote engine start - remaining engine runtime. icon-long-1.png icon-note-1.png Image not found or type unknown Image not found or type unknown Start engine icon-long-2.png icon-note-1.png...
-
Page 17: Configuration Menu
icon-long-3.png icon-note-1.png Image not found or type unknown Image not found or type unknown Activate sound profile 2 icon-short-1.png Image not found or type unknown icon-long-3.png icon-note-1.png Image not found or type unknown Image not found or type unknown Activate sound profile 1 icon-short-2.png Image not found or type unknown icon-long-3.png... -
Page 18: Settings Menu
Включен автоматический запуск по будильнику.jpg Image not found or type unknown A utomatic engine start and Set the hours and minutes 1 minute preheater start by timer for engine start. Switching between engine and preheater start settings is done by short pressing buttons 1_2.png Image not found or type unknown 3_4.png... - Page 19 To set the time zone, select the 1 item in the settings menu. Then, using buttons icon-short-2.png and icon-short-3.png set the desired value. The minimum step size is 1 Image not found or type unknown Image not found or type unknown hour.
- Page 20 To adjust the motion sensor sensitivity level, select the 6 item in the settings menu. Then, using buttons icon-short-2.png and icon-short-3.png , set the desired value from 0 to 30. Image not found or type unknown Image not found or type unknown 0 —...
- Page 21 To set the range of the tag detection zone, select the 11 item in the settings menu. Then, using buttons icon-short-2.png and icon-short-3.png , set the desired value from 1 to 8. Image not found or type unknown Image not found or type unknown 1 —...
- Page 22 To set the parking heater activation before remote engine start, select the 18 item in the settings menu. Then, using buttons icon-short-2.png and icon-short-3.png , set the desired value Image not found or type unknown Image not found or type unknown 0 or 1.
- Page 23 № Profile Name Button Combination Description icon-long-3.png SOUND 2 Image not found or type unknown Maximum volume with all icon-note-1.png Image not found or type unknown signals, vibration signal icon-short-1.png Image not found or type unknown enabled. icon-long-3.png SOUND1 Image not found or type unknown Minimum volume with all icon-note-1.png Image not found or type unknown...
- Page 24 — off; 4 — Volume Adjustment Indication for Alarm Signals. Volume adjustment is done by short pressing the buttons icon-short-2.png Image not found or type unknown icon-short-3.png , respectively. A short press of the button icon-short-4.png enables or Image not found or type unknown Image not found or type unknown disables the vibration signal.
-
Page 25: Setting Time And Date
Selecting a Sound Theme In the sound profile menu, you can also set the tone of the remote key's sound signals by selecting one of the sound themes. To select a sound theme, follow these steps: 1. Enter the sound profile menu by performing a second-level long press on button 3: icon-long-3.png icon-note-2.png Image not found or type unknown... - Page 26 image.png image.png Image not found or type unknown Image not found or type unknown 1 — Day; 2 — Month; 3 — Year. icon-short-2.png 4. Use a short press of button to set the current day, a short press of Image not found or type unknown icon-short-3.png button...
-
Page 27: Checking Connection
User manual Controlling the System using a Wireless Tag (Transponder) Additional Bluetooth remote tags (hereafter referred to as the tag), included in the package, are initially in transport mode, in which they are disabled. Pressing the tag button in this mode will be indicated by green, red, and yellow flashes of the built-in LED. -
Page 28: Replacing The Battery
Short press — press and release the button, followed by a flash corresponding to the current operating mode. Long press — hold the button until LED flashes appear. The duration of the press can be of two levels: First-level long press — press and hold the button until two short flashes of the current operating mode followed by one long flash, during which the button should be released. -
Page 29: Operating Modes
User manual Operating Modes Security modes Armed Disarmed Anti-hijack Alarm Panic Additional modes «Slave» Hands-Free Service mode Device registration Configuration Security modes provide protection for the vehicle against theft. Additional modes are intended for adding new devices ("Device Registration" mode), disabling security functions for vehicle servicing ("Service Mode"), and convenient system control ("Slave"... -
Page 30: Silent Arming
SMS command Voice menu command 11 ; Via the StarLine mobile app; Through the personal account on the starline.online website; By activating the standard security system ("Slave" mode); When the tag is lost or the door handle sensor is touched in "Hands-Free" mode By pressing the tag button once in "Disarmed"... - Page 31 If the tag or remote key battery is dead, and there is no access to the starline.online personal account and StarLine mobile app, use emergency arming: 1. Press the service button or the transceiver button 3 times. 2. Turn on the ignition. Three sound signals will follow.
- Page 32 When the set speed threshold is exceeded Enabling, disabling, and configuring the "Central Locking During Travel" function is available in the personal account on the starline.online website (Settings → Main Parameters → Central Lock Control). Central Lock Unlocking During Travel...
-
Page 33: Alarm Mode
When the handbrake is engaged Enabling, disabling, and configuring the "Central Lock Unlocking During Travel" function is available in the personal account on the starline.online website (Settings → Main Parameters → Central Lock Control). Trunk Unlocking in Armed Mode Function This function allows the trunk to be opened with the standard vehicle remote key without disarming the system, provided that the tag and/or the system's remote key is within range. -
Page 34: Panic Mode
Notification options can be configured in the personal account on the starline.online website (Settings → Main Parameters → Light and Siren Control): Sound notification with siren and hazard lights Notification with hazard lights only No light or sound indication By default, sound notification with siren and hazard lights is enabled. - Page 35 To enable the "Anti-Hijack" mode by owner’s command, go to the personal account on the starline.online website (Settings → Main Parameters → Anti-Hijack by Tag Loss → Uncheck the boxes) or in the StarLine mobile application (Settings → Advanced Settings → Main Parameters → Anti-Hijack by Tag Loss → Uncheck the boxes).
-
Page 36: Slave Mode
By entering the emergency disarm code specified on the plastic card or pin envelope of the owner using the service button or transceiver button From the personal account on the starline.online website. The emergency disarm code specified on the plastic card or pin envelope of the owner needs to be entered. -
Page 37: Hands-Free Mode
Disabling the alarm by touching the door handle sensor (purchased separately) with the tag in sight The detection zone and loss are adjusted in the personal account on the starline.online website (Settings → Main Parameters → Hands-Free). By default, the tag's operating range is set to the maximum value. - Page 38 In the "Hands-Free" mode, automatic arming will not be executed if the tag is within sight. The parameters of the "Hands-Free" mode can be adjusted in the personal account on the starline.online website (Settings → Main Parameters → Hands-Free). Disabling "Hands-Free" Mode for 1 Security Cycle If the tag remains within range during parking (for example, you're in a cafe while your car is parked nearby), it is recommended to disable the security deactivation in "Hands-Free"...
-
Page 39: Service (Valet) Mode
Activation of the "Anti-Hijacking" mode by tag or key fob loss; Main unit calibration procedure; "CAN Information" section in the personal account on the starline.online website or in the StarLine mobile app. Entering Service Mode can be done using one of the following methods: Selecting the corresponding item in the tag cursor menu;... -
Page 40: Immobilizer Mode
By SMS command By voice menu command Via the StarLine mobile app; Through the personal account on the starline.online website. By entering the emergency disarm code. Entering Service Mode will be confirmed by a yellow LED indication on the tag. In Service Mode, transition to other additional modes is prohibited! -
Page 41: Engine Start
Requests can be made by the owner with a short press of the key fob button icon-short-3.png Image not found or type unknown or by sending SMS command When using the key fob, the information will be displayed on its screen, while SMS requests will receive a response SMS message. - Page 42 The minimum engine runtime for remote start is 10 minutes. This can be adjusted in the starline.online website personal account or the StarLine mobile app. Automatic engine start will not occur if less than 1 hour has passed since the last start or if the previous automatic start failed.
-
Page 43: Manual Mode
The "Alarm" mode is activated. The vehicle starts moving. The hood is opened. The parking brake is released (for MT vehicles). The AT selector is shifted out of the "Park" position (for AT vehicles). The brake pedal is pressed. The engine reaches the maximum temperature threshold specified during the security system setup to protect the engine from overheating. -
Page 44: Automatic Mode
Image not found or type unknown by SMS-command Via the StarLine mobile app; Through the personal account on the starline.online website. The preheater operates for 20 minutes in this mode. To change its duration, consult your installation specialist. If the preheater has factory settings different from those set by the installation specialist, the operating time may differ from the specified time. - Page 45 The operating time and temperature threshold for preheater disconnection can be changed in the personal account on the starline.online website or in the StarLine mobile app. «Intelligent turbotimer» function For vehicles with turbochargers, use the "Turbotimer" function to cool the engine turbine.
-
Page 46: Beach Mode
Owner authorization is achieved by entering the emergency disarm code by touching the door handle with a capacitive sensor StarLine ES-1 (optional). In this mode, the system does not respond to key fob commands. - Page 47 It is also possible to activate the video recorder for 5 minutes using SMS command 69 . If the engine is started when the "Armed" mode is activated, the video recorder will continue to operate until the engine is stopped. Risky parking mode Use this mode when parking in areas with a high risk of theft.
-
Page 48: Gsm Control Commands
The system provides notifications via phone calls and SMS messages for various events (alarm activation, SIM card balance decrease, battery discharge, etc.). Notification settings can be adjusted in the personal account on the website starline.online (Settings → Telematics → Notification Settings/Additional Notifications via SMS). Voice menu commands... - Page 49 image.png image.png image.png 0 Listen commands Image not found or type unknown Image not found or type unknown Image not found or type unkn menu image.png image.png image.png 10 Disarming Image not found or type unknown Image not found or type unknown Image not found or type unkn image.png image.png...
-
Page 50: Sms Commands List
image.png image.png image.png 70 Disable Hands-Free Image not found or type unknown Image not found or type unknown Image not found or type unkn image.png image.png image.png 71 Enable Hands-Free Image not found or type unknown Image not found or type unknown Image not found or type unkn Voice call commands Voice menu... - Page 51 image.png image.png image.png 111 Silent arming Image not found or type unknown Image not found or type unknown Image not found or type unkn image.png image.png image.png 12 Arming with shock Image not found or type unknown Image not found or type unknown Image not found or type unkn sensors disabled image.png...
- Page 52 image.png image.png image.png 221 Start engine Image not found or type unknown Image not found or type unknown Image not found or type unkn preheater image.png image.png image.png 40 Request location Image not found or type unknown Image not found or type unknown Image not found or type unkn GPS ...
- Page 53 image.png image.png image.png 51 Enable Service mode Image not found or type unknown Image not found or type unknown Image not found or type unkn S+ image.png image.png image.png 69 Activate video Image not found or type unknown Image not found or type unknown Image not found or type unkn recorde VIDEOREG ...
-
Page 54: Info Commands
image.png image.png image.png SETTING- Exit configuration via Image not found or type unknown Image not found or type unknown Image not found or type unkn image.png image.png image.png FWUPDATE VER Firmware update via Image not found or type unknown Image not found or type unknown Image not found or type unkn LANG ... - Page 55 TEL PHONES image.png image.png image.png 09 Request GSM signal Image not found or type unknown Image not found or type unknown Image not found or type unkn strength, battery voltage, firmware version status INFO GSM seting SMS command text Command meaning М1 М2, М3, М4 Guest number...
- Page 56 image.png image.png image.png 0001XYXXX Set new owner's Image not found or type unknown Image not found or type unknown Image not found or type unkn phone number (М1), where X — alert call on alarm (1 —on, 0 — 0001 XY XXX ...
- Page 57 M2XYXXX image.png image.png image.png 0003XYXXX Image not found or type unknown Image not found or type unknown Image not found or type unkn Set new M3 phone number where X — alert call on alarm (1 —on, 0 — 0003 XY XXX ...
- Page 58 image.png image.png image.png 0004XYXXX Image not found or type unknown Image not found or type unknown Image not found or type unkn Set new M4 phone number where X — alert call on alarm (1 —on, 0 — 0004 XY XXX ...
- Page 59 image.png image.png image.png ZZZZ9900PINXYXXX Emergency changing Image not found or type unknown Image not found or type unknown Image not found or type unkn M1 phone number: ZZZZ — password; PIN — emergenc y disarm code; — alert call on ZZZZ 9900 PIN XY alarm (1 ХХХ ...
- Page 60 GUEST- image.png image.png image.png 00961 Enable GSM Image not found or type unknown Image not found or type unknown Image not found or type unkn password request for M1PSW+ image.png image.png image.png 00960 Disable GSM Image not found or type unknown Image not found or type unknown Image not found or type unkn password request for...
- Page 61 image.png image.png image.png 00524 Disable data internet Image not found or type unknown Image not found or type unknown Image not found or type unkn in roaming image.png image.png image.png 0069Х Setting interval Image not found or type unknown Image not found or type unknown Image not found or type unkn of forwarding all incoming SMS from...
-
Page 63: Change Settings
User manual Change settings Change of user settings is available in the personal account on the website starline.online. image.png Image not found or type unknown... -
Page 64: Device Registration
User manual Device Registration To register new remote keys, tags, smartphones, and other wireless and wired accessories, use the "Device Registration" mode. To prevent unauthorized registration of new accessories, entry to registration mode is permitted in Disarmed mode only. If Immobilizer mode enabled then authorization must be passed to fully disarm a system. - Page 65 Registration of a smartphone: 1. Enable Bluetooth in the smartphone settings. 2. Select StarLine equipment from the list of available devices. 3. Enter the code "000000" (on the iOS platform, press the "Pair" button to enter the code). If multiple registered smartphones are simultaneously in the vicinity, the system will only work with the one that connects first.
- Page 66 A previously recorded smartphone in the system's memory will be automatically removed after registering a new smartphone or tag. Make sure to remove the system from the list of paired Bluetooth devices on your smartphone. Exiting the device registration mode Exiting the "Device Registration"...
-
Page 67: Emergency Disarming
Use the emergency disarmament code provided on the owner's plastic card or PIN envelope in the following situations: Loss of the tag. Depleted battery in the tag or remote key. No access to the StarLine mobile application. "Anti-hijack" mode is activated. Plastic card plastic2.png... - Page 68 Entering emergency disarm code via the StarLine EC-1 Capacitive Sensor The emergency disarm code can be entered using the StarLine EC-1 capacitive sensor (installed optionally). To disarm the system, follow these steps: 1. Touch the door handle 3 times. A single sound signal will follow.
- Page 69 User manual Changing the emergency disarm code To change the code, you need to know the current emergency disarm code. The initial emergency disarm code is indicated on the owner's plastic card or PIN envelope included in the delivery set. Plastic card plastic2.png Image not found or type unknown...
- Page 70 4. The system's transition to the emergency disarm code change mode will be confirmed by 2 short flashes of the service button LED and 2 sound signals. If there is no activity within 5 seconds, the system will automatically exit the emergency disarm code change mode.
- Page 71 15. Press the service button 4 times. Turn off the ignition. 16. The service button will flash four times. 17. Two short LED flashes and 2 beep sounds will confirm the correct entry of the current code. 18. Turn on the ignition. 19.
- Page 72 If there is no activity within 5 seconds, the system will automatically exit the emergency disarm code change mode. 5. Turn off the ignition. 6. Turn on the ignition and press the transceiver button the number of times corresponding to the first digit of the current emergency disarm code. 7.
- Page 73 18. Turn on the ignition. 19. Press the transceiver button 5 times. Turn off the ignition. 20. The transceiver LED will flash once. 21. Turn on the ignition. 22. Press the transceiver button 4 times. Turn off the ignition. 23. The transceiver LED will flash twice. 24.
- Page 74 Refer to the list of supported car buttons on the can.starline.ru website. If there is no flash of the service button LED after pressing the car's built-in button, then the button is not supported in this car.
- Page 75 button LED and 4 beep sounds. In this case, repeat steps 5 to 8. 10. Turn off the ignition after 10 seconds to exit the registration mode. off.png Image not found or type unknown 11. Exiting the "Device Registration" mode will be confirmed by 2 flashes of the service button LED and 2 beep sounds, after which there will be signals corresponding to the total number of registered remote keys, BLE tags, and smartphones.
-
Page 76: Connection Diagram
Connection diagram S96v2-connection-eng-1.png Image not found or type unknown S96v2-connection-eng-2.png Image not found or type unknown... - Page 77 Software All descriptions of software versions for the main unit, remote keys, and tags are available at the link: Software(to do)
