DIGITAL MIXING CONSOLE
CSD-R7
System Setup Guide
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RIVAGE PM7 and is the answer not in the manual?

Questions and answers

Related Manuals for Yamaha RIVAGE PM7

Summary of Contents for Yamaha RIVAGE PM7

  • Page 1 DIGITAL MIXING CONSOLE CSD-R7 System Setup Guide...
  • Page 2 TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT normalement ou est tombé. EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. (UL60065_03) AVERTISSEMENT POUR RÉDUIRE LES RISQUES D’INCENDIE OU DE DÉCHARGE ÉLECTRIQUE, N’EXPOSEZ PAS CET APPAREIL À LA PLUIE OU À L’HUMIDITÉ. (UL60065_03) RIVAGE PM7 System Setup Guide...
  • Page 3 • Raadpleeg uw leverancier over de verwijdering van de batterij op het moment dat u het apparaat ann het einde van de levensduur of gelieve 이 기기는 가정용(B급) 전자파적합기기로서 주로 dan contact op te nemen met de vertegenwoordiging van Yamaha in 가정에서 사용하는 것을 목적으로 하며, 모든 uw land.
  • Page 4 Disconnect all power sources. turn off the power switch, disconnect the electric plug from the This device receives power from multi outlet, and have the device inspected by qualified Yamaha sources. When setting up the device, make service personnel. sure that the AC outlet you are using is easily accessible.
  • Page 5 In particular, do not place the device on its side or upside down. Inadequate ventilation can result in Yamaha cannot be held responsible for damage caused by overheating, possibly causing damage to the device(s), or improper use or modifications to the device, or data that is even fire.
  • Page 6 You should note this serial number in the space provided below and retain this manual as a permanent record of your purchase to aid identification in the event of theft. Model No. Serial No. (rear_en_01) RIVAGE PM7 System Setup Guide...

  • Page 7: Table Of Contents

    Setting the Unit ID ......36 Firmware updates ......9 Connecting the devices ....37 Conventions in this manual....9 Turning on the power to the RIVAGE PM7 system ....37 Accessories........9 Setting the word clock ....38 System Overview....10 Assigning channels to the TWINLANe network ......

  • Page 8: Introduction

    Superb sound quality This guide describes an iPad application that enables you to control the RIVAGE PM series system The design of the RIVAGE PM7 digital mixing system is wirelessly. an uncomprised expression of Yamaha’s philosophy of Pro Audio device design. This philosophy is called “white Using the PDF manuals canvas, ”...

  • Page 9: About Utility Software

    About utility software Accessories The RIVAGE PM7 system can be used with a variety of • AC Power Cords (×2) utility software. (The connector shape may vary depending on the sales area.) • RIVAGE PM Editor • Dust cover This application software enables you to access the •...

  • Page 10: System Overview

    • Please refer to the owner’s manual supplied with the host device for information on installing the I/O cards. • For detailed information on I/O card settings, refer to the owner’s manual for the I/O card. For the latest information on which I/O cards can be used with the system, visit the Yamaha Pro Audio website at: http://www.yamaha.com/proaudio/...

  • Page 11: About Network Card

    NOTE Yamaha recommends that you use opticalCON DUO fiber cable made by Neutrik. In general, fiber optic cables are susceptible to About network card bending or pulling. Use a fiber optic cable that features a strong...

  • Page 12: About Dante

    A daisy chain connection is suitable for a simple system with a small number of devices. http://www.audinate.com/ Use a star network if a large number of devices are connected. More information on Dante is also posted on the Yamaha Pro Audio website: Daisy Chain Network http://www.yamaha.com/proaudio/ A daisy chain is a wiring scheme in which multiple devices are connected together in sequence.

  • Page 13: Star Network

    HY144-D PRIMARY SECONDARY CSD-R7 Rio3224-D2 (UNIT ID: Y001) PRIMARY SECONDARY Rio3224-D2 (UNIT ID: Y002) PRIMARY SECONDARY Primary Dante Secondary Dante RIVAGE PM7 System Setup Guide...

  • Page 14: Part Names & Functions

    Touch Screen section ➔ page 22 Channel Strip section ➔ page 23 Selected Channel section ➔ page 15 UTILITY section ➔ page 19 SCENE MEMORY section ➔ page 20 USER DEFINED KEYS/KNOBS section ➔ page 21 RIVAGE PM7 System Setup Guide...
  • Page 15 Switch on or off the signal sent from the input channel to stereo bus A or B. 5 Meter LEDs Displays the channel signal level. 6 [CUE] key Switches channel cue send on or off. RIVAGE PM7 System Setup Guide...
  • Page 16 Lights up when GC (GAIN COMPENSATION) is enabled. ] (Phase) key Reverses the phase of the input signal. ) DELAY [ON] key Switches Delay on or off. ! DELAY display Indicates the delay value. @ [DELAY] knob Sets the delay value. RIVAGE PM7 System Setup Guide...
  • Page 17 Indicate the assigned Mute Groups. 3 INSERT [PLUG-INS] key Enables you to recall a parameter setting screen for the inserted plug-ins. 4 INSERT 1/2 [ON] keys Switch the INSERT1 and INSERT2 on or off respectively. RIVAGE PM7 System Setup Guide...
  • Page 18 4 MIX/MATRIX SENDS display Indicates the corresponding bus. 5 MIX/MATRIX SENDS [MIX]/[MATRIX] keys Switch the type of the send destination bus. 6 MIX/MATRIX SENDS [1-12]/[13-24]/[25-36]/ [37-48]/[49-60] keys Selects a bank for the send destination bus. RIVAGE PM7 System Setup Guide...
  • Page 19 Adjusts the input level of the mic connected to the will light green. If either power switch A or B is TALKBACK jack. turned on, it will light red. If the RIVAGE PM7 system is not started, it will light orange. 8 TALKBACK [ON] key Switches the Talkback function on or off.
  • Page 20 If you select the existing scene, it will be overwritten. 7 [INC]/[DEC] keys Enable you to select the scene number of a scene that you want to store or recall. 8 [RECALL] key Enables you to recall a stored scene from scene memory. RIVAGE PM7 System Setup Guide...
  • Page 21 Control the functions as assigned by the user. 4 USER DEFINED KEYS displays Indicate the functions assigned to the USER DEFINED keys. 5 USER DEFINED KEYS [1]-[12] Control the functions as assigned by the user. RIVAGE PM7 System Setup Guide...
  • Page 22 NOTICE Never use a sharp or pointed object such as your fingernail to operate the touch screens. Doing so may scratch the screens and render the touch screens inoperable. RIVAGE PM7 System Setup Guide...
  • Page 23 Channel Strip section or on the display. When the channel is selected, the key LED will light. 5 Meter LEDs Indicate the channel level. 6 Dynamics LEDs Indicate the status of Dynamics 1 and 2. RIVAGE PM7 System Setup Guide...
  • Page 24 Lights if the channel is set to Recall Safe. @ SAFE M indicator Lights if the channel is set to Mute Safe. # ISOLATE indicator Lights if the channel is “Isolated. ” $ [CUE] key Selects the channel for cue. RIVAGE PM7 System Setup Guide...
  • Page 25 Enables you to select a DCA layer. ) CUSTOM [1]/[2] keys Enable you to select a custom layer. You can assign custom faders of two banks (total of 12 layers) to each custom layer. ! Layer display Indicates the selected layer. RIVAGE PM7 System Setup Guide...

  • Page 26: Front Panel

    To put away the hanger, turn the knob clockwise to unlock it, and then push it in. 2 PHONES A/B [LEVEL] knobs Adjust the level of the signal output from the PHONES OUT jacks respectively. RIVAGE PM7 System Setup Guide...

  • Page 27: Rear Panel

    6 [RESET] switch These four 4-pin female XLR output connectors are Resets the digital mixing console. used to supply power to Yamaha LA1L gooseneck Only the controls (screens, indicators, and control lamps supplied with the unit. (4 jacks) keys and knobs) on the control surface will restart without interrupting audio.
  • Page 28 This indicator lights up or flashes green, depending This indicator lights up or flashes red if an error on the connection status. occurs. In such an event, please contact your Yamaha dealer. ! OMNI IN jacks These are balanced XLR-3-31 female input jacks for * LINK indicators...
  • Page 29 Before you turn off the power to the digital mixing fans. These vents let warm air out from the unit. console, Yamaha recommends that you store the current Please make sure that you do not block the vents with status to scene memory.

  • Page 30: Power Supply

    Turn off both power switches A and B on the Pro Audio website to see whether your CSD-R7 supports unit. that card, and to verify the number of other Yamaha cards Connect one of the supplied power cords to or third-party cards that can be used in conjunction with AC IN connector (A), and the other to AC IN this card.

  • Page 31: Removing The Mini-Ygdai Card

    Completely loosen the screws that hold the card in place. Pull the card toward you while holding the screws on the card. Replace the stored slot cover and affix it with Card the screws. RIVAGE PM7 System Setup Guide...

  • Page 32: Removing An Hy Card

    If the lever claw does not lock in, pull up the card slightly, then push it in. Affix the card using the screws that were previously used to affix the slot cover. If the card is not fastened securely, component failure or malfunction may occur. RIVAGE PM7 System Setup Guide...

  • Page 33: Touch Screen

    This frame indicates that the knob has been selected for operation. NOTE Pressing certain knobs a second time while a thick frame is displayed around them will open a window in which you can make additional detailed settings. RIVAGE PM7 System Setup Guide...

  • Page 34: Viewing A Touch Screen

    A dialog box like the following will appear when you need to confirm the operation you just performed. Press the OK button to execute the operation. The operation will be canceled if you press the CANCEL button. RIVAGE PM7 System Setup Guide...

  • Page 35: Quick Guide

    • RY card (RY16-DA) ×1 Procedure Installing an optional card Setting the Unit ID Connecting the devices Turning on the power to the RIVAGE PM7 system Setting the word clock Assigning channels to the TWINLANe network Patching the input ports Patching the output ports...

  • Page 36: Setting The Unit Id

    Use the [U]/[D] keys to select a unique Unit ID. Press the [ENTER] key to confirm the Unit ID setting. If you press the [MENU] key without confirming the Unit ID beforehand, the unit will return to the top screen. RIVAGE PM7 System Setup Guide...

  • Page 37: Connecting The Devices

    Once the digital mixing console starts, information on the connected devices will automatically be collected and all devices will synchronize. A popup screen will appear. Select the data sync direction and press the SYNC button. RIVAGE PM7 System Setup Guide...

  • Page 38: Setting The Word Clock

    For this example, select STEREO. To close the WORD CLOCK popup window, press the “x” symbol located in the upper right. The system will return to the SETUP screen. The TWINLANe CONFIGURATION popup window will appear. RIVAGE PM7 System Setup Guide...
  • Page 39 The system will return to the SYSTEM CONFIG popup window. Select the I/O rack. Press the I/O rack select button (in this example, the M1 button). The I/O rack settings popup window will appear. RIVAGE PM7 System Setup Guide...

  • Page 40: Patching The Input Ports

    [TOUCH AND TURN] knob. If you select RY card slot 1 on the I/O rack (M1), “M1/RY SLOT1” will appear. Use the knob in the lower left corner to display the input channels. RIVAGE PM7 System Setup Guide...

  • Page 41: Patching The Output Ports

    [TOUCH AND TURN] knob. If you select RY card slot 2 on the I/O rack (M1), “M1/RY SLOT2” will appear. Use the knob in the lower-left corner to display the output channels. RIVAGE PM7 System Setup Guide...

  • Page 42: Setting The Analog Gain For Ha (Head Amp)

    • Turn phantom power off before you connect a device that does not support phantom power. • Do not connect or disconnect cables while phantom power is • Be sure to set the output level controls to minimum when you turn phantom power on or off. RIVAGE PM7 System Setup Guide...
  • Page 43 Check the output port patching. To adjust the pan/balance of the signal sent from the input channel to the STEREO bus, rotate the [PAN/BAL] knob (➔ page 16 7) of the Selected Channel section. RIVAGE PM7 System Setup Guide...

  • Page 44: Check List

    Check list You can use the following list to check whether the basic connections for the RIVAGE PM7 system are working properly. Both power A and B for each device must be turned on. Make sure that two power cords are connected to each device and that both power switches A and B on each device are turned on.

  • Page 45: Other Operations

    NOTE the touch screen. An alarm message will appear if a problem is detected in the fader settings while the RIVAGE PM7 system is starting up. Press the SETUP button on the menu bar in the touch screen. The SETUP screen will appear.
  • Page 46 When calibration is complete, press the FINISH button. The calibration values will be saved in internal memory. If the [SEL] key lights and the channel color indicator turns red, calibration has failed. Press the START button to perform calibration again. RIVAGE PM7 System Setup Guide...

  • Page 47: Troubleshooting

    ❍ Make sure that the power switches are turned ON. ❍ Make sure that the AC power cords are connected. ➥ If the power still does not turn on, contact your Yamaha dealer. The unit is not receiving an audio input signal.

  • Page 48: Specifications

    Conditions Min. Typ. Max. Unit OMNI IN 1-8 OMNI OUT 1-8 600Ω AD + DA, GAIN: –6 dB — OMNI OUT 1-8 600Ω DA Converter * An IHF-A filter is used to measure dynamic range. RIVAGE PM7 System Setup Guide...
  • Page 49 100–240 V 50/60 Hz — — kcal/h Power cable length and temperature range Conditions Min. Typ. Max. Unit Power cord length — — Temperature range Operating temperature range °C — Storage temperature range °C –20 — RIVAGE PM7 System Setup Guide...
  • Page 50 The unit features an internal switch to change the maximum output level. The +24dBu switch position can be changed for fee so that the output level will be +20 dBu. For more information, contact your Yamaha dealer. Connectors are balanced. (1=GND, 2=HOT, 3=COLD) These measurements were obtained when the PHONES A/B LEVEL knobs are set 10 dB lower than the maximum.
  • Page 51 Touch-sensitive 100mm motorized faders; resolution +10 dB to –138 dB, –∞ dB (1024 steps) NC value Low mode: NC=20 / High mode: NC=25 Measuring position: 30cm horizontally away and vertically up from the unit (front pad), RIVAGE PM7 System Setup Guide...

  • Page 52: Pin Assignment Table

    M2.6 x 0.45 mm pitch LAMP Pin No. Signal Pin No. Signal Pin No. Signal GPO1 GPO2 N.C. GPO3 GPO4 N.C. GPO5 GPO6 GPO7 RLY_NC +12V RLY_C RLY_NO OPTO- OPTO+ GPI1 GPI2 GPI3 GPI4 GPI5 GPI6 GPI7 N.C. RIVAGE PM7 System Setup Guide...

  • Page 53: Dimensional Diagrams

    Approximate Munsell value of exterior color: N5 * The contents of this manual apply to the latest specifications as of the publishing date. To obtain the latest manual, access the Yamaha website then download the manual file. RIVAGE PM7 System Setup Guide...

  • Page 54: Index

    HY card..............35 Mini-YGDAI card ..........30 RY card ..............35 Output port ..............41 OVERLAY ..............20 Patch input port..............40 output port ............. 41 Rear panel ..............27 Ring connection............11 RY card................35 RIVAGE PM7 System Setup Guide...
  • Page 55 MEMO RIVAGE PM7 System Setup Guide...
  • Page 57 Valletta Road, Mosta MST9010, Malta JAFZA-16, Office 512, P.O.Box 17328, Tel: +356-2133-2093 Jebel Ali FZE, Dubai, UAE Tel: +971-4-801-1500 PA50 Head Office/Manufacturer: Yamaha Corporation 10-1, Nakazawa-cho, Naka-ku, Hamamatsu, 430-8650, Japan (For European Countries) Importer: Yamaha Music Europe GmbH Siemensstrasse 22-34, 25462 Rellingen, Germany...
  • Page 58 Yamaha Pro Audio global website http://www.yamaha.com/proaudio/ Yamaha Downloads http://download.yamaha.com/ Manual Development Group © 2018 Yamaha Corporation Published 01/2018 IPTO-A0 ZX89210...
