Summary of Contents for NXP Semiconductors S12ZVML-MINIKIT
- Page 1 Quick Start Guide S12ZVML-MINIKIT 3-phase BLDC and PMSM Development Kit with NXP S12ZVML128 MCU...
- Page 2 Quick Start Guide 3-PHASE BLDC/PMSM DEVELOPMENT KIT WITH NXP S12ZVML128 MCU 40W PM Motor Part Number: 45ZWN24-40 S12ZVML-MINIBRD...
- Page 3 www.nxp.com GET TO KNOW THE S12ZVML-MINIBRD Load Terminals 3-phase MOSFET Bridge with Decoupling Capacitor and Load Current Sense Resistor MC9S12ZVML128 MCU With Load Current Sense Circuit LIN / Power Supply Digital Input/ Output Analog / Digital Input User LED Serial Communication Interface OSBDM and USB-...
- Page 4 Quick Start Guide GET TO KNOW THE S12ZVML-MINIBRD Boost Circuit Reverse Battery Protection Figure 1: Back side of S12ZVML-MINIBRD...
- Page 5 www.nxp.com S12ZVML-MINIBRD FEATURES Hardware Software • S12ZVML-MINIBRD— • Automotive Motor Control Algorithm MC9S12ZVML128 with LIN connectivity – Sensorless control of the support, BDM and OSBDM BLDC motor based on Six-step downloading and debugging commutation control technique • Low Cost PM Motor—3-phase PM allowing torque/speed control with motor,24VDC,4000RPM,40W,45Z low CPU load...
-
Page 6: Connect The Power Supply
Quick Start Guide STEP-BY-STEP INSTRUCTIONS Download BLDC Motor Download Control Software Package Software Visit nxp.com/S12ZVML-MINIBRD. Download installation software and Navigate the “Getting Started” section documentation under “Getting started” and download the latest version of at nxp.com/AutoMCDevKits. documentation and software package. Connect the Install CodeWarrior Motor... -
Page 7: Usb Cable
www.nxp.com STEP-BY-STEP INSTRUCTIONS CONTINUED • Navigate to the installed application Connect the directory: USB Cable – for BLDC application: MC_ Connect S12ZVML-MINIBRD to the PC DevKits\S12ZVMLMINIBRD\sw\ using the USB cable. Allow the PC to S12ZVMLMINIBRD_BLDC_SW_ automatically configure the USB drivers if CW11 and click OK needed. - Page 8 Quick Start Guide STEP-BY-STEP INSTRUCTIONS CONTINUED • Click the red STOP button in the FreeMASTER FreeMASTER toolbar or press CTRL+K Setup to enable the communication. • Start the FreeMASTER application • Successful communication is signalized – For BLDC application: Open in the status bar at very bottom as FreeMASTER project MC_DevKits\ BLDC: “RS232 UART...
-
Page 9: Application Control
www.nxp.com APPLICATION CONTROL 1. Click Motor 1 in the Motor Control manually in the.variable watch Application Tuning tool(MCAT) tool tab window, by clicking speed gauge. For menu to display the motor control page. BLDC application, the speed range is between 250rpm to 4000rpm. For 2. -
Page 10: Warranty
SUPPORT Get Started Visit www.nxp.com/support for a list of phone numbers within your region. Download installation software and documentation WARRANTY under “Getting Started” Visit www.nxp.com/warranty for at www.nxp.com/SZVML-MINIBRD. complete warranty information. www.nxp.com NXP, the NXP logo and Kinetis are trademarks of NXP B.V. All other product or service names are the property of their respective owners.
