- Page 1 S32R372141EVB QUICK START GUIDE (QSG) Ultra-Reliable MCUs for Industrial and Automotive Applications S32R372141EVB Webpage EXTERNAL USE...
- Page 2 Contents • Quick Start Package Overview • Step-by-Step Installation Instructions • Hardware: S32R372141EVB Board − Features − S32R372141EVB Overview − S32R372141EVB Pinout Settings − Communication and Debug Interfaces − Power Supply • Software: − Software Development Tools − Pre-compiled Code Examples •...
- Page 3 Integrated Development Environment (IDE) Eclipse based S32DS IDE with free GCC compiler and Debugger support S32R372141EVB Quick Start Package Software examples and supporting documents for getting started with the S32R372141EVB S32R372141EVB Schematics PDF schematic files for the S32R372141EVB board S32R372141EVB PCB Design Package...
- Page 4 Step-by-Step Installation Instructions In this quick start guide, you will learn how to set up the Install Software and Tools S32R372141EVB board and run the default program. Install S32 Design Studio IDE for Power Architecture. S32 Design Studio for Power...
- Page 5 S32Rx qualified to AEC-Q100 Grade 1 and ambient temperature of -40 to +150 °C • S32R372141EVB is a low cost standalone radar EVB. Attach a radar transceiver to the MIPI-CSI2 connector to take advantage of its radar processing capability •...
- Page 6 S32R372141EVB Board : Overview NXP Microcontroller Ethernet Port (DNP) S32R372 JTAG The S32R372141EVB is NXP’s evaluation board for the S32R372 radar processor. It is designed to be paired with an Nexus GPIO Pins analog front end. NXP Trace Port supports the TEF810 and...
- Page 7 S32R372141EVB: Pinout 1 of 2 FUNCTION PORT PORT FUNCTION GPIO[15] PA15 P3-16 P3-15 PA14 SIUL_EIRQ13 DSPI2_SIN PA13 P3-14 P3-13 PA12 DSPI2_SOUT DSPI2_SCK PA11 P3-12 P3-11 PA10 DSPI2_CS0 GPIO[9] P3-10 P3-9 TX1_PS TX2_PS P3-8 P3-7 TX3_PS EIRQ_5 P3-6 P3-5 ERROR_RST SSN-MEM...
- Page 8 S32R372141EVB: Pinout 2 of 2 FUNCTION PORT PORT FUNCTION P5-16 P5-15 FCCU_1 FCCU_F1 P5-14 P5-13 FCCU_F0 FCCU_0 P5-12 P5-11 CAN2_TXD RESET P5-10 P5-9 GPIO[119] GPIO[104] P5-8 P5-7 PF15 CAN2_RXD CTE_RCS P5-6 P5-5 PE15 GPIO[79]_CLKOUT GPIO[77] PE13 P5-4 P5-3 GPIO[70] GPIO[68]...
- Page 9 S32R372141EVB: Communication Interfaces 1 of 3 CAN_2 DESCRIPTION NAME Port PI5 & PF15 CANL J35-03 J35-02 CAN2 CANH J35-01 CAN_0 DESCRIPTION NAME Port PB0 & PB1 CANL J31-03 J31-02 CAN0 CANH J31-01 EXTERNAL USE...
- Page 10 S32R372141EVB: Communication Interfaces 2 of 3 Ethernet Ethernet (DNP) DESCRIPTION PORT MTI_P0_IUC MTI_P0 MTI_N0_IUC MTI_N0 MTI_N2_IUC MTI_N2 MTI_P1_IUC MTI_P1 MTI_N1_IUC MTI_N1 MTI_P2_IUC MTI_P2 MTI_N3_IUC MTI_N3 MTI_P3_IUC MTI_P3 *These pins map to special purpose pads on the S32R274 MCU instead of general purpose ports as controlled by the SIUL module.
- Page 11 S32R372141EVB: Communication Interfaces 3 of 3 MIPI-CSI2 MIPI-CSI2 DESCRIPTION PORT DESCRIPTION PORT ETIMER_ETC0 PC15 CTE_RCS TX2_PS CTE_RFS PE13 TX3_PS SIUL_EIRQ13 PA14 TX1_PS DSPI2_SCK PA11 RESET ERROR_N DSPI2_CS0 PA10 MIPI-CSI2 ERROR_RST DSPI2_SIN PA13 SSN_MEM DSPI2_SOUT PA12 ETIMER_ETC2 RESET_B RESET_B ADC1_AN_0 PB13...
- Page 12 S32R372141EVB: Communication Interfaces 2 of 2 MIPI-CSI2 Ethernet DESCRIPTION PORT Ethernet (DNP) ETIMER2_ETC3 PC12 DESCRIPTION PORT SD_0_ADCN* SDADC0 Neg. Inp. MTI_P0_IUC MTI_P0 SD_0_ADCP* SDADC0 Pos. Inp. MTI_N0_IUC MTI_N0 CTE_RFS PE13 MTI_N2_IUC MTI_N2 DSPI2_SOUT PA12 MTI_P1_IUC MTI_P1 DSPI2_SIN PA13 MTI_N1_IUC MTI_N1...
- Page 13 S32R372141EVB: Programing Interface JTAG JTAG DESCRIPTION Support for JTAG-capable debugger such as USB Multilink EXTERNAL USE...
- Page 14 S32R372141EVB: Power Supply The S32R372141EVB supports two power options. You can generate 12V from a DC generator and connect that to P2; or you can plug in a 12V power supply through the barrel connector P1. NXP does not directly sell 12V power supplies. You can obtain a power supply through a third-party vendor.
- Page 15 Package Level Pinout Diagram – S32R372 (141 BGA) EXTERNAL USE...
-
Page 16: Software Development Tools
Software Development Tools • S32 Design Studio IDE for Power Architecture • IDE & Compilers − Free S32 Design Studio IDE with GCC compiler − GHS MULTI Integrated Development Environment − Cosmic IDE − iSystems winIDEA IDE − Sourcery CodeBench Development Tools •... - Page 17 Pre-Compiled Code Examples List of code examples: Hello World • Quick start examples for Hello World + PLL S32R372141EVB are available in the Hello World + PLL + Quick Start Package to help familiarize Interrupts you to the board FlexCAN (coming soon) •...
- Page 18 Documentation and Reference Material • Documentation Links − S32R372 Datasheet − S32R372 Factsheet • Application Notes − S32R Radar Signal Compression − S32R27/37 Hardware Design Guide − Clock Monitor Unit Guide − e200 Core Memory Protection Unit Guide • Reference Manuals −...
- Page 19 Radar Family – Product Feature Differences • S32R372 is the low-cost counterpart to the S32R274 radar processor • Selected features below FEATURES Flash* Security Transceiver Interface PROM S32R274 2.0MB 1.5MB Emulate 1 x 4-lane MIPI-CSI2 S32R372 *Differences in memory are all in the Large Flash Block EXTERNAL USE...
- Page 20 PLL before executing application code. • Keep S32 Design Studio IDE and OpenSDA firmware Up-to-date for best results • Post Technical Questions on NXP community for MPC5xxx. • Useful Links: − S32R372 Webpage − S32R372141EVB Webpage − nxp.com/s32ds − nxp.com/community EXTERNAL USE...
