- Page 1 wireless unit Revision No. 2 October 2016...
- Page 2 StarLine R6 may only be used in combination with the 6th Generation StarLine security systems (X96,M96, E96, S96 etc.) Data between the main unit of a security system and StarLine R6 are transferred via the Bluetooth Smart (BLE) protocol using a data interception protection algorithm while device registration.
-
Page 3: Delivery Package
Installation manual Delivery package Main unit with wires. Temperature sensor. Plastic brace (2 pcs.) Installation manual. -
Page 4: Specifications
StarLine R6 Specifications Parameter Value Input voltage, V 8 – 18 Current consumption, mA Insulation class IP67 Maximum current at LOCK and UNLOCK outputs, A Maximum permitted switched current via relay contacts, A Operating temperature range, °С –40 ... +85 Temperature sensor measuring range, °С... -
Page 5: Operation Description
In normal mode StarLine R6 communicates with the main unit and receives its control commands for engine block, hood lock, and the alarm siren. The StarLine R6 monitors the state of the hood, ignition, engine temperature and transfers these data to the main unit. - Page 6 StarLine R6 Engine blocking Normal mode In the normal operation mode StarLine R6 blocks an engine by a command of the main unit. Standalone mode In the standalone mode, an engine can be blocked by either of the following events: •...
- Page 7 Alarm siren control In the normal mode alarm siren control is made with an alarm main unit ommands. In the standalone mode StarLine R6 independently controls an alarm siren. The StarLine R6 turns on sound alarm in following cases: • communication with an alarm main unit is lost (30 s long intermittent alarm siren sound);...
-
Page 8: General Installation Requirements
StarLine R6 nderhood unit is designed for installation on vehicles with 12 V voltage. StarLine R6 should be installed under the vehicle hood. Mount the unit in a hidden place so that it would not contact moving parts of the vehicle. Fasten the housing with plastic braces. -
Page 9: Wiring Diagram
Installation manual Wiring diagram Connection diagram... - Page 10 StarLine R6 Description of external outputs Diagram of external outputs INPUT orange-grey brown black-white orange black black-yellow UNLOCK blue yellow green LOCK OUTPUT grey Designation of external outputs Marking Assignment Ground (-) Power (+) Ignition (+) Normally open contact of relay (NO)
- Page 11 If current in the blocked circuit exceeds 10 A, an auxiliary external relay should be used. Crankshaft R6 NO contacts Engine position control...
- Page 12 StarLine R6 UNLOCK, LOCK wires – power outputs for controlling the hood lock electrical drive. The outputs are built according to the power scheme (the maximum output current is 12 A), therefore no additional power modules are required for lock control. Whenever the hood is unlocked, a +12 V pulse is generated at the UNLOCK wire for 0.8 s.
- Page 13 Installation manual Registering the underhood unit If a StarLine R6 underhood unit was purchased separately from the security system, it must be registered into the main unit memory. Registration procedure for StarLine R6 unit: 1. Switch ignition Off. 2. Disconnect the ВАТ, OUTPUT and INPUT wires from a car circuits.
- Page 14 StarLine R6 The manufacturer reserves the right to modify and improve the product design and technical features without prior notice. Manufacturer: ScPA “StarLine” LLC, Komissara Smirnova str., 9, 194044, Saint-Petersburg, Russian Federation Tel. +7 812 3263333 www.alarmstarline.com...
- Page 15 Installation manual...
- Page 16 StarLine R6...
