Page 1 StarLine A96, AS96, B96, D96 EN version mock manual User manual Safety Measures for Operating the Security System General Description Technical Specifications Light and sound indication Controlling the system using a remote key Controlling the System using a Tag Operating Modes...
Page 2 User manual...
Page 3 User manual Safety Measures for Operating the Security System Please read carefully! Before operating the security system, carefully read this manual and pay special attention to Screenshot 2023-11-28 163123.png sections marked with an exclamation point . To Image not found or type unknown determine if this security system is suitable for your vehicle, refer to the vehicle manufacturer's requirements and operating instructions.
Page 4 Store a spare battery in the vehicle in its original packaging. The full electronic version of the instruction manual is available on the website help.starline.ru. Mandatory Safety Measures When Using the Engine Start Function: It is important to remember that a vehicle is a potential hazard. Section 12.8 of the traffic rules states: "The driver may leave their place or leave the vehicle if necessary measures are taken to...
Page 5 Before activating the remote or automatic engine start function: Ensure the vehicle is in good condition. Ensure there is sufficient fuel, oil, coolant, etc. Set the heater, air conditioner, defroster, and other accessories to the required levels. Set the cabin air circulation to improve heating or cooling efficiency. Safety Measures When Charging Your Vehicle's Battery Keep in mind that any battery charging process involves supplying a voltage higher than the...
Page 6 This necessity arises because without measuring devices, you cannot determine the condition, state, or reason for battery discharge (such as internal short circuits or breaks). Connecting a charging device to a faulty battery poses a risk of damaging the vehicle's electronic equipment and security system due to increased voltage.
Page 7: General Description
Positioning System (GPS) satellites. Depending on the configuration, the complex can be controlled using a key fob, SMS commands, voice menu, wireless tag, the StarLine mobile application, or through the personal account on the starline.online website. To access the personal account, use the login and password provided on the owner's pin envelope included in the supply kit.
Page 8 Emergency Disarm Code: Intended for emergency deactivation of the security system. Login and Password: Used for logging into the personal account on the starline.online website and in the StarLine mobile application. Complex Phone Number: The phone number of the SIM chip integrated into the security complex.
Page 9: Technical Specifications
-148 dBm (Cold Start) -163 dBm (Hot Start) -165 dBm (Tracking Mode) Interfaces 2 CAN 4 LIN 1 Universal StarLine Bus 1 USB 16 Configurable Channels: 15 Outputs (0.2 A) 2 Outputs (2 A) 3 Positive Inputs 3 Negative Inputs...
Page 10: Light And Sound Indication
User manual Light and sound indication The security complex provides various options for indicating modes such as "Disarmed", "Armed", and "Alarm": Hidden: Light and sound indicators are disabled. Silent: Only light indicators are enabled. Sound: Only sound indicators are enabled. Full: Both light and sound indicators are enabled.
Page 11: Led Indicator
icon-short.png icon-short.png Image not found or type unknown Image not found or type unknown Security deactivation (one of the icon-short.png Image not found or type unknown zones was violated in the security icon-short.png Image not found or type unknown icon-short.png icon-short.png cycle)
Page 12 Event Sound Indicator Waiting for Authorization 10 seconds icon-short.png icon-short.png icon-short.png Image not found or type unknown Image not found or type unknown Image not found or type unkno Key Fob Battery Low (when ignition is turned on) icon-short.png icon-short.png Successful Owner Authorization Code Input Image not found or type unknown Image not found or type unknown...
Page 13 The remote key with LCD uses a AAA 1.5 V battery. The battery life of the remote key with LCD is up to 6 months depending on operating conditions. 2. Additional remote key. a96-led-remote.jpg Image not found or type unknown The additional remote key uses a CR2032 3 V battery.
Page 14: Security Zones
Включен автоматический периодический запуск.jpg Image not found or type unknown Automatic periodic start is activated Включен автоматический запуск по температуре.png Image not found or type unknown Automatic start by temperature is activated Включен автоматический запуск по падению напряжения АКБ.png Image not found or type unknown Automatic start by battery voltage drop is activated Выполнена...
Page 15: Additional Information
Сработал датчик наклона.png Image not found or type unknown Tilt sensor activated Сработал датчик движения.png Image not found or type unknown Motion sensor activated Сработал предупредительный уровень датчика удара.png Image not found or type unknown Warning level of shock sensor activated Сработал...
Page 16 dop-brelok.png Image not found or type unknown The following terms of button press duration are used in this manual: Short Press Pressing a single button (or two buttons simultaneously) for less than 1.5 seconds. Example: icon-short-1.png Image not found or type unknown —...
Page 17 icon-short-1.png icon-short-1.png Image not found or type unknown Image not found or type unknown Arm without confirmation sound signals icon-short-1.png Image not found or type unknown icon-short-2.png Disarm Image not found or type unknown icon-short-2.png icon-short-2.png Image not found or type unknown Image not found or type unknown Disarm without confirmation sound signals icon-short-2.png...
Page 18: Cursor Menu
icon-short-double-2-3.png Activate/deactivate button lock Image not found or type unknown icon-long-double-1-4.png icon-note-2.png Image not found or type unknown Image not found or type unknown Activate/deactivate "Button Autolock" function icon-long-3.png icon-note-1.png Image not found or type unknown Image not found or type unknown Activate only remote key vibration signal icon-short-3.png Image not found or type unknown...
Page 19: Settings Menu
Icon Parameter Description Setting Step Режим «Свободные руки».png Image not found or type unknown " Hands-Free" mode Enable/disable "Hands- — Free" mode Включен автоматический запуск по будильнику.jpg Image not found or type unknown A utomatic engine start and Set the hours and minutes 1 minute preheater start by alarm for engine start.
Page 20 Setting the Time Zone To set the time zone, select the first item in the settings menu. Then, using buttons icon-short-2.png and icon-short-3.png set the desired value. The minimum step size is 1 Image not found or type unknown Image not found or type unknown hour.
Page 21 To adjust the motion sensor sensitivity level, select the sixth item in the settings menu. Then, using buttons icon-short-2.png and icon-short-3.png , set the desired value from 0 to 30. Image not found or type unknown Image not found or type unknown 0 —...
Page 22 To set the range of the mark detection zone, select the eleventh item in the settings menu. Then, using buttons icon-short-2.png and icon-short-3.png , set the desired value from 1 to 8. Image not found or type unknown Image not found or type unknown 1 —...
Page 23 Enter the menu by long press of the button icon-long-3.png icon-note-2.png . After Image not found or type unknown Image not found or type unknown entering, the current profile settings will be displayed. Adjusting Command Confirmation Volume image.png image.png Image not found or type unknown Image not found or type unknown 1 —...
Page 24 Сработал тревожный уровень датчика удара.png — on, Image not found or type unknown Датчик удара отключен.png — off. Image not found or type unknown Volume adjustment is done by short pressing the buttons icon-short-2.png Image not found or type unknown icon-short-3.png , respectively.
Page 25: Setting Time And Date
Automatic Button Lock Function When this function is activated, the remote key buttons are automatically locked after the backlight turns off. The function is enabled and disabled by performing a second-level long press on buttons 1 and 4: icon-long-double-1-4.png icon-note-2.png Image not found or type unknown Image not found or type unknown Remote Key Locator Function...
Page 26: Checking Connection
User manual Controlling the System using a Tag Additional Bluetooth remote tags (hereafter referred to as the tag), included in the package, are initially in transport mode, in which they are disabled. Pressing the tag button in this mode will be indicated by green, red, and yellow flashes of the built-in LED. Before use, press the tag button several times until the flash color changes to green.
Page 27: Replacing The Battery
First-level long press — press and hold the button until two short flashes of the current operating mode followed by one long flash, during which the button should be released. Second-level long press — press and hold the button until two short flashes of the current operating mode followed by one long flash, then a series of short flashes, during which the button should be released.
Page 28: Operating Modes
User manual Operating Modes Security modes Armed Disarmed Antihijack Alarm Panic Additional modes «Slave» Hands-Free Service mode Device registration Telematic setup Security modes provide protection for the vehicle against theft. Additional modes are intended for adding new devices ("Device Registration" mode), disabling security functions for vehicle servicing ("Service Mode"), and convenient system control ("Slave"...
Page 29: Silent Arming
SMS command Voice menu command 11 ; Via the StarLine mobile app; Through the personal account on the starline.online website; By activating the standard security system ("Slave" mode); When the tag is lost or the door handle sensor is touched in "Hands-Free" mode By pressing the tag button once in "Disarmed"...
Page 30 If the tag or remote key battery is dead, and there is no access to the starline.online personal account and StarLine mobile app, use emergency arming: 1. Press the service button or the transceiver button 3 times. 2. Turn on the ignition. Three sound signals will follow.
Page 31 When the set speed threshold is exceeded Enabling, disabling, and configuring the "Central Locking During Travel" function is available in the personal account on the starline.online website (Settings → Main Parameters → Central Lock Control). Central Lock Unlocking During Travel...
Page 32: Alarm Mode
When the handbrake is engaged Enabling, disabling, and configuring the "Central Lock Unlocking During Travel" function is available in the personal account on the starline.online website (Settings → Main Parameters → Central Lock Control). Trunk Unlocking in Armed Mode Function This function allows the trunk to be opened with the standard vehicle remote key without disarming the system, provided that the tag and/or the system's remote key is within range.
Page 33: Panic Mode
Notification options can be configured in the personal account on the starline.online website (Settings → Main Parameters → Light and Siren Control): Sound notification with siren and hazard lights Notification with hazard lights only No light or sound indication By default, sound notification with siren and hazard lights is enabled.
Page 34 To enable the "Anti-Hijack" mode by owner’s command, go to the personal account on the starline.online website (Settings → Main Parameters → Anti-Hijack by Tag Loss → Uncheck the boxes) or in the StarLine mobile application (Settings → Advanced Settings → Main Parameters → Anti-Hijack by Tag Loss → Uncheck the boxes).
Page 35: Slave Mode
By entering the emergency disarm code specified on the plastic card or pin envelope of the owner using the service button or transceiver button From the personal account on the starline.online website. The emergency disarm code specified on the plastic card or pin envelope of the owner needs to be entered.
Page 36: Hands-Free Mode
Disabling the alarm by touching the door handle sensor (purchased separately) with the tag in sight The detection zone and loss are adjusted in the personal account on the starline.online website (Settings → Main Parameters → Hands-Free). By default, the tag's operating range is set to the maximum value.
Page 37 In the "Hands-Free" mode, automatic arming will not be executed if the tag is within sight. The parameters of the "Hands-Free" mode can be adjusted in the personal account on the starline.online website (Settings → Main Parameters → Hands-Free). Disabling "Hands-Free" Mode for 1 Security Cycle If the tag remains within range during parking (for example, you're in a cafe while your car is parked nearby), it is recommended to disable the security deactivation in "Hands-Free"...
Page 38: Service Mode
Activation of the "Anti-Hijacking" mode by tag or key fob loss; Main unit calibration procedure; "CAN Information" section in the personal account on the starline.online website or in the StarLine mobile app. Entering Service Mode can be done using one of the following methods: Selecting the corresponding item in the tag cursor menu;...
Page 39: Immobilizer Mode
By SMS command By voice menu command Via the StarLine mobile app; Through the personal account on the starline.online website. By entering the emergency disarm code. Entering Service Mode will be confirmed by a yellow LED indication on the tag. In Service Mode, transition to other additional modes is prohibited!
Page 40: Engine Start
Requests can be made by the owner with a short press of the key fob button icon-short-3.png Image not found or type unknown or by sending SMS command When using the key fob, the information will be displayed on its screen, while SMS requests will receive a response SMS message.
Page 41 The minimum engine runtime for remote start is 10 minutes. This can be adjusted in the starline.online website personal account or the StarLine mobile app. Automatic engine start will not occur if less than 1 hour has passed since the last start or if the previous automatic start failed.
Page 42: Manual Mode
The "Alarm" mode is activated. The vehicle starts moving. The hood is opened. The parking brake is released (for MT vehicles). The AT selector is shifted out of the "Park" position (for AT vehicles). The brake pedal is pressed. The engine reaches the maximum temperature threshold specified during the security system setup to protect the engine from overheating.
Page 43: Automatic Mode
Image not found or type unknown by SMS-command Via the StarLine mobile app; Through the personal account on the starline.online website. The preheater operates for 20 minutes in this mode. To change its duration, consult your installation specialist. If the preheater has factory settings different from those set by the installation specialist, the operating time may differ from the specified time.
Page 44 The operating time and temperature threshold for preheater disconnection can be changed in the personal account on the starline.online website or in the StarLine mobile app. «Turbotimer» function For vehicles with turbochargers, use the "Turbotimer" function to cool the engine turbine.
Page 45: Beach Mode
Owner authorization is achieved by entering the emergency disarm code by touching the door handle with a capacitive sensor StarLine ES-1 (optional). In this mode, the system does not respond to key fob commands.
Page 46 It is also possible to activate the video recorder for 5 minutes using SMS command 69 . If the engine is started when the "Armed" mode is activated, the video recorder will continue to operate until the engine is stopped. Risky parking mode Use this mode when parking in areas with a high risk of theft.
Page 47: Gsm Control Commands
The system provides notifications via phone calls and SMS messages for various events (alarm activation, SIM card balance decrease, battery discharge, etc.). Notification settings can be adjusted in the personal account on the website starline.online (Settings → Telematics → Notification Settings/Additional Notifications via SMS). Voice menu commands...
Page 48 image.png image.png image.png 0 Listen commands Image not found or type unknown Image not found or type unknown Image not found or type unkn menu image.png image.png image.png 10 Disarming Image not found or type unknown Image not found or type unknown Image not found or type unkn image.png image.png...
Page 49: Sms Commands List
image.png image.png image.png 70 Disable Hands-Free Image not found or type unknown Image not found or type unknown Image not found or type unkn image.png image.png image.png 71 Enable Hands-Free Image not found or type unknown Image not found or type unknown Image not found or type unkn Voice call commands Voice menu...
Page 50 image.png image.png image.png 111 Silent arming Image not found or type unknown Image not found or type unknown Image not found or type unkn image.png image.png image.png 12 Arming with shock Image not found or type unknown Image not found or type unknown Image not found or type unkn sensors disabled image.png...
Page 51 image.png image.png image.png 221 Start engine Image not found or type unknown Image not found or type unknown Image not found or type unkn preheater image.png image.png image.png 40 Request location Image not found or type unknown Image not found or type unknown Image not found or type unkn GPS ...
Page 52 image.png image.png image.png 51 Enable Service mode Image not found or type unknown Image not found or type unknown Image not found or type unkn S+ image.png image.png image.png 69 Activate video Image not found or type unknown Image not found or type unknown Image not found or type unkn recorde VIDEOREG ...
Page 53: Info Commands
image.png image.png image.png SETTING- Exit configuration via Image not found or type unknown Image not found or type unknown Image not found or type unkn image.png image.png image.png FWUPDATE VER Firmware update via Image not found or type unknown Image not found or type unknown Image not found or type unkn LANG ...
Page 54 TEL PHONES image.png image.png image.png 09 Request GSM signal Image not found or type unknown Image not found or type unknown Image not found or type unkn strength, battery voltage, firmware version status INFO GSM seting SMS command text Command meaning М1 М2, М3, М4 Guest number...
Page 55 image.png image.png image.png 0001XYXXX Set new owner's Image not found or type unknown Image not found or type unknown Image not found or type unkn phone number (М1), where X — alert call on alarm (1 —on, 0 — 0001 XY XXX ...
Page 56 M2XYXXX image.png image.png image.png 0003XYXXX Image not found or type unknown Image not found or type unknown Image not found or type unkn Set new M3 phone number where X — alert call on alarm (1 —on, 0 — 0003 XY XXX ...
Page 57 image.png image.png image.png 0004XYXXX Image not found or type unknown Image not found or type unknown Image not found or type unkn Set new M4 phone number where X — alert call on alarm (1 —on, 0 — 0004 XY XXX ...
Page 58 image.png image.png image.png ZZZZ9900PINXYXXX Emergency changing Image not found or type unknown Image not found or type unknown Image not found or type unkn M1 phone number: ZZZZ — password; PIN — emergenc y disarm code; — alert call on ZZZZ 9900 PIN XY alarm (1 ХХХ ...
Page 59 GUEST- image.png image.png image.png 00961 Enable GSM Image not found or type unknown Image not found or type unknown Image not found or type unkn password request for M1PSW+ image.png image.png image.png 00960 Disable GSM Image not found or type unknown Image not found or type unknown Image not found or type unkn password request for...
Page 60 image.png image.png image.png 00524 Disable data internet Image not found or type unknown Image not found or type unknown Image not found or type unkn in roaming image.png image.png image.png 0069Х Setting interval Image not found or type unknown Image not found or type unknown Image not found or type unkn of forwarding all incoming SMS from...
Page 62: Change Settings
User manual Change settings Change of user settings is available in the personal account on the website starline.online. image.png Image not found or type unknown...
Page 63: Device Registration
User manual Device Registration To register new remote keys, tags, smartphones, and the Master-6 GSM+GPS module, use the "Device Registration" mode. To prevent unauthorized registration of new accessories, entry to registration mode is permitted in Disarmed mode only. If Immobilizer mode enabled then authorization must be passed to fully disarm a system.
Page 64 Entering the device registration mode using the transceiver button 1. Set the system to "Disarmed" mode. 6.png Image not found or type unknown 2. Turn off the ignition (if it was on). 7.png Image not found or type unknown 3. Press the transceiver button 7 times. n_Кнопка-трансивера_2.png Image not found or type unknown 4.
Page 65 Registration of a smartphone: 1. Enable Bluetooth in the smartphone settings. 2. Select StarLine equipment from the list of available devices. 3. Enter the code "000000" (on the iOS platform, press the "Pair" button to enter the code). If multiple registered smartphones are simultaneously in the vicinity, the system will only work with the one that connects first.
Page 66: Emergency Disarming
Use the emergency disarmament code provided on the owner's plastic card or PIN envelope in the following situations: Loss of the tag. Depleted battery in the tag or remote key. No access to the StarLine mobile application. "Antihijack" mode is activated. Plastic card plasticcard1.png...
Page 67 Entering emergency disarm code via the StarLine EC-1 Capacitive Sensor The emergency disarm code can be entered using the StarLine EC-1 capacitive sensor (installed optionally). To disarm the system, follow these steps: 1. Touch the door handle 3 times. A single sound signal will follow.
Page 68 An attempt to enter a digit will be indicated by 5 flashes of the service button LED.
Page 69 User manual Changing the emergency disarm code To change the code, you need to know the current emergency disarm code. The initial emergency disarm code is indicated on the owner's plastic card or PIN envelope included in the delivery set. Plastic card plasticcard1.png Image not found or type unknown...
Page 70 1. Put the system in the "Disarmed" mode. 2. Press the service button 4 times. 3. Turn on the ignition. Confirm the action by observing 4 flashes of the service button LED and 4 sound signals. 4. The system's transition to the emergency disarm code change mode will be confirmed by 2 short flashes of the service button LED and 2 sound signals.
Page 71 11. Turn on the ignition. 12. Press the service button 8 times. Turn off the ignition. 13. The service button will flash three times. 14. Turn on the ignition. 15. Press the service button 4 times. Turn off the ignition. 16.
Page 72 3. Turn on the ignition. Confirm the action by observing 4 flashes of the transceiver LED and 4 sound signals. 4. The system's transition to the emergency disarm code change mode will be confirmed by 2 short flashes of the transciever LED and 2 sound signals If there is no activity within 5 seconds, the system will automatically exit the emergency disarm code change mode.
Page 73 14. Turn on the ignition. 15. Press the transceiver button 4 times. Turn off the ignition. 16. The transceiver LED will flash four times. 17. Two flashes of the transceiver LED and 2 beep sounds will confirm the correct entry of the current code.
Page 74 Refer to the list of supported car buttons on the can.starline.ru website. If there is no flash of the service button LED after pressing the car's built-in button, then the button is not supported in this car.
Page 75 11. Exiting the "Device Registration" mode will be confirmed by 2 flashes of the service button LED and 2 beep sounds, after which there will be signals corresponding to the total number of registered remote keys, BLE tags, and smartphones. Deleting the owner authorization code To delete the owner authorization code, follow these steps: 1.
Page 76 Installiation manual An installiation manual is available at the link(to do). The connection diagram is available in the current instructions on the ‘Connection Diagram’ page.
Page 77: Connection Diagram
Connection diagram...
Page 78 Software All descriptions of software versions for the main unit, remote keys, and tags are available at the link: Software(to do)
