Starline i96 CAN Short User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Short user's manual
Immobilizer
i96 CAN
Short user's manual
Version 2
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the i96 CAN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Starline i96 CAN

Summary of Contents for Starline i96 CAN

  • Page 1 Short user’s manual Immobilizer i96 CAN Short user’s manual Version 2...

  • Page 2: Table Of Contents

    Tag Bluetooth Smart ....................8 2.4.1 Connection testing ..................8 LED indication ......................8 2.5.1 Discharge of the battery ................9 Specifications ................10 Main unit i96 CAN ....................10 Tag Bluetooth Smart ....................10 Operation description ..............11 Security mode ......................11 Engine blocking ......................12 Service mode ......................
  • Page 3 Short user’s manual Please, read attentively! Prior to operation of the security complex carefully read this manual paying special attention to the sections marked and determine whether this security complex is suitable for your car, for which follow the car manufacturer’s requirements and the car operation manual. If you could not determine whether this security complex can be installed on the car, return it to the seller within 14 days after purchase.

  • Page 4: Safety Precautions During Charging Of Your Car's Storage Battery

    StarLine i96 • always switch over the complex to the service mode when handing the car over for maintenance or washing. Do not hand tags and remote keys over to third parties to prevent unauthorized access to security functions •...
  • Page 5 Short user’s manual All the aforesaid devices and modes may cause uncontrolled supply of increased voltage over 25 V and up to 60 V to the car circuit and cause failure of the security complex electronic components and car equipment. The light-up method should not be used for storage battery charging.

  • Page 6: General Description

    • LED indication Discharge of the battery Purpose Immobilizer StarLine i96 CAN is intended for car protection from theft by way of hidden engine blocking via the standard car bus (iCAN technology). The owner is authorized in two ways: •...

  • Page 7: Plastic Card

    • Service code — intended for setting and programming of complex parameters using the StarLine Master application. It is recommended to take along the owner’s plastic card or save the code of emergency security deactivation in the mobile phone.

  • Page 8: Tag Bluetooth Smart

    StarLine i96 Tag Bluetooth Smart The tags, included in the delivery set, are initially in the transport mode in which they are off! Pressing of the tag button in this mode will be indicated by green and red flashes of the built-in LED.

  • Page 9: Discharge Of The Battery

    Short user’s manual Discharge of the battery To prevent engine blocking due to a discharged battery, the immobilizer constantly checks battery capacity. The low battery charge level will be reported to the owner at ignition switch-on by 6 short sound signals. Replace the battery as soon as possible in case of discharge indication.

  • Page 10: Specifications

    StarLine i96 Specifications Main unit i96 CAN Parameter Value Supply voltage 6..16 V from -40 to +85 °С Operating temperature range Frequency range 2400..2480 MHz Radio exchange protocol Bluetooth Smart Consumption current with 8 mA switched-off ignition • Interfaces 3 CAN •...

  • Page 11: Operation Description

    Short user’s manual Operation description • Security mode • Engine blocking • Service mode • «Emergency security deactivation» mode • «Device registration» mode • «Programming» mode To drive a car, equipped with the immobilizer, you must carry along the tag for authorization. After the tag appears in the main unit’s operational range, automatic data exchange via the encrypted Bluetooth Smart protocol takes place.

  • Page 12: Engine Blocking

    StarLine i96 Successful authorization will be confirmed by sound signals when ignition switch-on. In addition, authorization is confirmed at closing of the driver’s door after remote engine starting. If the tag was not found due to some reasons during ignition switch-on, the immobilizer will wait for authorization, while issuing intermittent sound signals.

  • Page 13: Service Mode

    Short user’s manual Service mode The service mode is intended for temporary deactivation of security functions for the maintenance period. Entry in and exit from the mode is performed by holding the tag button for 5 seconds. Transition to the service mode will be indicated by green color of the LED on the tag.

  • Page 14: Emergency Security Deactivation

    StarLine i96 Emergency security deactivation If the tag was lost or the battery is discharged, use the “Emergency security deactivation” mode. This mode allows for driving without the tag. The mode can be entered using the code of emergency security deactivation given on the owner’s plastic card.
  • Page 15 Short user’s manual Press service button number times corresponding to the first digit of the code of emergency security deactivation. Switch off the ignition. A signal confirming the digit entry will follow. Repeat items 1...3 for the remaining digits. If 3 short signals will follow, the code of emergency security deactivation was entered correctly, 1 long signal —...

  • Page 16: Registration Of Tags And Smartphones

    StarLine i96 Example of entry of the code of emergency security deactivation 5342 Registration of tags and smartphones Use the «Device registration» mode for registration of new tags and smartphones. Tags and smartphones shall be registered in one cycle. At registration of new tags and smartphones all previous tags and smartphones will be deleted from memory.
  • Page 17 Short user’s manual Entry in the «Device registration» mode Set the immobilizer to the «Emergency security deactivation» mode. If there is connection with registered tag or smartphone — this item can be omitted. Switch on the ignition. Press the service button 7 times. Switch ignition off and on.
  • Page 18 LED will light up red. Repeat items 1...3 for the remaining tags. Smartphone registration Register a smartphone using the StarLine Key mobile application. Exit from the device registration mode Exit from the device registration mode is performed at ignition switch-off.

  • Page 19: Change Of Owner Authorization Code

    Short user’s manual Change of owner authorization code The owner authorization code is used for authorization by means of the standard car buttons. Do as follows to change the owner authorization code: Set the immobilizer to the «Security off» mode. Switch on the ignition.
  • Page 20 StarLine i96...
