Silicon Laboratories TSM1285 Manual

FEATURES
 Quick and easy Interface to computer for
evaluation via Nano River Technologies
ViperBoard and USB cable
 Input BNC connection
 On-board +3.3V supply voltage
 External power supply connection available
 Fully Assembled and Tested
 2in x 3in 2-layer circuit board
Figure 1. TSM1285 Evaluation Board
with Nano River Tech ViperBoard
Figure 2. TSM1285 Evaluation Board
(Top View)
A 300ksps, Single-supply, 12-Bit Serial-output ADC
TSM1285 Demo Board
DESCRIPTION
The demo board for the TSM1285 is a completely
assembled and tested circuit board that can be used
for evaluating the TSM1285. For easy and quick
evaluation of the TSM1285, a Nano River Tech
ViperBoard with an onboard microcontroller and
FPGA for signal processing is available. The
ViperBoard interfaces to any computer via USB port
and a user-friendly Windows OS compatible software
is available for evaluation.
The TSM1285 – a single-supply, single-channel, 12-
bit analog-to-digital converter (ADC) - is an alternate
source for the MAX1285 and a higher-speed upgrade
to the MAX1240 and MAX1240 ADCs. The TSM1285
combines a high-bandwidth track-and-hold (T/H), a
high-speed serial digital interface, an internal +2.5V
reference, and low
consumption. The TSM1285 operates from a single
+2.7V to+3.6V supply and draws less than 2.5mA at
300ksps.
Product data sheet and additional documentation can
be found at www.silabs.com.

ORDERING INFORMATION

Order Number
TSM1285DB
TSDA-VB
Figure 3. TSM1285 Evaluation Board
(Bottom View)
© 2014 Silicon Laboratories, Inc. All rights reserved.
conversion-mode
Description
TSM1285
Demo Board
Nano River Tech ViperBoard
power
Page 1
