- Page 1 User manual Immobilizer i96 CAN User manual Version 5...
-
Page 2: Table Of Contents
StarLine i96 TABLE OF CONTENTS Safety precautions during charging of your car’s storage battery ............4 General description ..............5 Purpose ...........................5 Plastic card ........................6 Service button ......................6 Bluetooth Smart tag ....................7 2.4.1 Connection testing ..................7 LED indication ......................7 2.5.1 Discharge of the battery ................8 Specifications ................9... - Page 3 User manual Please, read attentively! Prior to operation of the security system carefully read this manual paying special attention to the sections marked and determine whether this security system is suitable for your car, for which follow the car manufacturer’s requirements and the car operation manual. The security system is a complicated technical device implying connection to the car circuits related to engine operation.
-
Page 4: Safety Precautions During Charging Of Your Car's Storage Battery
StarLine i96 remote keys over to third parties to prevent unauthorized access to security functions • do not leave remote keys or tags in areas accessible to children and animals Safety precautions during charging of your car’s storage battery Remember that any battery charging process implies supply of voltage... -
Page 5: General Description
LED indication Discharge of the battery Purpose Immobilizer StarLine i96 CAN is intended for anti-theft security with digital engine blocking via CAN bus (iCAN technology) and with cut of analog circuits wires. The owner is authorized in two ways: •... -
Page 6: Plastic Card
• Code of emergency disarming — disable engine blocking. • Service code — for access to the system configuration in StarLine Master program. It is recommended to take along the owner’s plastic card or save the emergency disarm code in the mobile phone. -
Page 7: Bluetooth Smart Tag
User manual Bluetooth Smart Tag The tags, included in the delivery set, are initially in the transport mode in which they are off! Pressing of the tag button in this mode will be indicated by green and red flashes of the built-in LED. Prior to operation, press the tag button several times until the flash color changes to green. -
Page 8: Discharge Of The Battery
StarLine i96 Discharge of the battery To prevent engine blocking due to a discharged battery, the immobilizer constantly checks battery capacity. The low battery charge level will be reported to the owner at ignition switch-on by 6 short bleeps. Replace the battery as soon as possible in case of discharge indication. -
Page 9: Specifications
User manual Specifications Main unit i96 CAN Parameter Value Supply voltage 6..16 V from -40 to +85 °С Operating temperature range Frequency range 2400..2480 MHz Radio exchange protocol Bluetooth Smart Consumption current with 8 mA switched-off ignition • 3 CAN Interfaces • 1 USB • 2 inputs from 0 to 5 V • 2 outputs of 12 V up to 500 mA... -
Page 10: Operation Description
StarLine i96 Operation description • Security mode • Factory security system control • Engine blocking • Service mode • «Emergency disarm» mode • «Device registration» mode • «Programming» mode To drive a car, equipped with the immobilizer, you must carry along the tag for authorization. -
Page 11: Factory Security System Control
User manual authorization will be confirmed by bleeps when ignition switch-on. In addition, authorization is confirmed at closing of the driver’s door after remote engine starting. If the tag is not detected due to some reasons when ignition switched- on, the immobilizer will wait for authorization, while issuing intermittent bleeps. - Page 12 StarLine i96 button push Hold Release LED light up to 2 sec Enable Anti-hijack mode button push Hold Release LED light up to 2 sec Disable Anti-hijack mode Depending on settings configuration Anti-hijack is activated by one of algorithms: by time interval, by distance or by engine speed.
-
Page 13: Hands-Free Mode
User manual • motion sensor triggered or engine speed exceeded the set value; • immobilizer shall activate the warning bleeps at half of the set distance value; • then immobilizer shall block engine at the set distance value (1 km by default). -
Page 14: Keyless-Go System Blocking
StarLine i96 Hands-Free disabling on a one security cycle If a tag is still visible in detection range while parking, so Hands-Free mode can be disabled for one security cycle by one of methods: • arming with a tag button push;... -
Page 15: Engine Blocking
User manual Engine blocking Engine is blocked with iCAN technology in the “Armed” mode. Thanks to the iCAN technology the immobilizer itself selects an event for safe engine blocking and supports of remote engine starting systems (depending on supported functions in the car CAN-bus). Engine blocking will be active until ignition switch-off. -
Page 16: Emergency Security Disarming
StarLine i96 To enable service mode make following steps: 1. Make sure authorization is passed. 2. Switch ignition On. 3. Push the service button 11 times. 4. Switch ignition Off and On again. 5. Service mode entry will be confirmed by 2 bleeps. - Page 17 User manual The immobilizer will remind about «Emergency disarm» mode each time when ignition switch-on by a long bleep. ATTENTION! Be sure to request the location of the service button in your car from installer. Do as follows for immobilizer switchover to «Emergency disarm» mode: Switch ignition On.
-
Page 18: Registration Of Tags And Smartphones
StarLine i96 Registration of tags and smartphones Use «Device registration» mode for registration of new tags and smartphones. Tags and smartphones shall be registered in one cycle. At registration of new tags and smartphones all previous tags and smartphones will be deleted from memory. In total, up to... - Page 19 User manual Entry in «Device registration» mode Set immobilizer to «Emergency disarm» mode. If there is connection with registered tag or smartphone — this step can be omitted. Switch ignition On. Press service button 7 times. Switch ignition off and on. 7 bleeps will follow, confirming entry in «Device registration»...
-
Page 20: Change Of Owner Authorization Code
Repeat items 1...3 for the remaining tags. Smartphone registration Register a smartphone with standard Bluetooth pairing procedure or with help of StarLine Key App. Pairing code - 000000. Exit from device registration mode Exit from device registration mode is performed at ignition switch-off. - Page 21 3 to 10 pressings of factory buttons. The list of supported factory buttons for particular vehicle model can be checked at can.starline.ru. In 3 seconds after the end of owner code entry, 2 short bleeps of buzzer will follow.
- Page 22 StarLine i96...
- Page 23 User manual...
- Page 24 StarLine i96 The manufacturer reserves the right to modify and improve the product design and technical features without prior notice. Manufacturer: ScPA “StarLine” LLC, Komissara Smirnova str., 9, 194044, Saint-Petersburg, Russian Federation Tel. +7 812 3263333 www.alarmstarline.com...
