- Page 1 Quick Start Guide S12VR32EVB Highly Integrated Microcontroller Power Window Lift Relay-Based...
- Page 2 Quick Start Guide www.nxp.com GET TO KNOW THE S12VR32EVB BOARD SIMPLIFIED BOARD DESCRIPTION User Hall Sensor Button Connector External Temperature Motor Out (2) Sensor Relay User Up/Stop/ Down Switch LIN Interface and Power Supply Reset Button Connector Front side of S12VR32EVB board...
- Page 3 Quick Start Guide www.nxp.com INTRODUCTION SOFTWARE TOOLS INSTALLATION The S12VR32 EVB features the S12VR32 microcontroller, an automotive 16-bit MCU Connect the for applications based on motor control relays. The S12VR32 evaluation board Install CodeWarrior ® Board integrates an S12 CPU, a LIN physical interface, a 5 V regulator system to supply the Development Studio microcontroller and low-side drivers to control the relay.
- Page 4 Quick Start Guide www.nxp.com STEP-BY-STEP BOARD CONNECTION STEP-BY-STEP BOARD CONNECTION (CONT.) Connect Connect Connect an External Connect the Hall Sensor the Board the Motor HCS12(X) Debugger Connector Supply your board with 12 V as is shown Connect your DC motor as is shown in Connect the Hall encoder (Only required in the image.
-
Page 5: Headers And Connectors
Quick Start Guide www.nxp.com HEADERS AND CONNECTORS PUSH BUTTONS AND SWITCHES HEADER/CONNECTOR DESCRIPTION HEADER/CONNECTOR DESCRIPTION Push button connects to a high voltage input HALL sensor connector Pin 1 Motor1_Out Switch used to control motor direction Pin 2 Motor0_Out Push button reset Pin 1 Pin 2 Pin 3... - Page 6 Quick Start Guide www.nxp.com...
-
Page 7: Warranty
WARRANTY “Jump Start Your Design” at Visit www.nxp.com/warranty for www.nxp.com/S12VR32EVB. complete warranty information. www.nxp.com/automcdevkits NXP, the NXP logo and CodeWarrior are trademarks of NXP B.V. All other product or service names are the property of their respective owners. © 2016 NXP B.V.
