- Page 1 We would like to thank you for choosing the motoimmobilizer and wish you many pleasant and safe drives! Revision No. 3 April 2017...
-
Page 2: Table Of Contents
Designation of external outputs ................ 7 Connection of power circuits..................8 Wiring diagrams ..................11 Connection diagram of StarLine V66 ............... 11 Standard connection diagrams of EXT input ..........12 Telematic setting ................... 13 Motoimmobilizer programming using a tag ........13 Entry the “Parameter programming”... -
Page 3: General Description
Bluetooth Smart protocol (BLE). The motoimmobilizer has sound and light indication to notify the owner and other people of security zone violation. The immobilizer is controlled with the tag or StarLine mobile application. ATTENTION! -
Page 4: Specifications
Motoimmobilizer StarLine V66 Specifications Parameter Main unit Frequency range of control radio signals, 2400...2480 Bluetooth Smart with key exchange via Type of control code the Diffie-Hellman protocol Supply voltage, V 8...18 2.0...3.3 Consumed current in security mode, – maximum, mA Maximum current load via relay contacts, –... -
Page 5: General Mounting Requirements
General mounting requirements The StarLine V66 motoimmobilizer is intended for installation on motor vehicles with the onboard voltage of +12 V. Prior to mounting, check operability of the motorcycle circuits, to which the immobilizer will be connected, as well as absence of indication of motorcycle standard equipment errors. -
Page 6: Magnetic Contact Installation
Motoimmobilizer StarLine V66 Magnetic contact installation The magnetic contact is intended for tracing of the motorcycle trunk state. Fasten the sensor in the trunk, for instance, using self-tapping screws. When installing the sensor, place the magnet near the sealed contact as shown in the figure. When the trunk is opened, distance between the magnet and sealed contact shall increase, so that alarm in the security mode is activated. -
Page 7: Description Of External Outputs
installation manual Description of external outputs Diagram of external outputs INPUT orange-gray brown black-white orange black black-yellow UNLOCK blue yellow LOCK green OUTPUT gray Designation of external outputs Marking Explanation Ground (–) Power (+) Ignition (+) Normally open contact of relay (NO) Normally closed contact of relay (NC) Common relay contact UNLOCK... -
Page 8: Connection Of Power Circuits
Motoimmobilizer StarLine V66 Connection of power circuits Power supply is connected using two wires: +12 V (BAT wire) and “ground” (GND wire). First of all, connect the “ground” wire. For connection to the “ground” use the “ground” bolt or nut. At that, crimp the terminal on the wire for the corresponding fastener diameter. - Page 9 installation manual NO contacts of built-in relay Ignition (–) Common Engine blocking circuit Connection of external blocking relay Crankshaft Engine NO relay contacts position control sensor unit Example of use NO contacts for blocking LOCK, UNLOCK wires – power outputs of motor vehicle light signal control.
- Page 10 Motoimmobilizer StarLine V66 UNLOCK Connection of light signals to the UNLOCK output INPUT wire – is connected to the trunk magnetic contact, included in the set. Due to this the motoimmobilizer can trace the trunk state. OUTPUT wire – alarm siren control output. The maximum permissible current is 2 A.
-
Page 11: Wiring Diagrams
Wiring diagrams Connection diagram of StarLine V66... -
Page 12: Standard Connection Diagrams Of Ext Input
Motoimmobilizer StarLine V66 Standard connection diagrams of EXT input To motor vehicle circuits Connection to clutch “+” at ignition hand brake switch-on foot “+” at ignition brake switch-on NO contacts control of stop lights and marker lights Connection to hand brake For this connection diagram, the EXT input should be set as a positive normally open one. -
Page 13: Telematic Setting
Telematic setting Convenient and quick setting of the motoimmobilizer is performed by means of wireless setting using the “StarLine Master” application, www.starline.ru available for download on the website Wireless setting will require the BLE-programmer StarLine. The telematic setting manual is given in section “Help” of the application during programmer connection via USB. -
Page 14: Entry The "Parameter Programming" Mode
Motoimmobilizer StarLine V66 Entry the “Parameter programming” mode Do as follows to enter the mode: 1) Switch off the ignition. 2) Hold the clutch* (brake) handle for 5 seconds. 3) A flash of light signals will follow. Release the clutch handle. -
Page 15: Motoimmobilizer Parameter Setting
installation manual Motoimmobilizer parameter setting For parameter setting, set the immobilizer to the “Parameter programming” mode. The programming mode is given in table for convenient use. Menu navigation is performed using the tag button. The number in the “Parameter” column corresponds to the number of tag pressings while the green LED is illuminated. - Page 16 Motoimmobilizer StarLine V66 Parameter Value Description Note Tilt sensor sensitivity 1 – low sensitivity Allows for adjusting tilt sensor 1...10 sensitivity 10 – high sensitivity 4 – default Movement sensor sensitivity 1 – low sensitivity Allows for adjusting movement 1...10 sensor sensitivity 10 –...
- Page 17 installation manual Parameter Value Description Note Volume level of alarm siren 1 – low Allows for siren volume control 1...10 at alarm activation 10 – loud 10 – default Volume level of sound confirmation signals 1 – no sound, only Allows for setting of volume level light signals of sound confirmation signals...
-
Page 18: Example Of Setting Of Shock Sensor Alarm Level Sensitivity
Motoimmobilizer StarLine V66 Parameter Value Description Note Siren control method continuous signal Allows for selecting the siren sounding method intermittent signal 1 – default Automatic security activation Allows for setting of automatic security activation (in 30 seconds after ignition switch-off and tag disappearance). - Page 19 installation manual 3) Press the tag button 5 times for sensitivity level setting. 4) After the end of illumination, 5 short red flashes will follow. 5) Successful setting of sensitivity level will be confirmed by 2 sound signals. If the input value is inadmissible, 4 sound signals will follow.
- Page 20 Motoimmobilizer StarLine V66 The manufacturer reserves the right to change the design and elements without prior notification Manufacturer: Limited Liability Company “Scientific and Production Association “StarLine” (LLC “SPA “StarLine”) 194044, Russia, Saint Petersburg, 9 Komissara Smirnova Str., letter A, office 204...
